- Page 1 PF2200 - SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0...
- Page 3 Congratulations on your purchase of the PF2200 BMS Controller! We are thrilled that you have chosen Profire to deliver the most user-friendly, dependable, and secure burner management and combustion control solutions for your heating application — and that’s just the beginning! For 20+ years we have been dedicated to designing products for thermal appliances used across several industrial applications.
-
Page 4: Important Safety Information
PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 IMPORTANT SAFETY INFORMATION WARNING – EXPLOSION HAZARD. DO NOT DISCONNECT WHILE THE CIRCUIT IS LIVE OR UNLESS THE AREA IS FREE OF IGNITIBLE CONCENTRATIONS. WARNING – EXPLOSION HAZARD. DO NOT REMOVE OR REPLACE FUSES UNLESS POWER HAS BEEN DISCONNECTED OR THE AREA IS FREE OF IGNITIBLE CONCENTRATIONS. - Page 5 PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 APPROVALS AND RATINGS The PF2200-SB is certified to the following standards: SIL 2 Capable IEC 61508: 2010 Parts 1-7 Approved for use in a 1oo1 deployment configuration Electrical Burner Control System UL 60730-2-5/ ANSI Z21.20-2014 • CSA C22.2 No. 60730-2-5 UL 121201 •...
- Page 6 PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 OVERVIEW This document provides a brief overview of the installation ACCESS PF2200-SB DOCUMENTATION requirements, user interface features, operating sequence, and functionality of the PF2200-SB BMS controller. Additional documentation for released PF2200 Firmware versions is available at profireenergy.com.
-
Page 7: Installation
In such a way as to avoid direct sunlight exposure on the screen. Extended UV exposure may compromise viewability. • Such that the enclosure door can be fully opened during maintenance and commissioning. Refer to the installation section of the Product Manual available on Profire's website for additional instructions. 855.PRO.FIRE PROFIREENERGY.COM... -
Page 8: Controller Interface
PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 CONTROLLER INTERFACE SCREENS STATUS STATUS Ready Alarm The PF2200-SB controller consists of 3 main screens: BATH (°C) BATH (°C) OUTLET (°C) OUTLET (°C) 186.5 186.5 107.5 107.5 1. STATUS SCREEN – Always-on display that shows [197] [197] [128]... -
Page 9: Buttons And Functions
PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 BUTTONS AND FUNCTIONS BUTTONS FUNCTIONS Start the system from the Ready state Reignite when one pilot is lost while running Stop the system* Return to previous screen from an on-screen menu Cycle through Status, Settings, and System screens Display keypad functionality help screen Switch to Commissioner Mode to see all available settings Switch to Operator Mode to see only essential settings and setpoints... -
Page 10: Key Settings
PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 KEY SETTINGS TEMPERATURE SETTINGS NAME DEFAULT RANGE DESCRIPTION 90 °C -40 °C - 1350 °C HIGH TEMP Temperature threshold at which the system shuts down. SETPOINT 194 °F -40 °F - 2462 °F High Temp Setpoint must be greater than Pilot Off Setpoint If Type setting is set to RTD, High Temp Setpoint must be less than 850 °C (1562 °F) 85 °C... -
Page 11: Input Settings
PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 INPUT SETTINGS NAME DEFAULT RANGE DESCRIPTION Input threshold at which the system will 4-20 LOW TRIP 12 mA 4 mA - 20 mA initiate a low-trip event in accordance SETPOINT with the 4-20 Low Trip Mode setting. Type must be set to 4-20 Input threshold at which the system will 4-20 HIGH TRIP... -
Page 12: Drop Down Menu Settings
PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 SETTINGS MODIFICATION DROP DOWN MENU SETTINGS QUICK SETTING ACCEPTED CHANGE METHOD ADJUSTMENT METHOD SETTINGS SETTINGS Bath Bath Ready Ready Type Type Input Dual Input Dual Mode Process Control Mode Process Control 90.0 90.0 °... - Page 13 PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 NUMERIC SETTINGS QUICK SETTING ACCEPTED CHANGE METHOD ADJUSTMENT METHOD SETTINGS SETTINGS Bath Bath Ready Ready Type Type Input Dual Input Dual Mode Process Control Mode Process Control 90.0 90.0 ° ° High Temp Setpoint High Temp Setpoint 85.0 85.0...
-
Page 14: System Tools
PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 SYSTEM TOOLS SYSTEM THE EVENT LOG SCREEN Event Log Press OK For Options/Export Date Time Description Page: 1/22 Sep 30 18:07:24 Clear Shutdown Code received (SYSTEM > LOGGING > EVENTS) Sep 30 18:06:12 Wait 10: Purging Sep 30 18:06:12... - Page 15 PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 THE PF2200-SB DIAGNOSTIC SYSTEM Ready Diagnostics Logging MENUS Temperature Power Events Inputs Run Metrics Data Outputs Modbus (SYSTEM > DIAGNOSTICS) Flame Keypad Contain useful real-time system input and Settings Customization Firmware output measurements, run metrics and useful Reset Info Status Priority...
-
Page 16: Operating Sequence
PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 OPERATING SEQUENCE The PF2200-SB utilizes a state-based control scheme to safely monitor and control a burner. Each system state has specific entry and exit requirements and defined output behavior. NOTE: The current system state is always displayed in the Status Bar located at the top of the User Interface screen. -
Page 17: State Diagram
Power On Alarm Lockout Ready Waiting Any Fuel State Ignition Pilot Main Light Off Process Control For further information on the operating sequence, please refer to the Product Manual specific to your FW version, available on Profire’s website. 855.PRO.FIRE PROFIREENERGY.COM... -
Page 18: Troubleshooting
PF2200-SB INSTALLATION AND OPERATION GUIDE DOC-001042 v7.0 TROUBLESHOOTING PROBLEM PROPOSED SOLUTIONS Ensure pilot assembly, flame rod, and the gap between are fully engulfed in flame. If not, adjust rod position Ensure flame detection wiring does not exceed the recommended maximum length System has visible flame but cannot detect 3. - Page 19 Together with our Trusted Partners, we’ve curated a comprehensive suite of services tailored to meet your evolving needs. From determining your exact requirements to ensuring smooth operations for years to come, you can rely on Profire and our partners for prompt and dependable support. These services include: Consulting –...
