  • Page 1 PROPAGATION SYSTEM HUMIDITY CONTROLLED ENVIRONMENT USER MANUAL...
  • Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com and click contact for our contact information. EMAIL LOCATION support@acinfinity.com...
  • Page 4 MANUAL CODE HD2305X1 PRODUCT MODEL UPC-A Humidity Dome, Medium Heavy-Duty AC-HDA5 819137023208 Heated Humidity Dome, Medium Heavy-Duty AC-HDM5 819137023420 Propagation Kit, Medium Heavy-Duty AC-HDL5 819137023215 Propagation System, Medium Heavy-Duty AC-HMX5 819137023413 Humidity Dome, Large 1020 AC-HDA7 819137023864 Propagation Kit, Large 1020...

  • Page 5: Table Of Contents

    Page 15 Controller Mounting ............... Page 16 Starter Guide ................. Page 20 Platform ................Page 26 Cleaning ..................Page 27 Programming ................. Page 29 Other Settings ................Page 35 Other AC Infinity Products ............. Page 36 Warranty ..................Page 37...

  • Page 6: Product Warning

    PRODUCT WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Ensure your power source conforms to the electrical requirements of this product. Read all instructions before installing and using this product. Be careful not to damage or cut the wire insulation (covering) during the installation. Do not permit wires to come in contact with any sharp edges.

  • Page 7: Key Features

    KEY FEATURES MEDIUM HEAVY-DUTY SERIES LOCKED-IN HUMIDITY SAMSUNG LED LIGHTING* DIGITAL CONTROLLER* Dual built-in rotating vents Two light bars with commercial- Smart controls feature provide precise control to grade Samsung LM301H EVO SCHEDULE and SUNSET/ lock in moisture or lower diodes deliver full-spectrum RISE modes to activate ten internal humidity levels.
  • Page 8 KEY FEATURES LARGE 1020 SERIES LOCKED-IN HUMIDITY SAMSUNG LED LIGHTING* DIGITAL CONTROLLER* Dual built-in rotating vents Two light bars with commercial- Smart controls feature provide precise control to grade Samsung LM301H EVO SCHEDULE and SUNSET/ lock in moisture or lower diodes deliver full-spectrum RISE modes to activate ten internal humidity levels.

  • Page 9: Product Contents

    PRODUCT CONTENTS HUMIDITY DOME HEAVY-DUTY MODELS ONLY HUMIDITY BASE SEEDLING VENT VENTED SIDE BOLT AND DOME TRAY TRAY DISKS PANEL PANEL WING NUTS (x1) (x1) (x1) (x4) (x2) (x2) (x8) IONBEAM LED LIGHT BARS (AC-HDL5V2, AC-HMX5V2, AC-HDL7V2, AC-HMX7V2) LIGHT BAR LIGHT BAR EC POWER SCHEDULE...

  • Page 10: Installation: Suncore Seedling Mat

    INSTALLATION SUNCORE SEEDLING MAT STEP 1 Unroll the seedling mat flat on to the ground. Do not allow the mat to overlap onto itself. STEP 2 Connect the AC power plug to a power outlet to turn on the seedling mat. Included in AC-HDM5, AC-HMX5V2, and AC-HMX7V2 models.

  • Page 11: Installation: Humidity Dome

    INSTALLATION HUMIDITY DOME STEP 1 Place the seedling tray into the base tray. For Large 1020 Series humidity domes, proceed to step 3. STEP 2 Assemble the dome extender*, keeping the vented panels on opposite ends and applying the plastic screw and nuts to secure the corners. *Not included in Large 1020 models.
  • Page 12 INSTALLATION HUMIDITY DOME STEP 3 Snap the vent disks into the side openings. Adjust the vents as needed. STEP 4 Place the dome over the tray. You may also place the dome extender* in between the tray and dome as an option. *Not included in Large 1020 models.

  • Page 13: Installation: Ionbeam Led Light Bars

    INSTALLATION IONBEAM LED LIGHT BARS STEP 1 Assemble the light bar chain. Connect the single-corded LED light bar's female port to the dual-corded LED light bar's male connector. Connect the power adapter's male connector to the other end of the dual- corded LED light bar.
  • Page 14 INSTALLATION IONBEAM LED LIGHT BARS STEP 2 Place the LED light bars on top of the dome. Its diodes should fit snugly into the divots of the dome.

  • Page 15: Powering And Setup

    POWERING AND SETUP IONBEAM LED LIGHT BARS STEP 1 Use the included UIS M-M extension cord to connect the fan's EC Motor box to one of the controller's ports. STEP 2 Plug the power adapter into a wall outlet.

  • Page 16: Controller Mounting

    CONTROLLER MOUNTING SUNCORE SEEDLING MAT STEP 1 Use the dial controller to set your desired position. Mark the two mounting holes. STEP 2 Drill two holes into the marked locations. Make sure your mounting area is structurally sound and free from obstruction.
  • Page 17 CONTROLLER MOUNTING SUNCORE SEEDLING MAT STEP 3 Align the controller mounting holes with the markings. Using a screwdriver or drill, secure the controller to the marked locations with the included wood screws or machine screws with nuts.
  • Page 18 CONTROLLER MOUNTING IONBEAM LED LIGHT BARS STEP 1 — WALL MOUNTING Locate a spot free of obstruction and secure the anchor into your wall. Twist the wood screw into the anchors. STEP 2 — WALL MOUNTING Hang the controller by the screw using the holes on the backside.
  • Page 19 CONTROLLER MOUNTING IONBEAM LED LIGHT BARS MAGNET MOUNTING The controller will magnetically mount onto the CLOUDLAB series advance grow tent's controller mounting plate* or any steel surface. The magnet is located under the controller's label. PLATE MOUNTING* Screw the controller plate bolts into the slot or mounting holes at the upper half of the plate.

