  • Page 1 AI-POWERED GROW SYSTEM COMPLETE INDOOR PLANT KIT...
  • Page 3 PROUD TO PRESENT TO YOU THE AI-POWERED GROW SYSTEM Thank you for choosing AC Infinity. As growers, we’ve dreamt of applying commercial levels of automation technology to our systems, scaled down for home growing, without the commercial level price tag. Now we’ve made it possible.
  • Page 4 819137022850 AI-Powered Grow System (4x4) AC-PKB44 819137022867 AI-Powered Grow System PRO (4x4) AC-PKC44 819137024335 AI-Powered Grow System PRO (5x5) AC-PKB55 819137024038 AC INFINITY x ATHENA*, AI-Powered Grow System (2x4) AC-PKN24 819137024366 *Athena is a registered trademark of Athena Ag, Inc.
  • Page 5 MANUAL INDEX Page 5 Manual Index ....................Page 7 Product Warning ................... Page 8 Product Contents ..................Page 10 Quick Build Guide ..................Page 12 CLOUDLAB: Advance Grow Tent ............... Page 13 Product Contents ................... Page 15 Tent Setup ..................... Page 20 Controller Plate Setup ................
  • Page 6 MANUAL INDEX Page 68 CLOUDRAY: Oscillation Fan System ............Page 69 Product Contents ................... Page 70 Installation ..................... Page 72 Powering and Setup ................Page 73 Cleaning ....................Page 75 Programming ..................CONTROLLER +: UIS Controller Page 78 ............Product Contents ...................
  • Page 7 PRODUCT WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Read all instructions before installing and using this product. Ensure your power source conforms to the electrical requirements of this product. Check your local code restrictions for additional safety measures that may be needed for a proper code compliant installation.
  • Page 8 PRUNING SNIPS DUCTING TAPE CABLE TIES BOX H BOX I BOX I BOX I BOX I BOX I AC INFINITY x ATHENA , AI-Powered Grow System † INSTANT POTTING ATHENA MIX KIT, 5 gal. NUTRIENTS BOX H (Athena models ONLY) *IONFRAME EVO8 shown †...
  • Page 9 PRODUCT CONTENTS DETAILS AI-Powered AC INFINITY x ATHENA*, AI-Powered Grow AI-Powered Grow AI-Powered Grow AI-Powered Grow AI-Powered Grow AI-Powered Grow Grow System AI-Powered Grow System (2x2) System (2x4) System (3x3) System (4x4) System PRO (4x4) System PRO (5x5) COMPACT (2x2)
  • Page 10 QUICK BUILD GUIDE Build the Grow Tent Install the Inline Fan with Straps (BOX (BOX A). Refer to the C), Ducting and Clamps (BOX G) to CLOUDLAB section. your preferred configuration. Refer to the CLOUDLINE section. You may connect and Hang the Grow Light using Clamp the Clip Fan hang the Carbon Filter...
  • Page 11 Level 10 in ON Mode, and 6:00 pm to 12:00 pm in Schedule Mode. Port 3 (and 4 if applicable) – Set your Oscillating Fan to Level 5 in ON Mode. Download the AC Infinity app to access recipes for each grow stage and more automations.
  • Page 12 CLOUDLAB SERIES ADVANCE GROW TENT...
  • Page 13 ADVANCE GROW TENT PRODUCT CONTENTS AI-Powered AC INFINITY x ATHENA, AI-Powered AI-Powered AI-Powered Grow AI-Powered Grow AI-Powered Grow AI-Powered Grow Grow System AI-Powered Grow Grow System Grow System System (2x2) System (2x4) System (3x3) System (4x4) COMPACT (2x2) System (2x4)
  • Page 14 CLOUDLAB PRODUCT CONTENTS CLOUDLAB SERIES Included only with CLOUDLAB 422 AC-CBA422 CLOUDLAB 722 AC-CBA722 FRAME POLES CLOUDLAB SERIES Included only with CLOUDLAB 642 AC-CBA642 FRAME POLES CLOUDLAB SERIES Included only with CLOUDLAB 733 AC-CBA733 CLOUDLAB 844 AC-CBA844 CLOUDLAB 866 AC-CBA866 FRAME POLES NOTE: Pole lengths may vary between all models.
