ZyXEL P-336M
802.11g Wireless MIMO Router
User's Guide
Version 1.00
Edition 1.00
1/2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P-336M and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications P-336M

Summary of Contents for ZyXEL Communications P-336M

  • Page 1 ZyXEL P-336M 802.11g Wireless MIMO Router User’s Guide Version 1.00 Edition 1.00 1/2006...

  • Page 2: Copyright

    Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patent rights of others.

  • Page 3: Federal Communications Commission (Fcc) Interference Statement

    ZyXEL P-336M User’s Guide Federal Communications Commission (FCC) Interference Statement The device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operations.
  • Page 4 Certifications 1 Go to www.zyxel.com 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page 注意 ! 依據 低功率電波輻射性電機管理辦法...

  • Page 5: Zyxel Limited Warranty

    ZyXEL P-336M User’s Guide ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two (2) years from the date of purchase.

  • Page 6: Customer Support

    ZyXEL P-336M User’s Guide Customer Support Please have the following information ready when you contact customer support. • Product model and serial number. • Warranty Information. • Date that you received your device. • Brief description of the problem and the steps you took to solve it.
  • Page 7 ZyXEL P-336M User’s Guide METHOD SUPPORT E-MAIL TELEPHONE WEB SITE REGULAR MAIL SALES E-MAIL FTP SITE LOCATION info@pl.zyxel.com +48-22-5286603 www.pl.zyxel.com ZyXEL Communications ul.Emilli Plater 53 POLAND +48-22-5206701 00-113 Warszawa Poland http://zyxel.ru/support +7-095-542-89-29 www.zyxel.ru ZyXEL Russia Ostrovityanova 37a Str. RUSSIA sales@zyxel.ru...

  • Page 8: Table Of Contents

    List of Figures ......................12 List of Tables ......................14 Preface ........................16 Chapter 1 Getting Started ....................... 18 1.1 About Your P-336M ..................18 1.2 Features ......................18 1.3 Hardware Connection and Wizard Setup ............19 1.3.1 Front Panel LEDs ..................19 Chapter 2 The Web Configurator....................
  • Page 9 ZyXEL P-336M User’s Guide 3.3 LAN Setup ......................30 3.4 DHCP Overview ....................30 3.4.1 IP Pool Setup ....................31 3.4.2 DHCP Setup .....................31 3.5 Wireless LAN Overview ..................33 3.5.1 SSID ......................33 3.5.2 Channel ....................33 3.5.3 Transmission Rate (Tx Rate) ..............33 TM .......................33 3.5.3.1 SuperG...
  • Page 10 5.1.4 Configuration Backup ................68 5.1.5 Configuration Restore ................69 5.2 System Time and Date ..................70 5.3 Syslog ........................72 5.4 E-mail .........................73 5.5 System .......................75 5.5.1 Rebooting Your P-336M ................75 5.5.2 Device Reset ....................75 5.6 Firmware ......................76 5.7 DDNS .........................77 Chapter 6 Status ........................80 6.1 Device Info ......................80...
  • Page 11 ZyXEL P-336M User’s Guide Table of Contents...

  • Page 12: List Of Figures

    ZyXEL P-336M User’s Guide List of Figures Figure 1 Web Configurator: Login ................. 20 Figure 2 Device Info ....................21 Figure 3 Save Settings: Success ................. 22 Figure 4 Change Password ................... 23 Figure 5 Basic: Start (Wizard) ................24 Figure 6 Basic: WAN: Dynamic IP ................
  • Page 13 ZyXEL P-336M User’s Guide Figure 39 Tools: System: Reboot the Device ............75 Figure 40 Tools: System: Reset ................76 Figure 41 Tools: Firmware ..................76 Figure 42 Tools: DDNS ..................77 Figure 43 Status: Device Info ................80 Figure 44 Status: Wireless ..................82 Figure 45 Status: Logs ..................

