AC Infinity IONBEAM S11 User Manual

AC Infinity IONBEAM S11 User Manual

Grow light bar system
Hide thumbs Also See for IONBEAM S11:
Table of Contents

Advertisement

Quick Links

IONBEAM
GROW LIGHT BAR SYSTEM
USER MANUAL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IONBEAM S11 and is the answer not in the manual?

Questions and answers

Related Manuals for AC Infinity IONBEAM S11

Summary of Contents for AC Infinity IONBEAM S11

  • Page 1 IONBEAM GROW LIGHT BAR SYSTEM USER MANUAL...
  • Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com and click contact for our contact information. EMAIL LOCATION support@acinfinity.com...
  • Page 4 MANUAL CODE NE2211X1 PRODUCT MODEL UPC-A IONBEAM S11 AC-NES11 819137023352 IONBEAM S16 AC-NES16 819137023369 IONBEAM U2 AC-NEU11-2 819137024090 IONBEAM U4 AC-NEU11-4 819137024106...

  • Page 5: Manual Index

    ........... Page 17 Starter Guide: UV Lighting ............. Page 19 Platform ................Page 21 Connecting to UIS ..............Page 22 Programming ................. Page 23 Other Settings ................Page 27 Other AC Infinity Products ............. Page 28 Warranty ..................Page 29...

  • Page 6: Product Warning

    PRODUCT WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Ensure your power source conforms to the electrical requirements of this product. Read all instructions before installing and using this product. Be careful not to damage or cut the wire insulation (covering) during the installation. Do not permit wires to come in contact with any sharp edges.

  • Page 7: Key Features

    KEY FEATURES HUMIDITY-RESISTANT EASY INSTALLATION LED LIGHTING Unibody design constructed Magnetic ends on the LED Full or targeted spectrum to IP65 standards to protect light bars allow for quick and LED light bars deliver optimal against liquids and dust with toolless mounting on any steel coverage for enhanced light a tightly formed seal.

  • Page 8: Product Contents

    PRODUCT CONTENTS IONBEAM U2 (AC-NEU11-2) LIGHT BAR LIGHT BAR MOUNTING SCHEDULE EC POWER (SINGLE-CORDED) (DUAL-CORDED) CONTROLLER ADAPTER (x1) (x1) (x2) (x1) (x1) BAR EXTENSION UIS EXTENSION WOOD SCREWS CONTROLLER HOOK AND LOOP WIRE CORD (M-F) CORD (M-M) (WALL MOUNT) PLATE BOLTS NUTS CABLE TIES MOUNT...

  • Page 9: Installation

    INSTALLATION LIGHT BAR CHAIN ASSEMBLY STEP 1 Connect the single-corded LED light bar's female port to the dual-corded LED light bar's male connector. STEP 2 Connect the EC power adapter's male connector to the other end of the dual-corded LED light bar. STEP 3 Connect the power adapter to the schedule controller.

  • Page 10: Pole Mounting

    INSTALLATION LIGHT BAR MOUNTING POLE MOUNTING You may magnetically mount the light bar(s) directly on your grow tent steel pole. You may also use the included hook and loop cable ties around the light bar(s) and mounting bar to adjust the lighting angle and for extra security.

  • Page 11: Step 1 - Wall Mounting

    INSTALLATION LIGHT BAR MOUNTING STEP 1 — WALL MOUNTING Make sure your mounting area is free from obstruction. Use a mounting bar to mark your drilling holes with the logo facing the wall. STEP 2 — WALL MOUNTING Drill holes into the marked locations.
  • Page 12 INSTALLATION LIGHT BAR MOUNTING STEP 3 — WALL MOUNTING If you are mounting onto anything other than a wood support or stud, insert the included four wall anchors into the drilled mounting holes. You may need to use a hammer to secure them through the holes.
  • Page 13 INSTALLATION LIGHT BAR MOUNTING STEP 5 — WALL MOUNTING Set the light bar(s) magnet ends onto the mounting bar(s).
  • Page 14 POWERING AND SETUP STEP 1 Use the included UIS M-M extension cord to connect the fan's EC Motor box to one of the controller's ports. STEP 2 Plug the power adapter into a wall outlet.

