K800 24V FCM FAST
‫رسومات فنية للمشروعات‬
Technical drawings for projects
‫عامل‬
‫مزود الطاقة‬
Operator
Power Supply
K800 24V FCM FAST
230V 50/60Hz
‫ماكس بوابة الوزن‬
Max gate weight
800 kg / 1760 lbs
RIB ‫يتم ضمان التشغيل الصحيح للمشغل فقط في حالة إدارته بواسطة لوحة تحكم‬
The correct operation of the operator is guaranteed only if it is managed by a RIB control panel
3 ‫ / الصفحة العربية‬ENGLISH page 5
‫ / مع‬with
See page 17
‫دفع‬
‫أقصى قوة دفع‬
Thrust
Max Thrust
382 N
550 N
1
L1 24V-CRX
‫االنفعال االقصى‬
Max torque
18,5 Nm
‫الشفرة‬
Code
AA31134

Advertisement

loading
Need help?

Need help?

Do you have a question about the K800 24V FCM FAST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RIB K800 24V FCM FAST

  • Page 1 18,5 Nm AA31134 RIB ‫يتم ضمان التشغيل الصحيح للمشغل فقط في حالة إدارته بواسطة لوحة تحكم‬ The correct operation of the operator is guaranteed only if it is managed by a RIB control panel 3 ‫ / الصفحة العربية‬ENGLISH page 5...
  • Page 2 ‫ الحد األدنى و‬sqmm 1،5 ‫ مع‬H05RN -F ‫ برقية نوع‬RIB ‫2 ° - لل قسم ونوع من النصائح الستخدام الكابالت‬ 3° - Positioning of a possible couple of photoelectric cells: the radius of the photoelectric cells .‫...
  • Page 3 L1 24V-CRX ‫ مع‬K800 24V FAST ‫تعليامت مبسطة حول‬ ‫1 - توصيل امللحقات‬ 24 Vdc 3 W 24 Vdc 20 W A+TEST / A- 24Vdc 0,5A ±15% 24Vdc 0,5A ±15% 230Vac 50HZ T 1,6A 24Vac 10Vac ANTENNA SCHERMATURA CAVO D’ANTENNA 433 MHz ‫...
  • Page 4 K800 24V FAST ‫ لـ‬DIP 16 ON ‫ و‬OFF 15 ‫ت ر اجع‬ .L1 24V ‫ لالستفادة من جميع الوظائف املتقدمة التي ميكن أن يقدمها لك مجلس‬RIB GATE App ‫+ مع وحداتها) واستخدام هاتفك الذيك مع تطبيق‬APP ‫ (أو بطاقة‬APP ‫تنبيه: • قم بتثبيت بطاقة‬...
  • Page 5 SIMPLIFIED INSTRUCTIONS FOR K800 24V FAST WITH L1 24V-CRX 1° Connecting the accessories MANUAL RELEASE L.S. OPEN SAFETY AND CLOSE 24 Vdc 3 W 24 Vdc 20 W COMMON A+TEST / A- 24Vdc 0,5A ±15% PHOTOCELL AUTO-TEST OR ENERGY SAVING (LOW BATTERY) WITH BATTERY 24Vdc 0,5A ±15%...
  • Page 6 DIP 15 OFF and DIP 16 ON for K800 24V FAST ATTENTION: Install the APP card )or the APP+ card with its modules( and use your smartphone with the RIB GATE App to take advantage of all the advanced features that the L1 24V control board...
  • Page 7 SYSTEM LAY-OUT 1 - K operating device 2 - External photocells 3 - Rack of Module 4 4 - Key selector 5 - Radio antenna 6 - Blinker 7 - Limit switch plate (cams) 8 - TOUCH Safety edge or VERTIGO photocell 9 - TOUCH Safety edge or VERTIGO photocell 10 - Internal Photocells 11 - Photocell columns...
  • Page 8 INSTALLATION K800 24V FAST CHECKING BEFORE THE INSTALLATION !! THE GATE SHALL MOVE FRICTIONLESS !! N.B.: Gate features must be uniformed with the standards and laws in force. The door/ gate can be automated only if it is in a good condition and its conditions comply with the EN 12604 norm.
  • Page 9 MOTOR AND RACK FITTING N.B.: To use metal rack only code ACS9050. The holes for fixing the metal rack must be made at 130 mm height from the motor support. The height of the rack can be adjusted thanks to the slots available on its right -angled bar. The height adjusting is necessary to prevent the gate leaning on the driving gear (5 and 6).
  • Page 10 ELECTRIC CONNECTIONS L1 24V code AC08080 MANUAL RELEASE L.S. OPEN SAFETY AND CLOSE 24 Vdc 3 W 24 Vdc 20 W COMMON A+TEST / A- 24Vdc 0,5A ±15% PHOTOCELL AUTO-TEST OR ENERGY SAVING (LOW BATTERY) WITH BATTERY 24Vdc 0,5A ±15% POWER SUPPLY OPERATION 230Vac 50Hz...