  • Page 15 CLOUDLAB TENT SETUP STEP 1 Insert the eight (A) poles* and into the floor end of the corner (D1) pieces to create two bases. When assembling, make sure the feet of A / A1 each corner (D1) piece faces the floor with the arrow facing down.
  • Page 16 CLOUDLAB TENT SETUP STEP 3 Door Unzip the tent so that three of the walls lay flat. Roof Floor STEP 4 Guide Base One into the floor of the tent, making sure its corners meet the tent’s corners. Base One Floor...
  • Page 17 CLOUDLAB TENT SETUP STEP 5 Base Two Insert the poles of Base Two into the poles of Base One to complete the frame. Base One Two people are recommended for this portion of the tent assembly. STEP 6 Pull the roof over the assembled frame. Two people are recommended for this portion of the tent assembly.
  • Page 18 CLOUDLAB TENT SETUP STEP 7 Pull the upper and lower zippers to close the walls and door. *CLOUDLAB 733 / 844 / 866 are built with additional side doors. STEP 8 You can neatly hold the window wall open any time by using its attached hook and loop strap.
  • Page 19 CLOUDLAB TENT SETUP STEP 9 Add the roof support beams (E) then (F). Insert the spill pool into the tent and secure the hook and loop straps around the poles. CLOUDLAB 422, 722 CLOUDLAB 733 CLOUDLAB 844, 866 CLOUDLAB 642 *CLOUDLAB 733 / 844 / 866 are built with additional side doors.
  • Page 20 CLOUDLAB CONTROLLER PLATE SETUP STEP 1 Magnetically mount the controller onto the bracket. Refer to the CONTROLLER AI+ Mounting section for additional controller mounting methods. STEP 2 Slide the controller bracket assembly into the tent straps. CLOUDLAB 866 will include a lower third strap for an alternate mounting location.
  • Page 21 CLOUDLAB CONTROLLER PLATE SETUP STEP 3 Route your devices’ power connectors through the opening inside and plug it into your controller. Plug the probe into the controller and route its cables through the opening.
  • Page 22 MOUNTING GUIDE CONTROLLER PLATE This grow tent includes a steel plate with a mounting slot for AC Infinity controllers. Mount your controller to the corresponding areas on the plate’s slot. Route its wires through the oval opening and through the grow tent’s flap. Some controller models may contain a hidden magnet on the backside, which can stick onto this plate without screws.
  • Page 23 CLOUDLAB VENTILATION GUIDE INLINE FAN AND GROW LIGHT First hang your inline duct fan to be used as an exhaust fan by the roof support beams. Position the intake fan at the bottom end so the intake air will be passive through the bottom vents. If you are installing a carbon filter inside, use the included straps to hang the carbon filter.
  • Page 24 CLOUDLAB CONFIGURATION SETUP LIGHT AND VENTILATION PLACEMENT There are many ways to configure these components to bring airflow into your grow space. A typical setup places the fan and the filter inside, which makes it easier to manage while dampening the fan noise. Both can be situated in any order within the ventilation chain if air is being pulled out of your grow space.
  • Page 26 CLOUDLINE MIXED FLOW INLINE FAN SYSTEMS CLOUDLINE A4 shown...
  • Page 27 CLOUDLINE PRODUCT CONTENTS AI-Powered AC INFINITY x ATHENA, AI-Powered AI-Powered AI-Powered Grow AI-Powered Grow AI-Powered Grow AI-Powered Grow Grow System AI-Powered Grow Grow System Grow System System (2x2) System (2x4) System (3x3) System (4x4) COMPACT (2x2) System (2x4) PRO (4x4)
  • Page 28 CLOUDLINE MOUNTING STEP 1 Unscrew the bolts on both sides from the plastic rings using a Phillips screwdriver. Pliers are also required for removing the metal rings of the CLOUDLINE PRO T6. STEP 2 Remove the motor box from the flange bracket.