  • Page 14: List Of Tables

    ZyXEL P-336M User’s Guide List of Tables Table 1 Front Panel LEDs ..................19 Table 2 Web Configurator Screen Sub-Menus ............21 Table 3 Web Configurator Screen Icons ............... 22 Table 4 Change Password ..................23 Table 5 Private IP Address Ranges ..............25 Table 6 Basic: WAN: Dynamic IP ................
  • Page 15 ZyXEL P-336M User’s Guide List of Tables...

  • Page 16: Preface

    North American products. Your P-336M is easy to install and configure. About This User's Guide This manual is designed to guide you through the configuration of your P-336M for its various applications. Syntax Conventions • “Enter” means for you to type one or more characters. “Select” or “Choose” means for you to use one predefined choices.

  • Page 17: Related Documentation

    The Quick Start Guide is designed to help you get up and running right away. They contain hardware installation/connection information. • ZyXEL Glossary and Web Site Please refer to www.zyxel.com for an online glossary of networking terms and additional support documentation. User Guide Feedback Help us help you.

  • Page 18: Chapter 1 Getting Started

    Home, SOHO, or SMB network environments. Unlike most routers, the P-336M provides data transfers at up to 108 Mbps (compared to the standard 54 Mbps) when connecting to other compatible MIMO (Multiple Input Multiple Output) devices.

  • Page 19: Hardware Connection And Wizard Setup

    • Equipped with four 10/100 Ethernet ports, one WAN port all with Auto MDI/MDIX. 1.3 Hardware Connection and Wizard Setup Follow the instructions in the Quick Start Guide to connect the P-336M and configure the wizard screens. 1.3.1 Front Panel LEDs The following table describes the front panel LEDs.

  • Page 20: The Web Configurator

    ZyXEL P-336M User’s Guide H A P T E R The Web Configurator This chapter introduces you to the P-336M web configurator, gives an overview of the screen menus and describes the common screen buttons. 2.1 Introduction The web configurator is an HTML-based management interface that allows easy Prestige setup and management via Internet browser.

  • Page 21: The Device Info Screen

    ZyXEL P-336M User’s Guide 5 Click Login to view the first web configurator screen. 2.3 The DEVICE INFO Screen The Device Info screen is the first screen that displays when you access the web configurator. Figure 2 Device Info The following table lists the various web configurator screens within the sub-links.

  • Page 22: Web Configurator Screen Buttons

    1 Click Save Settings on the top of a configuration screen. 2 A Success screen displays. • Click Reboot the Device to restart the P-336M and make the changes take effect. Wait before the P-336M finishes rebooting before accessing the web configurator again.

  • Page 23: Changing Your Password

    ZyXEL P-336M User’s Guide 2.6 Changing Your Password It is highly recommended that you periodically change the password for accessing the Prestige. If you didn’t change the default one after you logged in or you want to change to a new password again, then click Tools >...

  • Page 24: Chapter 3 Basic

    This chapter describes the Basic screens you use to configure the wizards, LAN, WAN and WLAN settings. 3.1 Setup Wizards You can use the wizard screens to configure the P-336M for Internet access and secure wireless connection. Click Basic > Start to display the main Wizard screen.

  • Page 25: Wan Overview

    If your ISP gives you DNS server addresses, manually enter them in the DNS server fields. 2 If your ISP dynamically assigns the DNS server IP addresses (along with the P-336M’s WAN IP address), set the DNS server fields to get the DNS server address from the ISP.

  • Page 26: Wan Configuration

    ZyXEL P-336M User’s Guide 3 You can manually enter the IP addresses of other DNS servers. These servers can be public or private. A DNS server could even be behind a remote IPSec router. 3.2.3 WAN Configuration Select Dynamic IP in the WAN screen if your ISP does not give you a fixed public IP address and Internet access account information (such as the user name and password).

  • Page 27: Wan Configuration: Static Ip

    Use the Default Maximum Transmission Unit (MTU) is a parameter that determines the largest packet size (in bytes) that the P-336M will send to the WAN. If LAN devices send larger packets, the P-336M will break them into smaller packets. Ideally, you should set this to match the MTU of the connection to your ISP.

