Dickson Cobalt X1 User Manual

Hide thumbs Also See for Cobalt X1:

Advertisement

Quick Links

Download this manual
Cobalt X1 / X2
OCEAView
User guide for firmware version 2.9

Advertisement

loading
Need help?

Need help?

Do you have a question about the Cobalt X1 and is the answer not in the manual?

Questions and answers

Related Manuals for Dickson Cobalt X1

Summary of Contents for Dickson Cobalt X1

  • Page 1 Cobalt X1 / X2 OCEAView User guide for firmware version 2.9...
  • Page 2 Introduction Notices and safety Disclaimer Dickson assumes no liability for any loss or claims by third parties which may arise through the use of this product. Users must not use the product in any manner not limitation specifically indicated by Dickson.
  • Page 3 Introduction Certifications and compliance Caution: Any changes or modifications made to this product not expressly approved in writing by Dickson could void the user's authority to operate the equipment. FCC statement This device complies with part 15 of the FCC rules.
  • Page 4 This device is compliant with the restriction of the use of certain hazardous substances in electrical and electronic equipment Directive 2002/95/EC (RoHS Directive). Do not dispose of this product with household trash. Dickson recycles this product under certain conditions. Please contact us for more information.
  • Page 5 ©2023 Dickson. All rights reserved. Dickson, the Dickson logo, Cobalt, Cobalt X, OCEAView, and DicksonOne are the exclusive property of Dickson. LoRa and LoRaWAN are registered trademarks or service marks of Semtech Corporation or its affiliates. The Bluetooth word mark, figure mark, and combination mark are trademarks of the Bluetooth SIG, Inc.
  • Page 6 Introduction Table of contents Notices and safety ................... 2 Certifications and compliance ..............3 Table of figures ....................10 1 Introduction ....................13 1.1 About this User Guide .................. 13 Terminology ...................... 13 1.2 OCEAView / Cobalt X solution overview ........... 15 LoRaWAN vs Bluetooth wireless topologies ..........
  • Page 7 Bluetooth Low Energy (BLE, Bluetooth Smart) .......... 38 4.2 Preparing the mounting kit ................. 39 5 Using external sensors ................40 5.1 Dickson Pt100 Smart-Sensors ..............40 Connecting Smart-Sensors ................41 Placing Smart-Sensors ................... 42 5.2 Digital temperature sensors ............... 46 Connecting a digital sensor ................
  • Page 8 Introduction Usage ........................61 Tube placement ....................64 Placement and assembly ................66 5.6 Dry contact input sensor ................68 Overview ......................68 Key specifications .................... 69 Plugging the connector cable into your data logger ....... 69 Activating dry contact functionality .............. 70 Testing current status of dry contact loop ..........
  • Page 9 Introduction Using remote sensors ..................99 Swapping sensors ................... 105 7.3 Advanced menu ..................108 Calibrating the Cobalt X screen ..............109 Resetting the Cobalt X data logger battery counter ........ 110 LoRaWAN network setup ................111 LoRaWAN wireless range test ..............112 LoRaWAN radio performance ..............
  • Page 10 Figure 6 – Side view of the Cobalt X data logger ............22 Figure 7 – Bottom view of Cobalt X2 (with two connectors) ........23 Figure 8 – Cobalt X data logger with Dickson wired and wireless sensors.... 24 Figure 9 – Cobalt X data logger dimensions ..............28 Figure 10 –...
  • Page 11 Introduction Figure 41 – Place tube on High (+) connector for positive values when monitoring a high-pressure cleanroom and negative values when monitoring a low-pressure cleanroom ............. 64 Figure 42 – Complete differential pressure sensor assembly ......... 65 Figure 43 – Slide the Smart-Sensor extension onto the Cobalt X data logger ..67 Figure 44 –...
  • Page 12 Introduction Figure 83 – Resetting a wireless sensor’s battery counter ........103 Figure 84 – BLE performance test with four connected remote sensors .... 104 Figure 85 – Choose the current wireless sensor you want to replace ....106 Figure 86 – Choose the new wireless sensor ............106 Figure 87 –...
  • Page 13 Alert The OCEAView solution alerts users when an alarm occurs. Alert notifications can be to users via e-mail, voice message, or SMS/text. The system can also trigger Dickson alert devices. Bluetooth ® Short-range wireless communication protocol, generally used in point-to-point connections (i.e.
  • Page 14 Web platform monitoring solution that allows you to ™ configure, manage, and monitor your Cobalt X data loggers. Smart-Sensor ™ Dickson technology that simplifies sensor management, notably by storing calibration and sensor information to provide plug-and-play operation. Cobalt X Data Logger User Guide (OCEAView) Page 14...