  • Page 29 CLOUDLINE MOUNTING STEP 3 Use the flange bracket to set your desired fan position. Mark the four mounting holes. STEP 4 Drill four holes into the marked locations. Make sure your mounting area is structurally sound and free from obstruction.
  • Page 30 CLOUDLINE MOUNTING STEP 5 If you are mounting onto anything other than a wood support or stud, insert the included four wall anchors into the drilled mounting holes. You may need to use a hammer to secure them through the holes. STEP 6 Align the flange bracket’s holes with the wall anchors.
  • Page 31 CLOUDLINE MOUNTING STEP 7 Place the wind circle back into the intake flange. Reposition the metal clamps over the flanges for the CLOUDLINE PRO T6. STEP 8 Slide the motor box back into the flange bracket, making sure its airflow arrow is pointing in the same direction as the flange bracket’s arrow.
  • Page 32 CLOUDLINE MOUNTING STEP 9 If installing ducting, use the included duct clamps to secure it to either end of the duct fan, making sure there is a tight seal. Tighten the duct clamps using a flathead screwdriver. POWERING AND SETUP Plug the fan’s power cord into an AC power outlet to power it and the controller.
  • Page 33 CLOUDLINE OVERHEAD HANGING STEP 1 Loop the strap around the bracket and a pole. STEP 2 Slip the strap through the inner ladder lock slot from the bottom.
  • Page 34 CLOUDLINE OVERHEAD HANGING STEP 3 Route the strap into the outer ladder lock slot from the top. Adjust the length of the completed loop as needed. STEP 4 Tuck the loose end through the center gap of the ladder lock to secure the loop.
  • Page 35 CLOUDLINE OVERHEAD HANGING STEP 5(a) - Hanging Downward Let the fan hang by the pole once the straps are secure. Make sure the fan's airflow arrow is pointing towards your desired direction. STEP 5(b) - Hanging Upward To hang the fan right-side up, loop and tighten the straps, as shown in steps 1-4, around the pole.
  • Page 36 CLOUDLINE MOTOR CAP STEP 1 Unscrew the motor cap using a screwdriver. STEP 2 Rotate the motor cap to your desired orientation. Reapply the screws. Rotating the motor cap will not void your warranty.
  • Page 37 CLOUDLINE CONFIGURATION SETUP INTAKE AND EXHAUST This fan can be used as either an intake fan or an exhaust fan in grow rooms and larger grow tents. To achieve optimal whole space ventilation, the intake fan or opening —if not using a fan— must be situated at a bottom corner of your grow space.
  • Page 38 CLOUDLINE CLEANING STEP 1 Remove the motor box from the mounting flange. Refer to the CLOUDLINE Mounting section to learn how to remove the motor box. STEP 2 Use a damp cloth to clear the impeller and fan blades of any dust and debris. Remove the wind circle in between the motor box and input flange.
  • Page 39 CLOUDLINE CLEANING STEP 3 Clear the stator blades of any dust and debris on the opposite end. Clean the area inside the output and exhaust flanges. STEP 4 Secure the motor box onto the mounting flanges. Refer to the CLOUDLINE Mounting section to learn how to secure the motor box.
  • Page 40 DUCT CARBON FILTER PREMIUM AUSTRALIAN CHARCOAL Inline Carbon Filter shown...
  • Page 41 CARBON FILTER PRODUCT CONTENTS AI-Powered AC INFINITY x ATHENA, AI-Powered AI-Powered AI-Powered Grow AI-Powered Grow AI-Powered Grow AI-Powered Grow Grow System AI-Powered Grow Grow System Grow System System (2x2) System (2x4) System (3x3) System (4x4) COMPACT (2x2) System (2x4) PRO (4x4)
  • Page 42 CARBON FILTER INSTALLATION STEP 1 Connect your duct tube over your filter. Use duct clamps to secure the connection. You may also apply ducting tape before using the duct clamps for even further security. STEP 2 You may also connect your filter directly to your inline duct fan.