  • Page 28: Wan Configuration: Pppoe

    3.2.5 WAN Configuration: PPPoE The P-336M supports PPPoE (Point-to-Point Protocol over Ethernet). PPPoE is an IETF Draft standard (RFC 2516) specifying how a computer interacts with a broadband modem (DSL, cable, wireless, etc.) connection. The PPPoE option is for a dial-up connection using PPPoE.

  • Page 29: Figure 8 Basic: Wan: Pppoe

    By implementing PPPoE directly on the P-336M (rather than individual computers), the computers on the LAN do not need PPPoE software installed, since the P-336M does that part of the task. Furthermore, with NAT, all of the LAN computers will have access.

  • Page 30: Lan Setup

    TCP/IP configuration at start-up from a server. You can configure the P-336M as a DHCP server or disable it. When configured as a server, the P-336M provides the TCP/IP configuration for the DHCP client. If DHCP service is disabled, you must have another DHCP server on your LAN, or else the computer must be manually configured.

  • Page 31: Ip Pool Setup

    The P-336M is pre-configured to provide IP addresses (ranging from 192.168.1.100 to 192.168.1.199) to DHCP clients. This configuration leaves some IP addresses (excluding the P-336M itself) in the lower and upper ranges for other server computers, for instance, servers for mail, FTP, TFTP, web, etc., that you may have.

  • Page 32: Table 10 Basic: Dhcp

    DNS information etc.) to an Ethernet device connected to the LAN ports. Clear this check box to stop the P-336M from acting as a DHCP server. you must have another DHCP server on your LAN, or else the computer must be manually configured.

  • Page 33: Wireless Lan Overview

    A radio frequency used by a wireless device is called a channel. 3.5.3 Transmission Rate (Tx Rate) The P-336M provides various transmission (data) rate options for you to select. In most networking scenarios, the factory default Best (Automatic) setting proves the most efficient.

  • Page 34: Figure 11 Basic: Wireless: Basic Wireless Lan Setup

    This field displays whether the wireless LAN feature is enabled (ON) or disabled RADIO STATUS (OFF). You can enable and disable the wireless LAN feature on the P-336M by using the wireless LAN switch at the rear panel of the P-336M. Refer to the Quick Start Guide for more information.

  • Page 35: Wireless Lan Security Overview

    WLAN. • Enter the WEP keys manually. Your P-336M allows you to configure up to four 64-bit or 128-bit WEP keys and only one key is used as the default key at any one time.

  • Page 36: Ieee 802.1X

    ZyXEL P-336M User’s Guide • Open mode is implemented for ease-of-use and when security is not an issue. The wireless station and the AP do not share a secret key. Thus the wireless stations can associate with any AP and listen to any data transmitted plaintext.

  • Page 37: Wlan Security Setup

    ZyXEL P-336M User’s Guide TKIP regularly changes and rotates the encryption keys so that the same encryption key is never used twice. The RADIUS server distributes a Pairwise Master Key (PMK) key to the AP that then sets up a key hierarchy and management system, using the pair-wise key to dynamically generate unique data encryption keys to encrypt every data packet that is wirelessly communicated between the AP and the wireless clients.

  • Page 38: Figure 13 Basic: Wireless: Wlan Security Setup: Wep

    WEP keys automatically. The keys display in the fields below. Key 1 .. 4 The WEP keys are used to encrypt data. Both the P-336M and the wireless stations must use the same WEP key for data transmission. If you want to manually set the WEP keys, enter the key in the field provided.

  • Page 39: Wlan Security Setup: Wpa-Personal

    Select WPA to set the P-336M to use WPA only. WPA is a older implementation than WPA2. Select WPA2 to set the P-336M to use WPA2 first and then WPA if connection fails with WPA2. Select WPA2 Only to set the P-336M to use WPA2 only.