  • Page 15 Combined with the OCEAView web application, Cobalt X data loggers provide a flexible solution for monitoring parameters simultaneously on several pieces of equipment in your lab or storage facilities. Cobalt X1 supports two active data logging sessions; Cobalt X2 supports up to four active data logging sessions.
  • Page 16 Introduction the data to the server automatically. This solution notably enables sensor read times as low as 5 seconds (in specific cases) and cost-effective coverage in areas with a low number of sensors. Figure 2 – Data logger in Bluetooth mode with OCEABridge gateway The usage model described in the OCEAView User Guide is identical for both LoRaWAN and Bluetooth operation.
  • Page 17 Unlimited data storage on OCEAView web platform • Internal data logger memory for up 4,000 readings per sensor channel (8,000 total on Cobalt X1; 16,000 total on Cobalt X2) Note: memory capacity for the dry contact sensor channel is 1,800 readings •...
  • Page 18 Introduction Information flow The diagram below summarizes the information flow between Cobalt X data loggers and the OCEAView platform. Remember, Cobalt X data loggers can be used with either LoRaWAN or Bluetooth wireless connectivity. Your choice of technologies depends on your specific needs and site requirements.
  • Page 19 Introduction LoRaWAN operation overview Step Process Comments For best wireless performance, follow recommendations when Place your Cobalt X data logger as physically placing your data required to monitor your equipment. logger, as described in section 4 - Placing your Cobalt X data logger, p. 38. Plug in wired sensors (recognized automatically) and/or pair Bluetooth sensors.
  • Page 20 Introduction Bluetooth-only operation overview The steps described here require the presence of a properly configured OCEABridge Bluetooth enabled gateway to communicate with OCEAView on the Cloud. Step Process Comments Remember that Bluetooth connectivity is limited to about 30 Place your Cobalt X data logger as meters.
  • Page 21 USB cable to AC power adapter Physical connector(s) for external sensors: 1 connector on Cobalt X1 2 connectors on Cobalt X2 Figure 4 – Cobalt X2 data logger with two external sensors Cobalt X Data Logger User Guide (OCEAView) Page 21...
  • Page 22 Introduction Rear view The battery compartment is located on the back of the data logger. The rear of the data logger has a slot to attach the data logger to the plastic holder using a small padlock (optional). See Chapter 4 – Placing your Cobalt X data logger, p. 38, for mounting information.
  • Page 23 Up to four simultaneous sensor channels on Cobalt X2 • Up to two simultaneous sensor channels with Cobalt X1 Plugs for connecting wired sensors are located at the bottom of the unit (two physical connectors on the X2 model and one physical connector on the X1 model).
  • Page 24 Smart-Sensor interface External digital temperature Figure 8 – Cobalt X data logger with Dickson wired and wireless sensors. Please check with your authorized Cobalt X representative for the latest information on available sensors. Cobalt X Data Logger User Guide (OCEAView)
  • Page 25 Adhesive-backed magnet (already attached) o Plastic ties and adhesive hooks for arranging cables • Flat sensor extension cable with Binder connector – 1 cable with Cobalt X1 or 2 cables with Cobalt X2 (1.5 m / about 5 feet) •...
  • Page 26 Technical specifications Technical specifications 2.1 Characteristics General • Color LCD display: 2.4” • Touch screen: Resistive • Number of sensor channels (simultaneous data logging sessions): X1: 2 channels, X2: 4 channels • Number of sensors (wired and/or wireless): X1: One physical plug (supports 1 single, dual, or triple sensor) and up to four Bluetooth wireless sensors.
  • Page 27 Technical specifications Monitoring • Read interval: Bluetooth operation: 5 seconds minimum on Cobalt X1 or 15 seconds minimum on Cobalt X2, up to 12 hours maximum. LoRaWAN operation: 1 minute to 12 hours (depending on the transfer interval configured in OCEAView) •...
  • Page 28 Technical specifications 2.2 Dimensions Data logger (in mm) Figure 9 – Cobalt X data logger dimensions Mounting kit (in mm) Figure 10 – Cobalt X mounting kit details Cobalt X Data Logger User Guide (OCEAView) Page 28...
  • Page 29 Technical specifications 2.3 Power options The Cobalt X data logger can be powered by two replaceable internal batteries (3.6 V) located on the back, or by AC power using the optional 5 Volt DC adapter. Battery specifications • 2 x SAFT LS17500 batteries: Lithium thionyl chloride, A-size bobbin cell •...
  • Page 30 Getting started 3.1 Prerequisites • An operational gateway: o For LoRaWAN operation: Dickson LoRaWAN gateway installed and setup to connect to the OCEAView web platform o For Bluetooth operation: OCEABridge Bluetooth gateway installed and setup for web platform connectivity •...
  • Page 31 Getting started 3.2 Attaching the antenna The Cobalt X data logger requires an antenna to connect properly to your LoRaWAN network. The antenna is provided in the package with your data logger. Attach the antenna to the data logger as shown here: 1.
