This User Manual has been translated using machine translation. We have made every effort to
ensure the translation is accurate, but please note that automated translations are not perfect and
are not meant to replace human translators. The official version of the User Manual is in English.
Any differences between the translated version and the original English are not legally binding. If
you have any questions about the accuracy of the translation, please refer to the English version,
which is the official reference. More language versions are available upon request via
info@expondo.com.
Technical data
Parameter description
Product name
Model
Capacity max loading [ton]
Max pressure [bar]
Dimensions [width * length * height; mm]
Weight [kg]
Description
This product is constructed with the ZG 3/8" connector, the hydraulic pump body, the non-slip handle, the oil
return switch, and the oil hose. It supports lifting, jacking, shovelling, and splitting operations. The split-type
hydraulic cylinder is easy to disassemble and store but must be used with a hydraulic pump. For optimal
compatibility, the CP-180 pump suits 5T, 10T, and 20T hydraulic cylinders, and the CP-700 pump is for 30T and
50T ones.
This product is widely used in the installation and maintenance of large and medium-sized machinery in
industries such as construction, oil, power, metallurgy, chemical, marine, bridge, and steel sectors.
Note: This product is not suitable for automotive use.
The user is liable for any damage resulting from unintended use of the device.
EN
Parameter value
Hydraulic cylinder with pump
10
700
200*400*155
6.2
