KEEP THIS MANUAL FOR FUTURE REFERENCE Thank you for buying a goot Solder Pot. Your new solder pot has been engineered and manu- factured to the goot high standard for dependability, ease of operation, and operator safety. Please follow this operation manual for your continued safety and operational comfort.
SAFETY MARK DEFINITIONS The following marks of WARNING and CAUTION are defined below. Please make sure you fully understand the contents to ensure proper use and protection of operator and others from injury and damage. WARNING Failure to obey a safety warning could result in serious injury or death to yourself or to others.
2 SAFETY INFORMATION To assure safe operation, read and always follow the rules below. WARNING Do not attempt to operate the unit before you have read thoroughly and understood completely all instructions, safety rules, etc. contained in this manual. WARNING Make sure that the machine must be grounded at all times to prevent electrical shocks and static electricity.
Page 5
5 years more 5 years 3 years This table compares the bath lives of goot POT-100C/200C and POT-103C/203C. It is only a guide. When using more chlor-flux, erosion is faster. And note that the chlorine will rust the bath surface.
• PID temperature control minimizes deviation between the actual solder temperature and the set temperature. • Warning lamp to detect any deviance from set temperature range. • Lead-free applicable (POT-103C/203C) 3-2 Specifications MODEL POT-100C POT-103C POT-200C POT-203C 110V, 120V, 220V, 230V,240V 110–120V, 220–240V 110V, 120V, 220V, 230V,240V 110–120V, 220–240V...
2. Hook the slag holder to the side of the top plate. Slag holder 3. Check that the power switch is OFF (O side), and connect the power cord. *POT-100C/200C : Plug the power cord into an outlet. Tray *POT-103C/203C : Connect the power cord to the switchboard.
5-2. Functions of Control Panel ① PRESENT VALUE (PV) DISPLAY Displays the actual measured value (PV ) and ① each parameter. ② ② INDICATION OF MEASUREMENT UNITS ③ ⑥ Displays the unit of temperature( ˚C or ˚F), or ④ manipulated value(MV) or each parameter. OUT1 OUT2 MAN STOP DO1 DO2...
5-3. How to set the value Example: Inputting 400˚C as the set value (SV) (PV value: 30˚C). Enter the setting mode Press the SET key to enter the SV setting mode. The lowest digit in the SV display will flash. OUT1 OUT2 MAN STOP DO1 DO2...
6 MAINTENANCE • Make sure that the tip of the sensor is always in the melted solder. Always keep the melted soldervolume at about 1cm below the rim of the pot. • When using the solder pot for long periods, oxidized dross may accumulate around the walls of thesolder bath.
Heater Replacement 4. Take out the shield board. 5. Remove the nuts (2 locations) which fix the POT-100C/200C heater-lead wire. Be careful not to loosen the 1. Turn off the main power switch and unplug bottomnuts.
Page 13
Bath Replacement POT-100C/200C 1. The same steps as the procedure of Heater Replacement POT-100C/200C 1-2. 2. Pull out the bath. 3. Mount a new bath. POT-103C/203C 1. The same steps as the procedure of Heater Replacement POT-103C/203C 1-4.
④ - ⑥ Heat insulation board set (Only available as a set) Fuse 250V 10A ⑦ Tray for POT-100C/103C Heat insulation board set (Only available as a set) ⑧ Slag remover for POT-100C/103C/200C/203C Tray for POT-100C/103C ⑨ Slag holder for POT-100C/103C/200C/203C Slag remover for POT-100C/103C/200C/203C ⑩...
Page 15
④ Fuse 250V 10A ⑤ - ⑦ Heat insulation board set (Only available as a set) ⑧ Tray for POT-100C/103C ⑨ Slag remover for POT-100C/103C/200C/203C ⑩ Slag holder for POT-100C/103C/200C/203C ⑪ PCB holder for dipping (Option) PCB-1 heater-fixing bracket ③...
Page 16
④ Fuse 250V 10A ⑤ - ⑧ Heat insulation board set (Only available as a set) ⑨ Tray for POT-200C/203C ⑩ Slag remover for POT-100C/103C/200C/203C ⑪ Slag holder for POT-100C/103C/200C/203C ⑫ PCB holder for dipping (Option) PCB-1 ⑬ Solder pot cover POT-200C-TCV ⑬...
Page 17
③ Bath [POT-203CP] ④ - ⑦ Heat insulation board set (Only available as a set) ⑧ Tray for POT-200C/203C ⑨ Slag remover for POT-100C/103C/200C/203C ⑩ Slag holder for POT-100C/103C/200C/203C ⑪ PCB holder for dipping (Option) PCB-1 ③ heater-fixing bracket ⑦...
Page 20