  • Page 32 Getting started 3.3 Using the mounting cradle The Cobalt X data logger includes a mounting cradle with a pre-attached magnet for adhering to metal surfaces. It is imperative to thoroughly clean the mounting surface before placing the data logger cradle. The cradle may also be mounted with screws.
  • Page 33 Getting started Mounting the cradle with screws Please make sure any screws and anchors you use are compliant with local regulatory requirements and safety practices. 1. Insert the screws through the holes in the mounting cradle on the desired surface. 2.
  • Page 34 Getting started 3.4 Activating your Cobalt X data logger To activate your Cobalt X data logger and enable it to communicate with the web platform, follow these steps: 1. Locate the Lithium batteries provided in the product box. 2. Insert the provided batteries in the battery compartment, making sure to respect polarity (+/-) as indicated on the printed image inside the compartment): Follow the “+”...
  • Page 35 Getting started To power your data logger using the AC adapter: 1. Plug the AC adapter into an electrical power outlet. 2. Insert the adapter’s cable into the USB port located on the side of the Cobalt X data logger, keeping the 3.6V batteries installed as back-up. Do not remove batteries from your data logger even when using the AC adapter.
  • Page 36 Getting started 3.5 LoRaWAN network selection This section assumes that your LoRaWAN-enabled gateway is up and running and within wireless range of the Cobalt X data logger you are trying to connect. After powering up the Cobalt X data logger: 1.
  • Page 37 Getting started 3. The Cobalt X ready screen is displayed as shown below, pending configuration via the monitoring application. This screen is displayed whenever data logging is not running on the data logger. Figure 16 – Cobalt X ready screen Cobalt X Data Logger User Guide (OCEAView) Page 37...
  • Page 38 Long-range wireless connectivity enables Cobalt X data loggers to be placed nearly anywhere in your building or site. If you are using a Dickson LoRaWAN gateway and the signal is not strong enough, a second LoRaWAN-enabled gateway may be required.
  • Page 39 Placing your Cobalt X data logger 4.2 Preparing the mounting kit The Cobalt X data logger can be mounted easily on various surfaces. The data logger holder can be fixed using the screws or maintained in a stable position with its magnetic surface.
  • Page 40 5.1 Dickson Pt100 Smart-Sensors The image below shows a Cobalt X data logger with an external Pt100 sensor, connected via the specially designed Dickson Smart-Sensor interface. Figure 17 – Cobalt X wireless data logger with a Pt100 Smart-Sensor Cobalt X Data Logger User Guide (OCEAView)
  • Page 41 Using external sensors Connecting Smart-Sensors The Cobalt X data logger and all types of external Smart-Sensors are independent from each other regarding calibration. Calibrated external Smart-Sensors store their own calibration parameters internally and can thus be plugged into any Cobalt X data logger.
  • Page 42 Using external sensors This feature offers an easy way to handle sensors at calibration time (depending on your standard operating procedure) without leaving your equipment unattended. Simply have an identical calibrated sensor on-hand and swap it with the one that needs calibration (replace with the same type of sensor: Pt100 with Pt100, or digital sensor with digital sensor).
  • Page 43 Using external sensors 5.1.2.1 Pt100 for ultra-low-temperature freezers When installing a Pt100 sensor in an ultra-low-temperature (ULT) freezer, it is easier to proceed with a thawed freezer. When possible, route the sensor through the same access port used by the unit control sensor or an accessory port, such as that shown below in Figure 19.
  • Page 44 Using external sensors Figure 19 – Sample Pt100 access port for ULT freezer Cobalt X Data Logger User Guide (OCEAView) Page 44...
  • Page 45 Pt100 sensors for LN2/cryogenic tanks must be mounted, when applicable, in close proximity to the unit display sensor. To avoid temperature measurement disparities, Dickson recommends mounting the sensor at the same height as the display sensor. As an example, some freezers have an access panel on the back of the unit in which you may route the sensor cable up the back wall.
  • Page 46 Using external sensors 5.2 Digital temperature sensors Standard external digital sensors from Dickson do not connect to data loggers via the Smart-Sensor interface, which means calibration parameters must be configured manually in the OCEAView web application. Figure 21 – Cobalt X data logger with external digital sensor Depending on the design of the space to be monitored, you may be able to pass the sensor through an access port or opening.
  • Page 47 Using external sensors Connecting a digital sensor Simply connect the sensor cable to the data logger by plugging it in to one of the available connectors directly, as shown here: Insert the keyed sensor plug onto an available port on the bottom of your module Figure 22 –...
  • Page 48 Using external sensors 2. Clean the surface for the sensor using alcohol to remove any grease or dirt. 3. Attach one of the plastic cable holders to the sensor, remove the protective strip from the adhesive, and place the holder on the clean spot inside the enclosure.