  • Page 40: Figure 15 Basic: Wireless: Wlan Security Setup: Wpa-Enterprise

    Select WPA to set the P-336M to use WPA only. WPA is a older implementation than WPA2. Select WPA2 to set the P-336M to use WPA2 first and then WPA if connection fails with WPA2. Select WPA2 Only to set the P-336M to use WPA2 only.
  • Page 41 ZyXEL P-336M User’s Guide Chapter 3 Basic...

  • Page 42: Chapter 4 Advanced

    These applications do not work through NAT- enabled networks. Your P-336M is a NAT-enabled device. In order to allow these applications to work in your network, you have to configure the P-336M to forward these applications to ports on a computer hosting that service.

  • Page 43: Virtual Server

    Enable Click Enable to activate this feature. Clear this check box to deactivate this feature. Note that some Internet applications may not work in your network behind the P-336M. Name Enter a descriptive name for this setting. Alternatively, select a pre-defined application name from the drop-down list box.

  • Page 44: Common Services And Port Numbers

    ZyXEL P-336M User’s Guide You may enter a single port number or a range of port numbers to be forwarded, and the local IP address of the desired server. The port number identifies a service; for example, web service is on port 80 and FTP on port 21. In some cases, such as for unknown services or where one server can support more than one service (for example both FTP and web service), it might be better to specify a range of port numbers.

  • Page 45: Figure 17 Advanced: Virtual Server

    Enter the inside IP address of the inside server. Protocol Select the protocol type (TCP, UDP or Both). Private Port Enter the port number to which you want the P-336M to translate the public port. Public Port Enter the incoming port number for the selected service. Inbound Filter Select a filter action on the traffic.

  • Page 46: Applications

    This field displays the IP address of the inside server. Protocol This field displays the protocol type. Private Port This field displays the port number to which you want the P-336M to translate the public port. Public Port This field displays the incoming port number.

  • Page 47: Configuring Special Applications

    ZyXEL P-336M User’s Guide a specific port number and protocol ("input" port and protocol), the P-336M forwards the traffic to the LAN IP address of the computer that sent the request. After that computer’s connection for that service closes, another computer on the LAN can use the service in the same manner.
  • Page 48 Name Enter a descriptive name for identification purposes. Alternatively, select a pre-defined application name from the drop-down list box to have the P-336M fill in the default port numbers and protocol type for the selected application. Trigger Port Range The trigger port is a port (or a range of ports) that causes (or triggers) the P- 336M to record the IP address of the LAN computer that sent the traffic to a server on the WAN.

  • Page 49: Streamengine

    ZyXEL P-336M User’s Guide Table 18 Advanced: Applications (continued) LABEL DESCRIPTION Save Click Save to save the changes of a configuration screen for the current session. Clear Click Clear to start configuring a screen again. Special Applications Rule List Enable Select this check box to enable this trigger port setting.

  • Page 50: Figure 19 Advanced: Streamegine

    Select this option to set the P-336M to automatically classify the traffic based on the Classification default Dynamic Select this option to set the P-336M to break up large packets with high priority. This Fragmentation improves transmission quality. Automatic Select this option to set the P-336M to automatically detect and set the optimum Uplink Speed WAN connection speed.
  • Page 51 Select Auto-detect to set the P-336M to automatically detect the Internet connection Type type. Select xDSL or Other Frame Relay Network if the P-336M connects to the Internet via a DSL modem. Select Cable or Other Broadband Network if the P-336M connects to the Internet via a cable modem.

  • Page 52: Routing

    Each remote node specifies only the network to which the gateway is directly connected, and the P-336M has no knowledge of the networks beyond. For instance, the P-336M knows about network N2 in the following figure through remote node Router 1. However, the P-336M is unable to route a packet to network N3 because it doesn't know that there is a route through the same remote node Router 1 (via gateway Router 2).

  • Page 53: Access Control

    Internet access control allows you to create and enforce Internet access policies tailored to your needs. Access control gives you the ability to block specified computers and/or applications from accessing the Internet. You can also set a schedule for when the P-336M performs content filtering.