  • Page 11 A - CONNEXIONS J13 J12 Wiring and fixing of power supply cable PROG > PHASE > NEUTRAL > EARTH Power supply 230 Vac 50/60 Hz - external to the control panel 10VAC Connectors for secondary 10 vac transformer - (120 V 60 Hz upon request) 24VAC Connectors for secondary 24 vac transformer A+COM...
  • Page 12 GRADUAL BRAKING programming procedure must be repeated. DIP 10 ON =>Brake activated. With the RIB GATE app it is possible to regulate braking making Note: the low speed starting point is calculated automatically by the control unit during the it gradual.
  • Page 13 The 10 s for programming the codes are automatically renewed, with LED Through the RIB GATE app it is possible to configure the operation of this relay as desired. DL12 which flashes red, in order to store the next transmitter.
  • Page 14 gate is closing, it re-opens the gate. Flasher and buzzer are activated with 2 tones every 5 s for one minute. REMOTE CONTROL FOR BOTH FULL AND PEDESTRIAN OPENING DIP 6 ON = > it runs a cyclical command sequence open-stop-close-stop-open etc. STOP BUTTON )COM A+/STOP( - Safety function PL “b”...
  • Page 15 - Feedback control - Memory storage (codes) 1000 - All inputs must be used as clean contacts because the power is generated internally (secure power) to the board and is set up to ensure compliance with double or reinforced insulation with regard to dangerous voltage.
  • Page 16 TABLE SUMMARISING VISUAL AND SOUND ALARMS SIGNALS DURING PROGRAMMING SEQUENCE EVENT BUZZER STATUS FLASHER STATUS DL1 LED STATUS DIP 1 ON (hold-to-run mode) Flashes ON/OFF 250 ms Or failure of a safety device DIP 2 ON (full stroke programming) Flashes ON/OFF 500 ms DIP 2 ON >...
  • Page 17 ACCESSORIES For the connections and the technical data of the optional equipments follow the relevant handbooks. RACK MODULE 4 PLATE TO BE CEMENTED with zinc plated angle Iron, in 2 m bars. code ACG8107 Ideal for gates up to 1,000 kg / 2,200 lbs weight. code ACS9050 FIT SLIM EN12978 - EN13849-2 SAIL...
  • Page 18 RADIO TRANSMITTER SUN RADIO MODULE 433MHz SUN 2CH code ACG6052 SUN 4CH code ACG6054 code ACG8069 SUN CLONE 2CH code ACG6056 SUN CLONE 4CH code ACG6058 SUN-PRO 2CH code ACG6210 SUN-PRO 4CH code ACG6214 APP8050 APP card APP8054 APP+ card to manage the control panel using to manage the control panel using Bluetooth 4.2 transmission...
  • Page 22 PHOTOCELLS CONNECTIONS 4 FIT SLIM / FIT SYNCRO photocells with self-test and infrared signal synchronizer 2 photocells FIT SLIM, FIT SYNCRO with self-test COM A+ TX SYNCRO COM A+ A+ TEST cod. ACG8028 PHOT1 PHOT2 A+ TEST PHOT1 PHOT2 cod. ACG8029 A*D+ A*D+ A*D+...
  • Page 23 K800 24V FCM FAST ACG9515 BA10088 CPL1225 CEL1522 CCA1535 AC08080 CEL1661 CEL1654 CEL1645B CTC1259 CMO5498 BA01019 ACG1082 BA01079 CME2046 CVA1372 CPL1437 CTC1164 CTC1308 CTC1243 DAC35X95I CPL1177 CME2028 CTC1221 CPL1435 CEL1652 CTC1406 CTC1355 CTC1012 CTC1123 CTC1355 DTB6X20I CME2043 CTC1205 DRL6X12I CTC1018...
  • Page 24 R.I.B. S.r.l. - Via Matteotti, 162 - 25014 Castenedolo - Brescia - Italy Tel. ++39.030.2135811 - www.ribind.it - ribind@ribind.it :‫موديل الجهاز‬ :‫الغرض من اإلقرار‬ K800 24V FCM FAST Apparatus model : Object of the declaration : c/ L1 24V-CRX :‫) وااللت ز ام بها‬EC/2006/42( ‫تم تطبيق المتطلبات األساسية التالية لتوجيه الماكينات‬...
