Summary of Contents for AC Infinity AC-HCA22
- Page 1 MOUNTING BARS GROW TENT ACCESSORY BARS USER MANUAL USER MANUAL...
- Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com and click contact for our contact information. EMAIL LOCATION support@acinfinity.com...
- Page 4 MANUAL CODE HCA2211X1 PRODUCT MODEL UPC-A Grow Tent Mounting Bars (2x2) AC-HCA22 819137023550 Grow Tent Mounting Bars (2x4) AC-HCA24 819137023567 Grow Tent Mounting Bars (3x3) AC-HCA33 819137023574 Grow Tent Mounting Bars (4x4) AC-HCA44 819137023581 Grow Tent Mounting Bars (5x5) AC-HCA55...
-
Page 5: Table Of Contents
Product Warning ................Page 6 Key Features ................. Page 7 Product Contents ................Page 8 Installation ..................Page 9 Tent Setup ..................Page 12 Weight Restrictions ................ Page 13 Other AC Infinity Products ............. Page 14 Warranty ..................Page 15... -
Page 6: Product Warning
PRODUCT WARNING TO REDUCE THE RISK OF INJURY TO PERSONS OR DAMAGE TO PRODUCTS, OBSERVE THE FOLLOWING: Read all instructions before installing and using this product. If you are unfamiliar or have doubts about performing this product’s installation, seek the services of a qualified, trained, and licensed professional. -
Page 7: Key Features
KEY FEATURES HEAVY DUTY CFM* INCREASE VERSATILE Made of thick, resilient steel Retains your grow tent's shape Capable of many arrays to that can support the weight to maximize interior space for create support systems for of equipment like clip-on more plants and equipment by inter-canopy side lighting, fans and LED side lighting. -
Page 8: Product Contents
PRODUCT CONTENTS AC-HC22 AC-HCA24 AC-HC33 AC-HCA44 AC-HCA55 LENGTH 2 FT 2 FT 4 FT 3 FT 4 FT 5 FT QUANTITY ALL MODELS HOOK AND THIN ADHESIVE THICK ADHESIVE LOOP STRAP SILICONE PAD SILICONE PAD (x8) (x8) (x8) SUPPORT CLAMP SUPPORT CLAMP MACHINE SCREW at least... -
Page 9: Installation
INSTALLATION STEP 1 Remove your grow tent* walls before installing the mounting bars. *Sold separately STEP 2 Place the adhesive silicone pads at the ends of each mounting bar, matching the correct size pads on both sides so that the bar fits snug on the grow tent poles. - Page 10 INSTALLATION STEP 3 Route the hook-and-loop straps through the bar opening located at its ends, making sure the buckle is outside and the padded side is inside. This strap can loop around up to two bar openings. STEP 4 Wrap the hook-and-loop strap around the grow tent pole and route it through its buckle.
- Page 11 INSTALLATION STEP 5 Select the support clamp size that best matches your grow tent bar for greater reinforcement. Apply smaller clamps for poles at least 16mm and larger clamps for poles at least 22mm. Open the support clamp around the bar. Tighten and secure the clamp with the nut and screw so that its flat side is parallel to your grow tent's walls.
-
Page 12: Tent Setup
TENT SETUP STANDARD ORIENTATION The standard orientation will prevent your grow tent from bowing. This configuration can also be used as a support system that allows elastic trellis nets to hook onto the side bars. SUPPORT ORIENTATION The support orientation will provide general use support throughout your grow tent. -
Page 13: Weight Restrictions
WEIGHT RESTRICTIONS SINGLE BAR A single mounting bar can hold up to 2 lbs when installed onto a CLOUDLAB grow tent.* SINGLE BAR AND SUPPORT CLAMP A single mounting bar with a support clamp can hold up to 4 lbs when installed onto a CLOUDLAB grow tent. -
Page 14: Other Ac Infinity Products
AC INFINITY PRODUCTS Circulator Clip Fans The CLOUDRAY series is a line of clip fans designed to provide precise air circulation for all stages of a plant’s growth cycle. Features digital controls to achieve ten speed levels, as well as a heavy-duty clamp constructed to tightly grip onto grow tent poles of all sizes. -
Page 15: Warranty
WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues. - Page 16 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
- Page 20 www.acinfinity.com...