  • Page 54: Figure 22 Advanced: Access Control

    ZyXEL P-336M User’s Guide Figure 22 Advanced: Access Control The following table describes the labels in this screen. Table 21 Advanced: Access Control LABEL DESCRIPTION Enable Select Enable Access Control to activate this feature. Add Access Set the following fields to configure an access control rule.

  • Page 55: Web Filter

    Apply Web Filter Select this option to apply the web filters you configure in the Web Filter screen. Log Internet Select this option to set the P-336M to create logs for Internet access activity. Access Filter Ports Click this button to display the fields you use to configure port filters.

  • Page 56: Mac Filter

    This field displays the web site address. 4.8 MAC Filter MAC address filtering means sifting traffic going through the P-336M based on the source and/or destination MAC addresses. You can set the P-336M to filter packets from connected wireless clients or computers on the wired LAN.

  • Page 57: Figure 24 Advanced: Mac Filter

    ZyXEL P-336M User’s Guide Figure 24 Advanced: MAC Filter The following table describes the labels in this screen. Table 23 Advanced: MAC Filter LABEL DESCRIPTION Enable Select Enable MAC Address Filter to activate this setting. Clear this check box to disable it.

  • Page 58: Firewall

    Service attacks when activated. The P-336M’s purpose is to allow a private Local Area Network (LAN) to be securely connected to the Internet. The P-336M can be used to prevent theft, destruction and modification of data, as well as log events, which may be important to the security of your network.

  • Page 59: Inbound Filter

    ZyXEL P-336M User’s Guide Figure 25 Advanced: Firewall The following table describes the labels in this screen. Table 24 Advanced: Firewall LABEL DESCRIPTION Enable SPI Select this option to activate Stateful packet inspection. Clear this check box to disable this feature.

  • Page 60: Figure 26 Advanced: Inbound Filter

    ZyXEL P-336M User’s Guide Figure 26 Advanced: Inbound Filter The following table describes the labels in this screen. Table 25 Advanced: Inbound Filter LABEL DESCRIPTION Add Inbound Filter Rule Name Enter a descriptive name (up to 16 characters) for this filter setting. This is for identification purposes only.

  • Page 61: Wireless

    ZyXEL P-336M User’s Guide Table 25 Advanced: Inbound Filter (continued) LABEL DESCRIPTION Action This field displays the action on the packets from the specified IP address range. Source IP Range This field displays the source IP address range(s). 4.11 Wireless This section describes advanced wireless LAN features.

  • Page 62: Fragmentation Threshold

    ZyXEL P-336M User’s Guide Stations can send frames smaller than the specified RTS/CTS directly to the AP without the RTS (Request To Send)/CTS (Clear to Send) handshake. You should only configure RTS/CTS if the possibility of hidden nodes exists on your network and the "cost"...

  • Page 63: Figure 28 Advanced: Wireless

    A wireless AP sets out a beacon to announce its presence and maintain an orderly communication between other wireless devices. Enter the time (between 20 and 1000 ms) the P-336M waits before sending a beacon to the wireless clients. DTIM Interval A DTIM (Delivery Traffic Indication Message) is included in a beacon to synchronize wireless transmission.

  • Page 64: Schedule

    AP(s) that participates in the WDS. 4.12 Schedule You can define schedule settings on the P-336M and apply these schedule settings in other configuration screens (such as Game Hosting and Virtual Server). Click Advanced > Schedule to display the configuration screen.
  • Page 65 ZyXEL P-336M User’s Guide Table 27 Advanced: Schedule (continued) LABEL DESCRIPTION Start Time Set the start of the schedule. End Time Set the end of the schedule. Save Click Save to save the settings in this part of the screen.

  • Page 66: Chapter 5 Tools

    ZyXEL P-336M User’s Guide H A P T E R Tools This chapter describes the Tools screens you use to configure login passwords, system time, logs, DDNS and firmware and configuration settings. 5.1 Administrator Settings You can change the login account passwords, enable UPnP and configure remote access settings in the Admin screen.