  • Page 49 This option is generally used in various types of storage, medical and traceability applications. This sensor connects via the Dickson Smart-Sensor connector, and therefore already contains calibration parameters if the sensor was calibrated by OCEAOSFT. Figure 25 – Cobalt X data logger with dual temperature-humidity sensor...
  • Page 50 Using external sensors Placing the sensor Mount the Cobalt X data logger in the desired location using the provided holder. Choose the attachment method that works best for your situation and place the Cobalt X data logger as described in section 4 – Placing your Cobalt X data logger, p.
  • Page 51 5.4 Triple CO - Temperature - Humidity Smart-Sensor Overview The Dickson CO , temperature, and humidity Smart-Sensor is a triple-function device with three sensors. This Smart-Sensor unit is designed to be placed upright inside an incubator and connected via the provided ribbon cable to a Cobalt X data logger placed outside the incubator.
  • Page 52 Using external sensors The various components in the above image are as follows: Description AC adapter, provided with several international plugs USB charging cable, plugged into AC adapter on left-hand side of Smart-Sensor extension Smart-Sensor extension, connected to the bottom of the Cobalt X data logger Smart-Sensor extension connector cable USB charging cable from Smart-Sensor extension providing...
  • Page 53 IP44 protection, plastic casing (ABS, Polycarbonate) with PTFE filter, 0 to 90% RH non-condensing for indoor use Please feel free to contact your Dickson representative for details regarding sensor accuracy, drift, and calibration. Placing the sensor and Cobalt X data logger Follow these instructions to assemble and place your triple sensor unit.
  • Page 54 Using external sensors 2. Make sure that the sensor unit stays in an upright position: Figure 29 – Sensor unit inside incubator 3. Clip the Smart-Sensor extension firmly onto the bottom of the Cobalt X data logger.  Figure 30 – Slide the Smart-Sensor extension onto the Cobalt X data logger Cobalt X Data Logger User Guide (OCEAView) Page 54...
  • Page 55 Using external sensors 4. Plug one end of the longer USB charging cable into the AC adapter and the other end into the left-hand side of the Smart-Sensor extension ( ), then plug the adapter into a wall socket with power. Plug the shorter USB charging cable into the Smart-Sensor extension and the Cobalt X data logger ( ) –...
  • Page 56 Using external sensors 6. Connect the temperature-humidity sensor unit to the back of the casing.  Figure 33 – Place the temperature/humidity sensor on the back of the unit 7. The fully assembled kit looks like this: Figure 34 – Fully connected triple sensor assembly 8.
  • Page 57 5 cm (2 inches) distance from high voltage components. Also, avoid running the sensor cable in parallel with high voltage wiring. Feel free to contact your Dickson representative for instructions regarding proper sensor and cable placement. Cobalt X Data Logger User Guide (OCEAView)
  • Page 58 X is located and one or more other spaces. This is described in more detail in the following sections. Three options are available for this Smart-Sensor: Single differential pressure sensor (for Cobalt X1) Single differential pressure sensor with 50 cm Smart-...
  • Page 59 Note regarding model with Smart-Sensor connection The extension with a Smart-Sensor extension cable (for Cobalt X2) accommodates both the tube for measuring differential pressure and other compatible Dickson Smart-Sensors. The 50 cm cable extends the second connector from the Cobalt...
  • Page 60 The Differential Pressure Smart-Sensor can be integrated with tubing provided by an existing system. Tube length and diameter have a direct effect on pressure readings. Please feel free to contact your Dickson representative for details regarding sensor accuracy, drift, calibration, and hose length.
  • Page 61 Using external sensors Usage The Differential Pressure Smart-Sensor is often used for monitoring in two different types of laboratory scenarios. In many laboratories, ambient air pressure is used to control the direction of particle flow. The differential pressure data logger is placed outside the cleanroom so that people know it is safe to enter, as shown in these two examples: 1.
  • Page 62 Using external sensors 2. Low pressure cleanrooms, such as virology laboratories in which the ambient pressure is lower than the neighboring room, hallway, or airlock in order to help keep particles from exiting the cleanroom. Cobalt X placement outside cleanroom Figure 38 –...
  • Page 63 Using external sensors You may cascade pressure control with an airlock before entering the cleanroom. Placed outside the airlock, the dual sensor data logger could be used in this case. Cobalt X placement outside airlock Figure 39 – High pressure cleanroom with an airlock Cobalt X placement outside airlock...
  • Page 64 Using external sensors Tube placement The photos in this section show the model with a single sensor, but operation with the dual sensor model is identical. With the Differential Pressure Smart-Sensor: • Air flowing in through the Low (-) opening produces a negative value on the display •...