  • Page 43 CARBON FILTER OVERHEAD HANGING (STRAPS) STEP 1 Loop the strap around a hanging pole. STEP 2 Slip the strap through the inner ladder lock slot from the bottom.
  • Page 44 CARBON FILTER OVERHEAD HANGING (STRAPS) STEP 3 Route the strap into the outer ladder lock slot from the top. Adjust the length of the completed loop as needed. STEP 4 Tuck the loose ends through the center gap of the ladder lock to secure the loop.
  • Page 45 CARBON FILTER OVERHEAD HANGING (STRAPS) STEP 5 Connect your filter to your ductwork using your preferred method, as shown on the Carbon Filter Installation page.
  • Page 46 CARBON FILTER OVERHEAD HANGING (ROPE CLIPS) STEP 1 Loop the rope clip hangers around your grow tent’s support beams. STEP 2 Hook the carabiners into the steel hooks located on the flanges.
  • Page 47 CARBON FILTER CONFIGURATION SETUP PREFILTER When placing your filter inside your grow space, slip the cloth over your filter to block dust and other particles from passing through. Make sure the entire metal mesh is covered by the cloth. INTERIOR HANGING To use this filter in intake applications, place the filter inside your grow space.
  • Page 48 CARBON FILTER CONFIGURATION SETUP EXTERIOR MOUNTING To use this filter in exhaust applications, place the filter outside of your grow space. Make sure your filter is connected to your inline duct fan's exhaust end before completing the installation. Stuff the prefilter inside of the filter to lengthen the carbon bed's lifespan.
  • Page 49 CARBON FILTER CONFIGURATION SETUP OVERSIZED GROW SPACE Use a dual fan and filter combination inside your grow space to completely scrub away odor in larger grow rooms and tents. Set the secondary filter on the floor and the inline fan on top of it so that the exhaust end points up.
  • Page 50 CARBON FILTER MAINTENANCE WASHING THE PREFILTER Wash the reusable cloth as needed to clear it of any dust and build-up. This will further extend the lifespan of the filter. REVERSING THE FLANGES — STANDARD To extend the filter's lifespan and utilize its entire carbon bed, rotate the flanges from either end.
  • Page 51 CARBON FILTER REPLACING THE CARBON — PRO MODELS ONLY STEP 1 Rotate the port flange from your filter, then remove the rubber stopper from the interior. STEP 2 Dispose of the used carbon. Used carbon can be composted. STEP 3 Place and direct the funnel into one of the openings and scoop the carbon refill (sold separately) into your filter.
  • Page 52 CARBON FILTER REPLACING THE CARBON — PRO MODELS ONLY STEP 4 Set the rubber stopper into place, making sure to align the nodes with the corresponding holes. STEP 5 Twist the flange back onto your filter.
  • Page 53 CARBON FILTER CARBON REFILL GUIDE — PRO MODELS ONLY RECOMMENDED REPLACEMENT The chart below outlines the approximate number of refills each capacity can provide for your carbon filter. How often you replace the activated carbon will depend on your use. We recommend keeping its carbon bed in place until you begin to smell odors.
  • Page 54 IONBOARD / IONFRAME EVO GROW LIGHT SYSTEM IONBOARD S22 shown...
  • Page 55 GROW LIGHT SYSTEM PRODUCT CONTENTS: IONBOARD AI-Powered AI-Powered Grow AI-Powered Grow AI-Powered Grow AI-Powered Grow Grow System System (2x2) System (2x4) System (3x3) System (4x4) COMPACT (2x2) AC-PKB22 AC-PKB24 AC-PKB33 AC-PKB44 AC-PKA22 IONBOARD S22, IONBOARD S22, IONBOARD S24, IONBOARD S33, IONBOARD S44, 2x2 Coverage 2x2 Coverage...
  • Page 56 GROW LIGHT SYSTEM PRODUCT CONTENTS: IONFRAME EVO AC INFINITY x ATHENA, AI-Powered Grow AI-Powered Grow AI-Powered Grow System PRO (4x4) System PRO (5x5) System (2x4) AC-PKC44 AC-PKB55 AC-PKN24 IONFRAME EVO3, IONFRAME EVO6, IONFRAME EVO8, 2x4 Coverage 4x4 Coverage 5x5 Coverage...