  • Page 67: Figure 30 Tools: Admin

    ZyXEL P-336M User’s Guide Figure 30 Tools: Admin The following table describes the labels in this screen. Table 28 Tools: Admin LABEL DESCRIPTION Admin Password Password Type the new password in this field. Verify Password Type the new password again in this field.

  • Page 68: Configuration Backup

    Click Cancel to start configuring this screen again. 5.1.4 Configuration Backup Note: Do not turn off the P-336M while the file transfer process is taking place. Follow the steps below to back up the current configuration of the P-336M. 1 In the web configurator, click Tools > Admin (see Figure 30 on page 67).

  • Page 69: Configuration Restore

    Close to close the screen. Figure 33 Tools: Admin: 5.1.5 Configuration Restore Note: Do not turn off the P-336M while the file transfer process is taking place. Follow the steps below to restore a previously saved configuration file to the P-336M. Chapter 5 Tools...

  • Page 70: System Time And Date

    Figure 34 Tools: Admin: Configuration Restore Progress 5.2 System Time and Date To change your P-336M’s time and date, click Tools > Time. Use this screen to configure the P-336M’s system time based on your local time zone. Chapter 5 Tools...

  • Page 71: Figure 35 Tools: Time

    ZyXEL P-336M User’s Guide Figure 35 Tools: Time The following table describes the labels in this screen. Table 29 Tools: Time LABEL DESCRIPTION Time Adjustment Time Zone Choose the time zone of your location. This will set the time difference between your time zone and Greenwich Mean Time (GMT).

  • Page 72: Syslog

    GMT or UTC (GMT+1). Automatic Time Setting Enable NTP Select this option to have the P-336M get the time and date from the Network Server Time Protocol (NTP) time server you specified below. NTP Server Used Enter the IP address (in dotted decimal notation) of the time server or select one from the pre-defined list.

  • Page 73: E-Mail

    Enter the IP address (in dotted decimal notation) of the syslog server to which the Address P-336M is to send logs. Alternatively, select a computer from the drop-down list box. 5.4 E-mail Click Tools > E-mail configure where the P-336M is to send logs and alerts. Chapter 5 Tools...

  • Page 74: Figure 37 Tools: E-Mail

    ZyXEL P-336M User’s Guide Figure 37 Tools: E-mail The following table describes the labels in this screen. Table 31 Tools: E-mail LABEL DESCRIPTION Enable Select Enable Email Notification to activate this feature. Email Settings From Email Enter an e-mail as the sender.

  • Page 75: System

    Select this option to send logs at the time defined in the selected schedule. 5.5 System Use the System screen to reboot or reset your P-336M. Click Tools > System to display the screen as shown. Figure 38 Tools: System 5.5.1 Rebooting Your P-336M...

  • Page 76: Firmware

    3 In the Uplaod field, enter the new firmware file name or click Browse to locate it. 4 Click Upload to start the file transfer process. Note: Do not turn off the P-336M while the file transfer process is taking place. 5 Wait for the P-336M finishes rebooting before accessing the web configurator again.

  • Page 77: Ddns

    ZyXEL P-336M User’s Guide 5.7 DDNS Dynamic DNS (DDNS) allows you to update your current dynamic IP address with one or many dynamic DNS services so that anyone can contact you (in NetMeeting, CU-SeeMe, etc.). You can also access your FTP server or Web site on your own computer using a domain name (for instance myhost.dhs.org, where myhost is a name of your choice) that will never...
  • Page 78 Enter the password associated with the user name above. You can use up to 31 alphanumeric characters (and the underscore). Spaces are not allowed. Verify Password or Enter the password again for confirmation. Timeout Specify the time (in hours) the P-336M waits before time out. Chapter 5 Tools...
  • Page 79 ZyXEL P-336M User’s Guide Chapter 5 Tools...