  • Page 65 Using external sensors One of the input pairs must always be left open. The dual sensor model is configured identically to the single sensor model described here. The complete kit is shown here (Cobalt X sold separately): Figure 42 – Complete differential pressure sensor assembly Cobalt X Data Logger User Guide (OCEAView) Page 65...
  • Page 66 Using external sensors The various components in the above image are as follows: Description 4 to 5 mm straight adapter; 4 to 5 mm “T” adapter Clear Tygon® hose (diameter: 4 mm; length 50 cm) which can be connected to an existing pressure monitoring system. Note: air flow through the sensor creates a dependence on the tube length.
  • Page 67 Using external sensors Figure 43 – Slide the Smart-Sensor extension onto the Cobalt X data logger 4. Place the Tygon tubing firmly onto the appropriate connector, generally High (+), as described in section 5.5.3 – Key specifications, p. 60. 5. Mount your Cobalt X data logger outside the cleanroom or airlock as appropriate.
  • Page 68 Using external sensors 5.6 Dry contact input sensor Overview The dry contact input sensor on the Cobalt X data logger (in firmware version 2.6.x and higher) can be used to monitor many types of standard industry equipment that either provides a dry contact output connection or a simple pair of wires to form a continuous low-current electrical loop.
  • Page 69 Using external sensors Key specifications • 2-wire cable with 2.5 mm jack • Cable lengths: 6.6 ft (2 m), 11.5 ft (3.5 m), or 16.4 ft (5 m) Note: memory capacity for the dry contact sensor channel is 1,800 events (state-change with date &...
  • Page 70 Using external sensors Activating dry contact functionality By default, the dry contact input sensor is not enabled on your data logger. Follow these steps to activate it: 1. Tap on Menu ( )  Sensors  Dry contact 2. Enter your PIN code and tap OK. 3.
  • Page 71 Using external sensors Testing current status of dry contact loop After activating the dry contact input, you may check its current status as follows: 1. Tap on Menu ( )  Sensors  Dry contact 2. Enter your PIN code and tap OK. Tap on Current status.
  • Page 72 Using external sensors Showing sensors You may confirm sensor configuration with respect to “Normally closed” or “Normally open”, typically after connecting the sensor to the output terminal or wires on the monitored device. 1. Tap on Menu ( )  Sensors  Show sensors 2.
  • Page 73 Using external sensors Wiring and common use cases Connect the 2-wire cable from the Cobalt X data logger to the appropriate output or wiring on the device for which you are monitoring open/closed status. The data logger implements a “dry loop”, that is, you must not inject any current or apply any voltage source to the dry contact wires.
  • Page 74 Using external sensors 5.6.7.2 Remote alarm contacts on an ultra-low-temperature freezer The dry contact input sensor is commonly used to monitor laboratory equipment, such as ultra-low-temperature freezers with a specific remote alarm contact output terminal. The contacts, which are triggered in the event of various alarm conditions, are typically located on the back of the equipment.
  • Page 75 Using external sensors 5.6.7.3 Wired door contact The dry contact input sensor is well suited for monitoring door contact devices. In this case, “Normally closed” is the most common setting (that is, the door is considered to be closed under normal circumstances). Corresponding Cobalt X 2-wire connection setting...
  • Page 76 5.7 4-20 mA and 0-10 V loop sensors Description Dickson 4-20 mA current loop and 0-10 V current Smart-Sensors can be connected to industry-standard devices that generate appropriate output signal. The signal can be measured to provide status information for a variety of...
  • Page 77 You can use any combination of wired or wireless sensors with your Cobalt X data logger, with up to two active wireless sensors on Cobalt X1, or up to four on Cobalt For the Cobalt X data logger to discover your nearby Atlas or Emerald wireless sensor, you must first activate Bluetooth on the sensor as described below.
  • Page 78 Using external sensors When within wireless range, the wireless sensor appears in the sensor pairing screen of the Cobalt X data logger. You may connect to it at any time as described in section 7.2.3.1. Pairing a Bluetooth wireless sensor, p. 99. Activating an Atlas data logger 1.
  • Page 79 Cobalt X user interface Cobalt X user interface The Cobalt X data logger offers a highly visible color LCD screen and a simple menu system. Using the data logger’s touch screen, you can navigate easily through data logging pages and menu settings, even while wearing most types of protective gloves.
  • Page 80 Cobalt X user interface 6.2 Entering your PIN code Some actions on your Cobalt X data logger require the user to enter a PIN code to continue. Only users authorized to use a PIN code are allowed to enter into the Advanced menu or acknowledge alarms directly on the data logger screen.
  • Page 81 Cobalt X user interface 6.3 Sensor display and control Cobalt X allows you to connect a variety of different sensors that can be configured to meet your needs. With the X1 data logger, you may monitor up to two physical parameters simultaneously (2 sensor channels);...