  • Page 57 GROW LIGHT SYSTEM INSTALLATION: IONBOARD STEP 1 — STEEL HOOKS Insert the steel hooks into your grow light’s slotted holes of the end caps. STEP 2 — STEEL HOOKS Position your grow tent’s pole under the steel hooks. Install the pole onto your grow tent’s frame.
  • Page 58 GROW LIGHT SYSTEM INSTALLATION: IONBOARD STEP 1 — ROPE CLIP HANGERS Insert the steel hooks into your grow light’s slotted holes of the end caps. STEP 2 — ROPE CLIP HANGERS Loop the rope clip hangers around your grow tent’s support beams. Hook the carabiners into the steel hooks.
  • Page 59 GROW LIGHT SYSTEM DRIVER MOUNTING (FRAME): IONFRAME EVO STEP 1 Align the brackets’ mounting holes with the driver’s mounting points located on the driver’s underside, making sure the brackets’ legs are pointing up. Secure the brackets by screwing in the round head driver screws using a Phillips screwdriver.
  • Page 60 GROW LIGHT SYSTEM DRIVER MOUNTING (WALL): IONFRAME EVO STEP 1 Align the brackets’ mounting holes with the driver’s mounting points located on the driver’s underside, making sure the brackets’ legs are pointing down. Secure the brackets by screwing in the flat head driver screws using a Phillips screwdriver.
  • Page 61 GROW LIGHT SYSTEM DRIVER MOUNTING (WALL): IONFRAME EVO STEP 4 If you are mounting onto anything other than a wood support or stud, insert the included four wall anchors into the drilled mounting holes. You may need to use a hammer to secure them through the holes.
  • Page 62 GROW LIGHT SYSTEM HANGING: IONFRAME EVO STEP 1 Clip the lanyard hooks onto the four anchors located at the corners of your grow light. STEP 2 Clip the two carabiners onto your grow tent's roof support beams. You may also use rope clip hangers to hang your grow light lower.
  • Page 63 GROW LIGHT SYSTEM POWERING AND SETUP: IONBOARD STEP 1 Plug the power cord into an AC power outlet to power your grow light. STEP 2 You may use the included UIS M-M extension cord to connect an external controller for smart programming. Plug the UIS connector with the gasket end into the LED driver, and the other end into your chosen controller.
  • Page 64 GROW LIGHT SYSTEM POWERING AND SETUP: IONFRAME EVO STEP 1 Plug the power cord into an AC power outlet to power your grow light. STEP 2 You may use the included UIS M-M extension cord to connect an external controller for smart programming. Plug the UIS connector with the gasket end into the LED driver, and the other end into your chosen controller.
  • Page 65 GROW LIGHT SYSTEM STARTER GUIDE The charts below offer suggested mounting heights and light intensities for each stage in the growing process of your preferred method. These factors will vary based on the plant you are growing. In dynamic placement, “height” refers to distance from the canopy (tip of the plant). STATIC Seedling Vegetative...
  • Page 66 GROW LIGHT SYSTEM PROGRAMMING: IONBOARD OFF/ON MODE Turning the knob to UIS switches the grow light off, or passes control over to your smart controller if one is connected. INTENSITY LEVEL Turning the knob from UIS will establish a set light intensity level in 20% increments, up to 100%.
  • Page 68 CLOUDRAY OSCILLATING FAN SYSTEM...
  • Page 69 CLOUDRAY PRODUCT CONTENTS AI-Powered AC INFINITY x ATHENA, AI-Powered AI-Powered AI-Powered Grow AI-Powered Grow AI-Powered Grow AI-Powered Grow Grow System AI-Powered Grow Grow System Grow System System (2x2) System (2x4) System (3x3) System (4x4) COMPACT (2x2) System (2x4) PRO (4x4)
  • Page 70 CLOUDRAY INSTALLATION STEP 1 Twist to remove the knob piece from the grip clip. STEP 2 Slide the grip clip into the swivel as shown. You may need to pull its clamps apart for it to fit over the swivel. This tightness ensures your fan will not tilt downwards on its own.