  • Page 20: Starter Guide

    STARTER GUIDE HUMIDITY DOME AND SEEDLING MAT GROWING SEASONS You may use a seedling mat to get a head start on the gardening season. Start the germination process during late winter or spring if you live in a colder region. GERMINATION Different seeds require different temperatures to germinate.
  • Page 21 STARTER GUIDE HUMIDITY DOME AND SEEDLING MAT HUMIDITY Closing the vents of the humidity dome will increase the humidity of the environment. To accelerate the environmental humidity build-up, pair the humidity dome with a seedling mat. SOWING SEEDS Sow 2-3 seeds per cell; not every seed will germinate.
  • Page 22 STARTER GUIDE HUMIDITY DOME AND SEEDLING MAT WATERING Water your seed tray’s starter mix or pellets, which will appear dark brown. Dry off any excess water. Place the humidity dome on the seed tray and close all air vents. Lightly water your seeds whenever the mix/pellets appear light brown.
  • Page 23 STARTER GUIDE FULL SPECTRUM LIGHTING The chart below offers suggested mounting heights and light intensities for each stage in the growing process. These factors will vary based on the plant you are growing. Height refers to the minimum recommended distance from the canopy (tip of the plant) to the light. GROW Height Intensity...
  • Page 24 STARTER GUIDE FULL SPECTRUM LIGHTING GROW Height Intensity Set Up STAGE Level 6 Vegetative 6 IN. Stage 60% Brightness Level 10 Flowering 6 IN. Stage 100% Brightness...
  • Page 25 STARTER GUIDE FULL SPECTRUM LIGHTING SETTING ACTIVE LIGHTING TIMERS The included controller can set daily schedules ranging from 1 minute to 24 hours. Set a lighting schedule of 1-12 hours to extend your plant’s daily exposure to light, in conjunction with natural sunlight, or when growing plants that don’t require extended exposure.

  • Page 26: Uis Tm Platform

    By creating this fully integrated system, you can power and program all your devices together or separately for optimized grow tent management. Your grow system can be regulated using your controller hub or remotely on the AC Infinity app (paired with compatible controllers), where you will have access to automation programming and climate data.

  • Page 27: Cleaning

    CLEANING STEP 1 Dip or soak a cloth with your preferred solvent. STEP 2 Separate each section and wipe each item to clear them of any debris.
  • Page 28 CLEANING STEP 3 Using a dry cloth, pat or wipe each item and set them aside upside-down to dry.

  • Page 29: Programming

    PROGRAMMING HEATING CONTROLLER LIGHT INDICATOR When the controller is turned on and receiving power, the LED at the top of the controller will light up to show it is on. Turn the knob clockwise until you hear and feel a click to turn on the seedling mat. Turn the knob counterclockwise from ON until you hear and feel a click to turn off the seedling mat.
  • Page 30 PROGRAMMING SCHEDULE CONTROLLER 1. MODE BUTTON 2. UP/DOWN BUTTON 3. CURRENT TIME Cycles through each of the Adjusts the setting of Displays the current controller modes: OFF, ON, your current mode. time. The internal battery SCHEDULE, SUNSET/RISE, and sustains the clock so it CLOCK.
  • Page 31 PROGRAMMING SCHEDULE CONTROLLER CONTROLLER MODES Pressing the mode button will cycle through the controller’s available programming modes and settings: OFF, ON, SCHEDULE, SUNSET/RISE, and CLOCK. OFF MODE Your grow light will not activate while in this mode. The intensity level set here establishes the minimum intensity level in the SCHEDULE mode.
  • Page 32 PROGRAMMING SCHEDULE CONTROLLER SCHEDULE MODE (ON & OFF) Sets an on clock-time and an off clock-time schedule for your grow light to follow daily. Press the up or down button to first set up an on clock-time to turn your grow light on, then press the mode button to set an off clock-time to turn your grow light off.
  • Page 33 PROGRAMMING SCHEDULE CONTROLLER SUNSET/RISE SETTING Sets a sunrise and sunset time for your grow light to brighten and dim, respectively. This setting only applies to SCHEDULE mode. Press the up or down button to set a duration between 0:00 – 6:00 hours for your grow light to brighten and dim.
  • Page 34 PROGRAMMING SCHEDULE CONTROLLER CLOCK MODE Adjusts the current clock time. Use the up and down buttons to adjust the time. Once you cycle through 12:00 each time, the units will automatically change to AM or PM. The clock time is located at the center of the display and the upper right hand corner.

  • Page 35: Other Settings

    OTHER SETTINGS SCHEDULE CONTROLLER FACTORY RESET Holding the mode and up/down buttons together for 5 seconds HOLD + will reset your controller and restore factory settings. This will clear all user set parameters of each controller mode and setting. RESET TO OFF/DEFAULT Holding the up and down buttons together for 2 seconds will HOLD + reset the value of your current mode to its default setting.

  • Page 36: Other Ac Infinity Products

    150 lb. weight capacity. Includes a mounting plate to install your AC Infinity controller onto. Fabric Pots A set of gardening grow bags designed to create wider root networks and improve plant growth by air pruning roots while draining excess water.

  • Page 37: Warranty

    WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues.
  • Page 38 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
  • Page 40 www.acinfinity.com...