  • Page 80: Chapter 6 Status

    ZyXEL P-336M User’s Guide H A P T E R Status This chapter describes the Status screens you use to view the system status and logs. 6.1 Device Info Display the Device Status screen to view device information such as the system time and interface settings.

  • Page 81: Table 33 Tools: Admin

    Click DHCP Release to release the current IP address. You must then click DHCP Renew to get a new IP address. Connect This button is available when the P-336M is set to use PPPoE connection type. Click Connect to establish an Internet connection using PPPoE. Disconnect This button is available when the P-336M is set to use PPPoE connection type.

  • Page 82: Wireless

    ZyXEL P-336M User’s Guide 6.2 Wireless To view a list of wireless clients currently connected to the P-336M, click Status > Wireless. Figure 44 Status: Wireless The following table describes the fields in this screen. Table 34 Association List LABEL...

  • Page 83: Statistics

    ZyXEL P-336M User’s Guide Figure 45 Status: Logs The following table describes the labels in this screen. Table 35 Status: Logs LABEL DESCRIPTION Log Options What to View Select the type of logs to display in this screen. View Levels Select the log severity level to display in this screen.

  • Page 84: Figure 46 Status: Statistics

    ZyXEL P-336M User’s Guide Figure 46 Status: Statistics The following table describes the labels in this screen. Table 36 Status: Statistics LABEL DESCRIPTION LAN Statistics Sent This field displays the number of packets sent on the LAN. Tx Packets This field displays the number of transmitted packets that were dropped on the Dropped LAN.
  • Page 85 ZyXEL P-336M User’s Guide Table 36 Status: Statistics (continued) LABEL DESCRIPTION Received This field displays the number of packets received on the WLAN. Errors This field displays the number of packets received with errors on the WLAN. Chapter 6 Status...

  • Page 86: Types Of Eap Authentication

    ZyXEL P-336M User’s Guide Appendix A Types of EAP Authentication This appendix discusses some popular authentication types: EAP-MD5, EAP-TLS, EAP- TTLS, PEAP and LEAP. The type of authentication you use depends on the RADIUS server or the AP (consult your network administrator for more information).

  • Page 87: Table 37 Comparison Of Eap Authentication Types

    ZyXEL P-336M User’s Guide PEAP (Protected EAP) Like EAP-TTLS, server-side certificate authentication is used to establish a secure connection, then use simple username and password methods through the secured connection to authenticate the clients, thus hiding client identity. However, PEAP only supports EAP methods, such as EAP-MD5, EAP-MSCHAPv2 and EAP-GTC (EAP-Generic Token Card), for client authentication.
  • Page 88 ZyXEL P-336M User’s Guide User Authentication WPA applies IEEE 802.1x and Extensible Authentication Protocol (EAP) to authenticate wireless stations using an external RADIUS database. Encryption WPA improves data encryption by using Temporal Key Integrity Protocol (TKIP) or Advanced Encryption Standard (AES), Message Integrity Check (MIC) and IEEE 802.1x.

  • Page 89: Table 38 Wireless Security Relational Matrix

    ZyXEL P-336M User’s Guide Security Parameters Summary Refer to this table to see what other security parameters you should configure for each Authentication Method/ key management protocol type. MAC address filters are not dependent on how you configure these security features.

  • Page 90: Appendix B

    After the appropriate TCP/IP components are installed, configure the TCP/IP settings in order to "communicate" with your network. If you manually assign IP information instead of using dynamic assignment, make sure that your computers have IP addresses that place them in the same subnet as the P-336M’s LAN port. Windows 95/98/Me...

  • Page 91: Figure 47 Windows 95/98/Me: Network: Configuration

    ZyXEL P-336M User’s Guide Figure 47 WIndows 95/98/Me: Network: Configuration Installing Components The Network window Configuration tab displays a list of installed components. You need a network adapter, the TCP/IP protocol and Client for Microsoft Networks. If you need the adapter: 1 In the Network window, click Add.