  • Page 71 CLOUDRAY INSTALLATION STEP 3 Replace the knob of the mounting point as desired. STEP 4 Loosen the grip to fit around your grow tent pole. STEP 5 Tighten the grip to fit securely around your tent pole.
  • Page 72 CLOUDRAY POWERING AND SETUP STEP 1 Plug the fan’s power cord into an AC power outlet to power the fan. Plug the fan into the closest AC outlet to allow for cable slack and avoid cable tension. STEP 2 Plug the UIS connector with the gasket end into your clip fan.
  • Page 73 CLOUDRAY CLEANING STEP 1 Unplug your clip fan. STEP 2 Unscrew the bottom of the front grille using a screwdriver. Removing the front grille to clean the fan blades will not void your warranty.
  • Page 74 CLOUDRAY CLEANING STEP 3 Twist the grille counter-clockwise and pull to remove it. STEP 4 Wipe off any dust and debris from the grille and fan blades using a damp cloth. Set aside to dry as needed. STEP 5 Realign the grille over your clip fan, twist clockwise, then screw the grille back on to lock it in place.
  • Page 75 CLOUDRAY PROGRAMMING POWERING ON/OFF Press the speed button to turn your clip fan ON. Cycling past Dynamic Wind Mode will turn your clip fan OFF. Speed Button FAN SPEED ADJUSTING The speed button cycles through OFF, fan speeds 1-10, indicated by the row of white LED lights.
  • Page 76 CLOUDRAY PROGRAMMING DYNAMIC WIND MODE This mode will alternate speeds between levels 1-10 to simulate a natural breeze. STEP 1 Set the fan speed to your desired maximum level using the speed button. We do not recommend setting your max speed level to level 1;...
  • Page 77 CLOUDRAY PROGRAMMING OSCILLATION In addition to the standard features, your fan can oscillate to provide airflow at a wide angle. The oscillation function is manually activated using the oscillation button and cannot be controlled using external UIS programming. If set to OFF, your clip fan will not oscillate regardless of any external programs.
  • Page 78 CONTROLLER AI-POWERED ENVIRONMENTAL CONTROLLER...
  • Page 79 CONTROLLER PRODUCT CONTENTS AI-Powered AC INFINITY x ATHENA, AI-Powered AI-Powered AI-Powered Grow AI-Powered Grow AI-Powered Grow AI-Powered Grow Grow System AI-Powered Grow Grow System Grow System System (2x2) System (2x4) System (3x3) System (4x4) COMPACT (2x2) System (2x4) PRO (4x4)
  • Page 80 CONTROLLER POWERING AND SETUP STEP 1 Plug the sensor probe into the controller’s sensor port. Set the probe near your plants in your grow tent for the most accurate reading. STEP 2 Plug your the power adapter’s UIS connector into the controller’s power port. Plug the two- prong connector to an AC power outlet to power the controller.
  • Page 81 CONTROLLER POWERING AND SETUP STEP 3 Use the included UIS M-M extension cord to connect your device’s UIS connector into one of the controller’s ports. Plug the device’s power cord into an AC power outlet to power it. Plug the UIS connector with the gasket end into your grow device and the other end into your controller.
  • Page 82 CONTROLLER MOUNTING STEP 1 — WALL MOUNTING Locate a spot free of obstruction and secure the anchors into your wall. Twist the wood screws into the anchors. STEP 2 — WALL MOUNTING Hang the controller by the screws using the holes on the backside.
  • Page 83 CONTROLLER MOUNTING MAGNET MOUNTING You may also mount the controller onto a steel surface using the magnet located behind the label. Set your controller outside your grow tent so the onboard sensor can gather external climate readings. PLATE MOUNTING Screw the bolts into the slot or mounting holes at the upper half of the plate.
  • Page 84 By creating this fully integrated system, you can power and program all your devices together or separately for optimized grow tent management. Your grow system can be regulated using your controller hub or remotely on the AC Infinity app (paired with compatible controllers), where you will have access to automation programming and climate data.
