- Page 1 Clickback Sofa Assembly Guide Scan for Full CCD-0009329 Manual REV: 9.26.24...
- Page 2 MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP CLEAR AND USE CAUTION Assembly Foot Assembly Instructions 1. Remove sofa from shipping box. 2. Organize parts. 3. Place sofa on its back (Fig.1) and attach all four feet by inserting two screws into each foot and into the bottom of the sofa (Fig.2).
- Page 3 Back Assembly 1. Unfold the front seat and middle seat to expose mounting bolts and nuts (Fig.3). middle seat bolt and nuts front seat Fig.3 2. Set back assembly in place with holes in the mounting brackets aligned with holes in the V2 frame (Fig.4). bracket V2 frame Fig.4...
- Page 4 Lippert provides explicit consent to distribute individual parts. All manual information is subject to change without notice. Revised editions will be available for free download at lippert.com. Manual information is considered factual until made obsolete by a revised version.