  • Page 82 Cobalt X user interface Status bar The Status bar across the top of Cobalt X screen includes the menu icon, wireless status, and battery level. The status bar remains visible on all screens, except when the data logger is in screen saver mode. It is slightly different in LoRaWAN and Bluetooth modes.
  • Page 83 Cobalt X user interface Data logging The Cobalt X data logger shows the currently programmed data logging cycle(s). Data is shown on a single screen or splits into distinct areas when two or more configurations are defined. Single data logging session (one sensor) Figure 61 –...
  • Page 84 Cobalt X user interface Multiple data logging sessions The display can show details for up to four sensors at the same time on the main screen. To adjust the display: 1. Select Menu  Settings  Items per page: Figure 62 – Setting the number of displayed data logging sessions 2.
  • Page 85 Cobalt X user interface More than two data logging sessions (three or four sensors) If you set the display to show two sensors, and more than two sensors are currently activated for data logging (on a Cobalt X2 data logger), right and left arrows present on the screen so you can access the other sensors: Figure 64 –...
  • Page 86 Cobalt X user interface Wireless sensor indicator As mentioned earlier, Cobalt X supports wired and wireless sensors. Wired sensors are plugged directly into the data logger; wireless sensors communicate via Bluetooth and are “paired” with the data logger (pairing process described in section 7.2.3 –...
  • Page 87 Cobalt X user interface On-demand reading Data on the Cobalt X screen is refreshed periodically. As a result, the temperature in the monitored environment may be different than the reading currently displayed on the unit itself. You may check the current reading at any time without affecting stored information.
  • Page 88 Cobalt X user interface 6.4 Screen backlight When the Cobalt X is on battery power, the backlight is managed to preserve battery life. The backlight turns off after 30 seconds of inactivity following the last user action. When the display is turned off, simply touch the Cobalt X screen to turn it back on. By default, the screen backlight remains on when the data logger is plugged in using the AC power adapter (USB).
  • Page 89 Configuration menus Configuration menus The Cobalt X data logger includes configuration menus for interacting with the data logger and setting specific parameters. Tap on the menu bars to open configuration menus.  Figure 68 – Accessing Cobalt X configuration menus Cobalt X Data Logger User Guide (OCEAView) Page 89...
  • Page 90 Configuration menus The following diagrams shows the menu structure according to whether the data logger is being used with LoRaWAN or Bluetooth wireless communication. Features are described in the following sections: Menu structure for LoRaWAN use Figure 69 – Menu structure when using LoRaWAN wireless operation Cobalt X Data Logger User Guide (OCEAView) Page 90...
  • Page 91 Configuration menus Menu structure for Bluetooth use The structure is the same as for LoRaWAN operation, but some options are grayed out in the interface and not available in Bluetooth mode. Figure 70 – Menu structure when using Bluetooth wireless operation Cobalt X Data Logger User Guide (OCEAView) Page 91...
  • Page 92 Configuration menus 7.1 Settings Tap on Menu ( )  Settings for the following options: Figure 71 – Options in the Settings menu Cobalt X Data Logger User Guide (OCEAView) Page 92...
  • Page 93 Configuration menus Setting Cobalt X language The Language option allows you to change the display language of your Cobalt X. To change the language: 1. Tap on Menu ( )  Settings  Language Figure 72 – Choosing the display language 2.
  • Page 94 Configuration menus Changing the temperature unit Temperature readings can be displayed in degrees Celsius (°C) or Fahrenheit (°F). To change the temperature unit shown on your Cobalt X data logger: 1. Tap on Menu ( )  Settings  Units 2.
  • Page 95 Configuration menus Decimal places You may choose to display sensor readings on the home screen with either one or two decimal places, as shown here: – or – Figure 74 – Values displayed with one or two decimal points 1. Tap on Menu ( ) ...
  • Page 96 Configuration menus Information System information such as the firmware version, LoRaWAN wireless frequency, and remaining battery capacity can be found in the Information screen. This information is mostly useful in case you need technical support and are asked to provide specific details. 1.
  • Page 97 Configuration menus 7.2 Sensor management Showing sensors When several sensors are connected to your Cobalt X data logger, you may display the readings and parameters of each sensor using the Show sensors feature. The display shows each sensor for about ten seconds before cycling on to the next. Tap on Menu ( ) ...
  • Page 98 Configuration menus Updating sensors on OCEAView When you physically plug a sensor into the connector on the Cobalt X data logger, the unit automatically recognizes the sensor and sensor type. That information is then transmitted to the OCEAView web application. If a sensor is not present or not up to date in the web application, you may use the Refresh sensor option to force it to detect the new sensor and update the configuration.
  • Page 99 Pairing the Cobalt X data logger with a Dickson wireless sensor is simple and guided through the touch screen.