  • Page 85 The expansion dongle will allow you to connect 4 devices with a single port and can support additional splitters to create up to three tiers of expansion ports. Intended for exclusive use with AC Infinity controllers built with UIS ports. UIS M - M...
  • Page 86 CONTROLLER ADDING MORE DEVICES The CONTROLLER AI+ is built with eight ports that enable you to power and control multiple devices at the same time (select products not included). See image below for a sample configuration. EXTENDING THE CHAIN Plug the male end of the splitter* into your UIS controller.
  • Page 87 CONTROLLER ADDING MORE DEVICES DAISY-CHAINING Each of the included controller’s ports can support up to 20 devices using a daisy-chain adapter (not included). All devices must be from the same series but can be of differing sizes. Plug the male end of the daisy-chain adapter into your device. Connect your UIS controller to the daisy-chain adapter’s INPUT port using a M-M connector cord.
  • Page 88 CONTROLLER PROGRAMMING CONTROLLER For in-depth programming instructions, refer to the included CONTROLLER AI+ Quick Start Guide. The following resources are also available for further assistance. WEBPAGE OVERVIEW Read through this instruction guide to easily explore all that your controller has to offer.
  • Page 89 Store by searching “AC Infinity”. pair your controller with the app. QUICK TIP FOR EASY ACCESS Open the smart phone camera and scan the QR code below to download the AC Infinity app. Please visit our website at www.acinfinity.com for more information on the AC Infinity app.
  • Page 90 CONTROLLER ADD A DEVICE: BLUETOOTH SETUP AND PAIRING Power your device on before pairing your controller with the app. Logging in or creating an account beforehand will expedite the pairing process. Have your Wi-Fi network’s name and password ready. Tap on the “+” tab to Tap on the “Smart Controllers”...
  • Page 91 CONTROLLER ADD A DEVICE: BLUETOOTH Select CONTROLLER AI+. Hold the port button for 5 seconds to activate Bluetooth. Wait for the Bluetooth icon to start flashing on your controller’s screen.
  • Page 92 CONTROLLER ADD A DEVICE: BLUETOOTH Connect using Bluetooth. To Connecting with Bluetooth will connect using Wi-Fi, skip to step 8. disable Wi-Fi functionality. Go to the app settings page to re- enable and connect using Wi-Fi. When pairing the app around multiple controllers, move your mobile device closer to your desired controller.
  • Page 93 CONTROLLER ADD A DEVICE: BLUETOOTH Tap the DONE button to complete the pairing process.
  • Page 94 CONTROLLER ADD A DEVICE: WI-FI Repeat steps 1-5. Log in or create Enter your Wi-Fi network’s an account to continue. password. You may also connect to an alternate 2.4 GHz router*. When pairing the app around multiple controllers, move your mobile device closer to your desired controller.
  • Page 95 CONTROLLER ADD A DEVICE: WI-FI Follow these tips if the pairing Tap the DONE button to complete process is unsuccessful. the pairing process. DONE *This controller is only compatible with 2.4 GHz frequency band routers. When connecting using Wi-Fi, make sure your mobile device is not connected to a 5 GHz frequency band network.
  • Page 96 CONTROLLER ADD A DEVICE: WI-FI Your controller will appear in your smart device with a unique ID. I-I000I...
  • Page 97 What devices are compatible with the CONTROLLER AI+? All AC Infinity devices that contain a UIS connector are compatible. If your AC Infinity device has a 4-pin Molex connector and an EC-Motor, it may still be compatible with the use of an UIS adapter to convert its connector to fit with the controller.
  • Page 98 CONTROLLER FREQUENTLY ASKED QUESTIONS Does the controller retain its settings after power is shut off? Yes. If the controller's power is cut off and is powered on afterward, your settings will remain. My controller isn't pairing with the app. How do I fix this? If the pairing process isn’t successful, press any button to return to the normal screen.
  • Page 99 Commercial grow lights sold by AC Infinity receive a five year warranty period. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues.
  • Page 100 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
