- Page 1 Meat Grinder Model MG-IT-0008-S Item 11055 Instruction Manual Revised - 03/13/2019 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
- Page 2 Table of Contents Model MG-IT-0008-S Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 7 Technical Specifications -------------------------------------------------------------------------- 7 Installation --------------------------------------------------------------------------------------- 7 - 9 Operation --------------------------------------------------------------------------------------- 9 - 11 Maintenance --------------------------------------------------------------------------------- 12 - 13 Troubleshooting...
- Page 3 If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.
- Page 4 Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
- Page 5 Safety and Warranty In the phase of equipment, maintenance and cleaning, and during all further manual operations that happens introducing the hands or other body parts in the machine dangerous areas, a residual risk remains due above all to: 1. Knocks with machine manufacturing parts. 2.
- Page 6 1 YEAR PARTS AND LABOUR BENCH WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment.
- Page 7 Safety and Warranty Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use. Please see https://omcan.com/disclaimer for complete info. WARNING: The packaging components are classified as normal solid urban waste and can therefore be disposed of without difficulty.
- Page 8 Installation can cause some malfunctions and the ranger situation beginning for the operators. The operator must besides have received an adequate training. PACKING REMOVAL – OPENING MODALITY The machines are packed so that the infiltration / entering of liquids, organic matters or beings alive is avoided: this is performed from a covering in polyethylene around the machine, and inserted in a cardboard box of adequate size.
- Page 9 Installation The disassembly activities of the grinding group from the machine are performed following in the backwards way the assembly phases previously described, starting from the phase n. 2 passing to the phase n. 1. For a plate and knife better improvement and duration it is advised to keep them always coupled.
- Page 10 Operation CONTROLS AND VERIFICATIONS BEFORE STARTING VERIFICATION / CONTROL MODALITY AND CHECKS Check that: Sight control of the indicated parts, to check of • Extraneous objects aren’t on the machine, inside objects or extraneous bodies lacking as for example the hopper, and inside the machine neck. different tools, clothes, etc.
- Page 11 Operation PUT IN FUNCTION The machine operator can put in function the machine following in order the under reported indications: 1. Controls positive result for the preparation preliminary operations. 2. Controls positive result for the electric feeding. 3. Plug connection in opportune current socket. For the functioning of the GRINDING GROUP: •...
- Page 12 Maintenance CLEANING It is forbidden to clean by hand the organs and the elements in motion. All cleaning interventions must be started only and exclusively, after having unloaded the machine with the food product in working and having insulated from the electric feeding source and from external energy. The machine, the electric equipment and the machine board components must not be ever washed utilizing water, and not in any kind of jets form and quantity;...
- Page 13 Maintenance FREQUENCY PERSONNEL MODALITY At the end of every Operator DISINFECTION shift work and • Use detergents with PH neutral not oxidizing. however before the • If the hot water is used (> 60°C) use exclusively daily use. demineralised water. •...
- Page 14 Authorized Assistance Center. Thermal intervention due to the Wait the complete cooling before overheating. the machine restarting. Damaged micro switch. Contact directly the Authorized Assistance Center. REFERENCE Manufacturer Model Item Number Model Number Description Number 11055 MG-IT-0008-S Meat Grinder 0.5HP 110/60 8kg...
- Page 15 Parts Breakdown Model MG-IT-0008-S 11055...
- Page 16 Parts Breakdown Model MG-IT-0008-S 11055 Item No. Description Position Item No. Description Position Item No. Description Position 78001 Screw DA 3.5x9.5 for TS8 1, 36 68921 Screw DA 5x14 for TS8 68932 Base Gasket for TS8 68910 Aluminum Closing Disc 80mm for TS8...
- Page 17 Electrical Schematics Model MG-IT-0008-S 11055...
- Page 18 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
- Page 19 Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté...
- Page 20 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