  • Page 100 Configuration menus 5. When discovered, your sensor is displayed on the screen. Figure 80 – Tap to pair the wireless sensor Note: Sensors with data logging currently activated or already connected to another Cobalt X data logger cannot be paired. 6.
  • Page 101 Configuration menus Once in paired with a Cobalt X data logger in “remote” mode, the wireless sensor is no longer visible as a data logger itself in the OCEAView Mobile application and will not be detected by the OCEABridge Bluetooth gateway. Sensor configuration will now be controlled exclusively by your OCEAView web application.
  • Page 102 Configuration menus 7.2.3.2 Unpairing a Dickson wireless sensor To unpair your Dickson wireless sensor: 1. Tap on the menu icon ( )  Sensors  Remote sensors 2. Enter your PIN code and tap OK. 3. Tap on Unpair remote sensors 4.
  • Page 103 Configuration menus 7.2.3.3 Resetting a remote sensor’s battery counter To reset the Emerald wireless sensor’s battery counter (only after removing or replacing batteries), use the Reset battery option on your Cobalt X data logger. Only perform this action if you really install new batteries in your Emerald wireless data logger.
  • Page 104 Configuration menus 7.2.3.4 Checking Bluetooth wireless signal strength You may check Bluetooth wireless signal strength between your Cobalt X data logger and paired remote sensors to make sure that connectivity is strong and reliable between the devices. 1. Tap on the menu icon ( ) ...
  • Page 105 Configuration menus Swapping sensors Wired sensors With your Cobalt X data logger, you may directly swap wired sensors that are physically connected to your data logger, such as for recalibration or to replace damaged cables. Wired sensors may be replaced on-the-fly whether data logging is running or not.
  • Page 106 Configuration menus To swap sensors: 1. Tap on the menu icon ( )  Sensors  Remote sensors 2. Enter your PIN code and tap OK. 3. Tap on Swap sensor 4. Tap to select the sensor to replace and tap OK to confirm: ...
  • Page 107 Configuration menus 6. A confirmation message is shown when the process is complete. Figure 87 – Confirmation message that the swap process is complete 7. Tap on OK  menu icon ( ) to return to the home screen. You may unpair the first sensor if you do not expect to use it again on the same Cobalt X data logger.
  • Page 108 Configuration menus 7.3 Advanced menu The Cobalt X data logger includes an Advanced menu that you can use for troubleshooting and to confirm that your data logger is working properly. Figure 88 – Features in the Advanced menu To limit access to the Cobalt X parameters and prevent unwanted changes, the Advanced menu is protected by your personal access code as configured in the OCEAView web application and is recommended for qualified personnel only.
  • Page 109 Configuration menus Calibrating the Cobalt X screen If your Cobalt X data logger screen does not respond accurately to your touch, the touch screen may require calibration to position touch point coordinates correctly. Proceed as follows to calibrate screen alignment: 1.
  • Page 110 Configuration menus Resetting the Cobalt X data logger battery counter It is imperative to replace Cobalt X data logger batteries when the battery indicator is down to one bar, before data logging becomes unreliable. To install new Replacing batteries batteries, see section 9.1 , p.
  • Page 111 Configuration menus LoRaWAN network setup LoRaWAN wireless technology offers the flexibility to deploy your monitoring solution with different types of access architecture. Your network selection must reflect the license or subscription you choose for your system. To configure your data logger: 1.
  • Page 112 Configuration menus LoRaWAN wireless range test You may use the range test feature in the Advanced menu to ensure that your Cobalt X data loggers are within wireless range of the configured LoRaWAN network (i.e. your LoRaWAN gateway). This feature is useful for system installers, as it can help you prepare your environment before deploying Cobalt X data loggers.
  • Page 113 Configuration menus We recommend not setting up your data loggers if signal level is weak. Poor signal quality can result in inadequate coverage and cause system performance or reliability problems. The wireless signal may be affected by excessive obstruction, RF/radio interference, or harsh environmental conditions. Make sure the data logger in question is placed optimally long-term operation.
  • Page 114 Configuration menus LoRaWAN radio performance You may check to see how well your data logger’s wireless radio is performing. Based on results, you may choose to adjust placement or positioning of the data logger. 1. Tap on Menu ( )  Advanced 2.
  • Page 115 Configuration menus 7.4 Quick server connection test Without using the Advanced menu, you may perform a simple Test command to make sure that your Cobalt X data logger is able to communicate with the server. This function sends a request to the server and waits for a response to determine whether the server is reachable.
  • Page 116 Configuration menus 7.5 Data synchronization The OCEAView monitoring solution enables you to force synchronization of your Cobalt X data logger with the server. This may be useful to speed up certain operations, notably: • When adding a new sensor to a Cobalt X data logger: if you use the Synchronize function, the new sensor is updated on the server right away, otherwise the update occurs at the next programmed data transfer.