  • Page 15: Controller Mounting

    CONTROLLER MOUNTING STEP 1 — WALL MOUNTING Locate a spot free of obstruction and secure the anchor into your wall. Twist the wood screw into the anchors. STEP 2 — WALL MOUNTING Hang the controller by the screw using the holes on the backside.

  • Page 16: Magnet Mounting

    CONTROLLER MOUNTING MAGNET MOUNTING The controller will magnetically mount onto the CLOUDLAB series advance grow tent's controller mounting plate or any steel surface. The magnet is located under the controller's label. PLATE MOUNTING* Screw the controller plate bolts into the slot or mounting holes at the upper half of the plate.
  • Page 17 STARTER GUIDE FULL SPECTRUM LIGHTING The chart below offers suggested mounting heights and light intensities for each stage in the growing process. These factors will vary based on the plant you are growing. Height refers to the minimum recommended distance from the canopy (tip of the plant) to the light. GROW Height Intensity...
  • Page 18 STARTER GUIDE FULL SPECTRUM LIGHTING GROW Height Intensity Set Up STAGE Level 6 Vegetative 6 IN. Stage Level 10 Flowering 6 IN. Stage...
  • Page 19 STARTER GUIDE UV LIGHTING Use of UV lighting is recommended only in the flowering stage to enhance fruit and flower development. This lighting can be left on for a few hours a day or the entire daily light cycle. These factors will vary based on the plant you are growing. Height refers to the minimum recommended distance from the canopy (tip of the plant) to the light.
  • Page 20 STARTER GUIDE UV LIGHTING COVERAGE Height Intensity Models 4' x 4' Level 10 IONBEAM U4 1 FT. (AC-NEU11-4) 5' x 5' Level 10 IONBEAM U4 1 FT. (AC-NEU11-4)
  • Page 21 By creating this fully integrated system, you can power and program all your devices together or separately for optimized grow tent management. Your grow system can be regulated using your controller hub or remotely on the AC Infinity app (paired with compatible controllers), where you will have access to automation programming and climate data.
  • Page 22 CONNECTING TO UIS IONBEAM LED grow lights can connect with select smart controllers as part of an integrated system using the included UIS extension cord. CONNECTING TO UIS CONTROLLERS Use the included UIS M-M extension cord to connect the EC power adapter to your selected UIS controller.

  • Page 23: Controller Mode

    PROGRAMMING 1. MODE BUTTON 2. UP/DOWN BUTTON 3. CURRENT TIME Cycles through each of the Adjusts the setting of Displays the current controller modes: OFF, ON, your current mode. time. The internal SCHEDULE, and CLOCK. battery sustains the Holding this button will lock the clock so it does not controller;...

  • Page 24: Controller Modes

    PROGRAMMING CONTROLLER MODES Pressing the mode button will cycle through the controller’s available programming modes and settings: OFF, ON, SCHEDULE, and CLOCK. OFF MODE Your grow light will not activate while in this mode. The intensity level set here establishes the minimum intensity level in the SCHEDULE mode.
  • Page 25 PROGRAMMING SCHEDULE MODE (ON & OFF) Sets an on clock-time and an off clock-time schedule for your grow light to follow daily. Press the up or down button to first set up an on clock-time to trigger ON mode, then press the mode button to set an off clock-time to trigger OFF mode.

  • Page 26: Clock Mode

    PROGRAMMING CLOCK MODE Adjusts the current clock time. Use the up and down buttons to adjust the time. Once you cycle through 12:00 each time, the units will automatically change to AM or PM. The clock time is located at the center of the display and the upper right hand corner.

  • Page 27: Other Settings

    OTHER SETTINGS FACTORY RESET Holding the mode and up/down buttons together for 5 seconds HOLD + will reset your controller and restore factory settings. This will clear all user set parameters of each controller mode and setting. RESET TO OFF/DEFAULT Holding the up and down buttons together for 2 seconds will HOLD + reset the value of your current mode to its default setting.
  • Page 28 150 lb. weight capacity. Includes a mounting plate to install your AC Infinity controller onto. Humidity Dome The humidity dome is designed to maintain moisture levels to create the ideal environment for seed germination.

  • Page 29: Warranty

    WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues.
  • Page 30 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
  • Page 32 www.acinfinity.com...