  • Page 92: Figure 48 Windows 95/98/Me: Tcp/Ip Properties: Ip Address

    ZyXEL P-336M User’s Guide 3 Select Microsoft from the list of manufacturers. 4 Select Client for Microsoft Networks from the list of network clients and then click 5 Restart your computer so the changes you made take effect. Configuring 1 In the Network window Configuration tab, select your network adapter's TCP/IP entry and click Properties 2 Click the IP Address tab.

  • Page 93: Figure 49 Windows 95/98/Me: Tcp/Ip Properties: Dns Configuration

    5 Click OK to save and close the TCP/IP Properties window. 6 Click OK to close the Network window. Insert the Windows CD if prompted. 7 Turn on your P-336M and restart your computer when prompted. Verifying Settings 1 Click Start and then Run.

  • Page 94: Figure 50 Windows Xp: Start Menu

    ZyXEL P-336M User’s Guide Figure 50 Windows XP: Start Menu 2 For Windows XP, click Network Connections. For Windows 2000/NT, click Network and Dial-up Connections. Figure 51 Windows XP: Control Panel 3 Right-click Local Area Connection and then click Properties.

  • Page 95: Figure 52 Windows Xp: Control Panel: Network Connections: Properties

    ZyXEL P-336M User’s Guide Figure 52 Windows XP: Control Panel: Network Connections: Properties 4 Select Internet Protocol (TCP/IP) (under the General tab in Win XP) and click Properties. Figure 53 Windows XP: Local Area Connection Properties 5 The Internet Protocol TCP/IP Properties window opens (the General tab in Windows XP).

  • Page 96: Figure 54 Windows Xp: Advanced Tcp/Ip Settings

    ZyXEL P-336M User’s Guide • If you have a static IP address click Use the following IP Address and fill in the IP address, Subnet mask, and Default gateway fields. Click Advanced. Figure 54 Windows XP: Advanced TCP/IP Settings 6 If you do not know your gateway's IP address, remove any previously installed gateways in the IP Settings tab and click OK.

  • Page 97: Figure 55 Windows Xp: Internet Protocol (Tcp/Ip) Properties

    8 Click OK to close the Internet Protocol (TCP/IP) Properties window. 9 Click OK to close the Local Area Connection Properties window. 10Turn on your P-336M and restart your computer (if prompted). Verifying Settings 1 Click Start, All Programs, Accessories and then Command Prompt.

  • Page 98: Figure 56 Macintosh Os 8/9: Apple Menu

    ZyXEL P-336M User’s Guide Figure 56 Macintosh OS 8/9: Apple Menu 2 Select Ethernet built-in from the Connect via list. Figure 57 Macintosh OS 8/9: TCP/IP 3 For dynamically assigned settings, select Using DHCP Server from the Configure: list. Appendix B...

  • Page 99: Figure 58 Macintosh Os X: Apple Menu

    • Type your subnet mask in the Subnet mask box. • Type the IP address of your P-336M in the Router address box. 5 Close the TCP/IP Control Panel. 6 Click Save if prompted, to save changes to your configuration.

  • Page 100: Figure 59 Macintosh Os X: Network

    Type your subnet mask in the Subnet mask box. • Type the IP address of your P-336M in the Router address box. 5 Click Apply Now and close the window. 6 Turn on your P-336M and restart your computer (if prompted).
  • Page 101 ZyXEL P-336M User’s Guide Appendix B...

  • Page 102: Index

    ZyXEL P-336M User’s Guide Index about your ZyXEL G-220F Address Assignment Finger Finland, Contact Information Application Layer Gateway Fragmentation Threshold authentication Fragmentation threshold authentication method France, Contact Information open system 31, 44, 77 shared key Germany, Contact Information getting started...
  • Page 103 ZyXEL P-336M User’s Guide NNTP Subnet Mask North America Contact Information support CD Norway, Contact Information Support E-mail Sweden, Contact Information syntax conventions Pairwise Master Key (PMK) passphrase password phrase Telephone Point-to-Point Tunneling Protocol Temporal Key Integrity Protocol (TKIP) POP3...