  • Page 117 Configuration menus 7.6 Using your data logger in Bluetooth-only mode The Cobalt X data logger may be used in “Bluetooth-only” mode, that is, without any LoRaWAN functionality. In that case, the data logger behaves exactly as it does with LoRaWAN connectivity, but data transmission is handled via Bluetooth wireless “advertising frames”...
  • Page 118 Alarms and warnings Alarms and warnings One of the Cobalt X data logger’s most important features is its ability to detect alarm conditions and work in tandem with the OCEAView server platform to notify designated users when problems occur. An alarm condition can be one of the following: •...
  • Page 119 Alarms and warnings When an alarm or warning occurs, the translucent outer ring on the Cobalt X casing flashes for as long as data logger remains in an alarm condition. The light stops flashing if, at the next programmed sensor read, the alarm condition has ended. Two colors are used for alarms: •...
  • Page 120 Alarms and warnings 8.1 LED status indications The color ring on the Cobalt X casing indicates data logger status and offers simple patterns based on status, as described below: General (  = short flash ) Data logger is booting ...
  • Page 121 Alarms and warnings 8.2 Alarm buzzer When the Cobalt X data logger is running on external power (using the optional AC adapter), the buzzer is activated to notify users in case of event on the data logger itself or at any point during data logging. For example, the buzzer is heard when the temperature or humidity is above or below programmed limits.
  • Page 122 Alarms and warnings In some cases, or certain known situations, you may want to mute alarms temporarily. To snooze an alarm: 1. Tap once on the alarm icon ( 2. A “mute” symbol appears in the left-hand corner of the screen: ...
  • Page 123 Alarms and warnings Acknowledging an alarm When an alarm is in progress, the Cobalt X data logger remains in an alarm state as long as the alarm conditions are present. If data logging was programmed with a delay to trigger an alarm only after a specified period of time, a stopwatch icon is displayed on the data logging screen (as described in the next section) and the alarm is activated when the limit is reached.
  • Page 124 Alarms and warnings 3. Tap on the up/down arrows ( ) to select a reason for the acknowledgement: Figure 101 – Choose a reason for acknowledging the alarm 4. Once the alarm is acknowledged, the alarm icon is no longer shown on the Cobalt X data logger screen.
  • Page 125 Alarms and warnings Alarm delay indicator When setting up data logging, you may program a delay before the alarm is triggered. For example, you could set a 5-minute delay for the data logger to wait 5 minutes before triggering an alarm in case the temperature rises above, or drops below, the programmed limit.
  • Page 126 Maintaining your Cobalt X data logger Maintaining your Cobalt X data logger 9.1 Replacing batteries The Cobalt X data logger runs on batteries and/or AC power (via an adapter plugged into the USB port). Batteries are not installed prior to delivery. If data logging is currently running, we recommend that you not take any risks by removing both batteries at the same time.
  • Page 127 Maintaining your Cobalt X data logger 3. A single battery will ensure continued operation so you can replace the other battery without interrupting data logging: Remove one used battery from the data logger and replace it with a new one, making sure to respect battery polarity (see image printed inside battery slot).
  • Page 128 Maintaining your Cobalt X data logger 9.2 Cleaning instructions You may occasionally need to clean your Cobalt X data loggers depending on conditions at your site. Here are some recommendations and guidelines for cleaning your data loggers: 1. Clean the data logger using a soft cloth lightly moistened with water, a detergent or isopropanol alcohol.
  • Page 129 Appendix 1 – Cobalt X battery life 10 Appendix 1 – Cobalt X battery life Cobalt X data logger battery life varies depending upon many factors: 1. Ambient temperature: battery capacity is diminished when subject to very cold or extreme heat conditions. 2.
  • Page 130 Appendix 2 - Troubleshooting 11 Appendix 2 - Troubleshooting If you are having difficulties with your configuration, have a look at these frequently asked questions before contacting technical support. I swapped a sensor and received a Sensor Fail error. But then everything seemed OK.
  • Page 131 Appendix 2 - Troubleshooting transfer interval occurs. Wait for the next transfer interval to get your data updated. This could also be due to a loose cable or improperly connected temperature sensor. Check the cable between the Cobalt X data logger and the sensor. Unplug the sensor and plug it back in.
  • Page 132 Appendix 2 - Troubleshooting The unit or temperature range for my sensor is not displayed correctly in the OCEAView web application. What should I do? Under rare conditions, it may happen that the sensor’s physical parameter (unit) or temperature does not appear properly in the OCEAView web application. If that occurs, resynchronize the information by unplugging the sensor from the Cobalt X data logger and pressing Settings ...
  • Page 133 Appendix 2 - Troubleshooting Cobalt X Data Logger User Guide (OCEAView) Page 133...

This manual is also suitable for:

Cobalt x2
