WARNING
Read this Owner's Operation Manual before using your solder pot. Failure to follow the
safety precautions and instructions in this manual could result in serious injury and
property damage.
Thank you for buying a goot Solder Pot. Your new solder pot has been engineered and manufactured to
the goot high standard for dependability, ease of operation, and operator safety. Please follow this
operation manual for your continued safety and operational comfort.
SOLDER POT
POT-100C / 103C
POT-200C / POT-202C
KEEP THIS MANUAL FOR FUTURE REFERENCE
TAIYO ELECTRIC IND.CO.,LTD.
OPERATION MANUAL
POT-203C
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Goot POT-100C
Summary of Contents for Goot POT-100C
- Page 1 Thank you for buying a goot Solder Pot. Your new solder pot has been engineered and manufactured to the goot high standard for dependability, ease of operation, and operator safety. Please follow this operation manual for your continued safety and operational comfort.
- Page 2 SAFETY MARK DEFINITIONS The following marks of WARNING and CAUTION are defined below. Please make sure you fully understand the contents to ensure proper use and protection of operator and others from injury and damage. WARNING Failure to obey a safety warning could result in serious injury or death to yourself or to others.
- Page 3 TABLE OF CONTENTS SAFETY MARK DEFINITIONS ....................2 TABLE OF CONTENTS....................3 SAFETY INFORMATION ....................4 SPECIFICATIONS ......................5 3-1. F ........................5 EATURES 3-2. S ......................5 PECIFICATIONS PACKAGE CONTENTS ....................6 HOW TO SET UP ......................7 5-1. S ..........................
- Page 4 5 years 3 years This table compares the bath lives of goot POT-100C/200C and POT-103C/203C. It is only a guide. When using more chlor-flux, erosion is faster. And note that the chlorine will rust the bath surface. TAIYO ELECTRIC IND.CO.,LTD.
- Page 5 PID temperature control minimizes deviation between the actual solder temperature and the set temperature. Warning lamp to detect any deviance from set temperature range. Lead-free applicable (POT-103C/203C) 3-2. Specifications MODEL POT-100C POT-103C POT-200C POT-203C Voltage 110V, 120V, 130V, 220V, 230V, 240V, AC 50/60Hz...
- Page 6 PACKAGE CONTENTS Make sure that all the items listed below are included. And store the packaging until making sure that the pot functions properly. Main unit Instruction manuals (for POT, RB series quick operation / Parameter) Tray Slag holder Slag remover TAIYO ELECTRIC IND.CO.,LTD.
- Page 7 2. Hook the slag holder to the side of the top plate. 3. Check that the power switch is OFF (O side), and connect the power cord. *POT-100C/200C: Plug the power cord into an outlet. *POT-103C/203C: Connect the power cord to the switchboard.
- Page 8 5-2. Functions of Control Panel ① ② ③ ⑥ ④ ⑤ ⑦ ⑧ ⑨ ⑩ 1. PRESENT VALUE (PV) DISPLAY Displays the actual measured value (PV) and each parameter. 2. INDICATION OF MEASUREMENT UNITS Displays the unit of temperature(°C or °F), or manipulated value(MV) or each parameter. 3.
- Page 9 5-3. How to set the value Example: Inputting 400°C as the set value (SV) (PV value: 30°C). [Enter the setting mode] Press the SET key to enter the SV setting mode. The lowest digit in the SV display will flash. OUT1 OUT2 MAN STOP DO1 DO2...
- Page 10 MAINTENANCE Make sure that the tip of the sensor is always in the melted solder. Always keep the melted solder volume at about 1cm below the rim of the pot. When using the solder pot for long periods, oxidized dross may accumulate around the walls of the solder bath.
- Page 11 9. Reassemble with new heaters, reversing these steps. POT-103C/203C 1. The same steps as the procedure of Heater Replacement POT-100C/200C 1-5. 2. Remove the screws which fix the ground wire. 3. Pull out the bath with the front heat insulation board.
- Page 12 Bath Replacement POT-100C/200C 1. The same steps as the procedure of Heater Replacement POT-100C/200C 1-2. 2. Pull out the bath. 3. Mount a new bath. POT-103C/203C 1. The same steps as the procedure of Heater Replacement POT-103C/203C 1-4. 2. Remove the screws and take out the ground wire.
- Page 13 Fuse 250V 8A for the 110-130V model Fuse 250V 4A for the 220-240V model Heat insulation board set (Only available as a set) Tray for POT-100C/103C Slag remover for POT-100C/103C/200C/203C Slag holder for POT-100C/103C/200C/203C PCB holder for dipping (Option) ②...
- Page 14 Fuse 250V 8A for the 110-130V model Fuse 250V 4A for the 220-240 model Heat insulation board set (Only available as a set) Tray for POT-100C/103C Slag remover for POT-100C/103C/200C/203C Slag holder for POT-100C/103C/200C/203C PCB holder for dipping (Option) heater-fixing bracket ③...
- Page 15 Fuse 250V 8A for the 110-130V model Fuse 250V 4A for the 220-240 model Heat insulation board set (Only available as a set) Tray for POT-200C/203C Slag remover for POT-100C/103C/200C/203C Slag holder for POT-100C/103C/200C/203C PCB holder for dipping (Option) ③...
- Page 16 C top plate B ⑤ top plate A ⑥ ④ ⑥ sensor ⑪ ⑧ ⑨ Web site: www.goot.co.jp/e E-mail: info@goot.co.jp TEL: (81)84-951-1512 “goot” is registered trade mark of TAIYO ELECTRIC IND.CO.,LTD. Printed in Japan MARCH 2012 A4330BA00 TAIYO ELECTRIC IND.CO.,LTD.
