Page 1 ADVANCE GROW SYSTEM COMPLETE INDOOR PLANT KIT USER MANUAL...
Page 3 PROUD TO PRESENT TO YOU THE ADVANCE GROW SYSTEM Thank you for choosing AC Infinity. As growers, we’ve dreamt of applying commercial levels of automation technology to our systems, scaled down for home growing, without the commercial level price tag. Now we’ve made it possible.
Page 4 MANUAL CODE PK2210X1 PRODUCT MODEL Advance Grow Tent Kit (2x2) COMPACT AC-PKA22 819137022829 Advance Grow Tent Kit (2x2) AC-PKB22 819137022836 Advance Grow Tent Kit (2x4) AC-PKB24 819137022843 Advance Grow Tent Kit (3x3) AC-PKB33 819137022850 Advance Grow Tent Kit (4x4) AC-PKB44...
Page 5: Table Of Contents
MANUAL INDEX Page 5 Manual Index ....................Page 7 Product Warning ................... Page 8 Product Contents ..................Page 10 Quick Build Guide ..................CLOUDLAB: Advance Grow Tent ............... Page 12 Product Contents ................... Page 13 Tent Setup ..................... Page 15 Page 20 Controller Plate Setup ................
Page 6 MANUAL INDEX Page 68 CLOUDRAY: Oscillation Fan System ............Page 69 Product Contents ................... Page 70 Recommended Usage ................Page 71 Installation ..................... Page 74 Cleaning ....................Page 76 Programming ..................CONTROLLER 69 PRO: UIS Controller ............ Page 78 Product Contents ...................
Page 7: Product Warning
PRODUCT WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Ensure your power source conforms to the electrical requirements of this product. Check your local code restrictions for additional safety measures that may be needed for a proper code compliant installation.
Page 8: Product Contents
PRODUCT CONTENTS OVERVIEW CLOUDLAB CONTROLLER 69 PRO CLOUDLINE Advance Grow Tent UIS Controller Inline Fan BOX A BOX B BOX C (NOT included in AC-PKB55) CLOUDLINE PRO IONBOARD IONFRAME EVO Inline Fan LED Grow Light LED Grow Light BOX C BOX D BOX D (ONLY included in AC-PKB55)
Page 9 PRODUCT CONTENTS DETAILS Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Tent Kit (2x2) Tent Kit (2x2) Tent Kit (2x4) Tent Kit (3x3) Tent Kit (4x4) Tent Kit (5x5) COMPACT AC-PKB22 AC-PKB24 AC-PKB33 AC-PKB44 AC-PKB55 AC-PKA22 CLOUDLAB 422, CLOUDLAB 722, CLOUDLAB 642,...
Page 10: Quick Build Guide
QUICK BUILD GUIDE Build the Grow Tent (BOX A). Install the Inline Fan with Straps (BOX C), Ducting and Clamps (BOX G) to your Refer to pages 12-25. preferred configuration. Refer to pages 26-39. You may connect and hang Hang the Grow Light Clamp the Clip Fan the Carbon Filter with Straps using Rope Hangers...
Page 11 QUICK BUILD GUIDE Mount the Grow Tent Controller (BOX B) onto the Controller Plate (BOX A). Refer to page 20. Plug the probe into the probe port. Plug the Inline Fan’s controller cable (BOX C) into Port 1, the Grow Light’s controller cable (BOX D) into Port 2, and the Clip Fan’s controller cable (BOX E) into Port 3.
Page 12: Cloudlab: Advance Grow Tent
CLOUDLAB SERIES ADVANCE GROW TENT...
Page 13: Product Contents
ADVANCE GROW TENT PRODUCT CONTENTS Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Tent Kit (2x2) Tent Kit (2x2) Tent Kit (2x4) Tent Kit (3x3) Tent Kit (4x4) Tent Kit (5x5) COMPACT AC-PKB22 AC-PKB24 AC-PKB33 AC-PKB44 AC-PKB55 AC-PKA22 CLOUDLAB 422,...
Page 14 CLOUDLAB PRODUCT CONTENTS CLOUDLAB SERIES Included only with CLOUDLAB 422 AC-CBA422 CLOUDLAB 722 AC-CBA722 FRAME POLES CLOUDLAB SERIES Included only with CLOUDLAB 642 AC-CBA642 FRAME POLES CLOUDLAB SERIES Included only with CLOUDLAB 733 AC-CBA733 CLOUDLAB 844 AC-CBA844 CLOUDLAB 866 AC-CBA866 FRAME POLES NOTE: Pole lengths may vary between all models.
Page 15: Tent Setup
CLOUDLAB TENT SETUP STEP 1 Insert the eight (A) poles* and into the floor end of the corner (D1) pieces to create two bases. When assembling, make sure the feet of A / A1 each corner (D1) piece faces the floor with the arrow facing down.
Page 16 CLOUDLAB TENT SETUP STEP 3 Door Unzip the tent so that three of the walls lay flat. Roof Floor STEP 4 Guide Base One into the floor of the tent, making sure its corners meet the tent’s corners. Base One Floor...
Page 17 CLOUDLAB TENT SETUP STEP 5 Insert the poles of Base Two into the poles of Base One to complete the frame. Base Two Base One Two people are recommended for this portion of the tent assembly. STEP 6 Pull the roof over the assembled frame. Two people are recommended for this portion of the tent assembly.
Page 18 CLOUDLAB TENT SETUP STEP 7 Pull the upper and lower zippers to close the walls and door. *CLOUDLAB 733 / 844 / 866 are built with additional side doors. STEP 8 You can neatly hold the window wall open any time by using its attached hook and loop strap.
Page 19 CLOUDLAB TENT SETUP STEP 9 Add the roof support beams (E) then (F). Insert the spill pool into the tent and secure the hook and loop straps around the poles. CLOUDLAB 422 / 722 CLOUDLAB 733 CLOUDLAB 844 / 866 CLOUDLAB 642 *CLOUDLAB 733 / 844 / 866 are built with additional side doors.
Page 20: Controller Plate Setup
CLOUDLAB CONTROLLER PLATE SETUP STEP 1 Magnetically mount the controller onto the bracket. Refer to pages 82-83 for additional controller mounting methods. STEP 2 Slide the controller bracket assembly into the tent straps. CLOUDLAB 866 will include a lower third strap for an alternate mounting location.
Page 21 CLOUDLAB CONTROLLER PLATE SETUP STEP 3 Route your inline duct fan’s power connector through the opening inside and plug it into your controller. Plug the probe into the controller and route its cables through the opening.
Page 22: Mounting Guide
MOUNTING GUIDE CONTROLLER PLATE This grow tent includes a steel plate with a mounting slot for AC Infinity controllers. Mount your controller to the corresponding areas on the plate’s slot. Route its wires through the oval opening and through the grow tent’s flap. Some controller models may contain a hidden magnet on the backside, which can stick onto this plate without screws.
Page 23: Ventilation Guide
CLOUDLAB VENTILATION GUIDE INLINE FAN AND GROW LIGHT First hang your inline duct fan to be used as an exhaust fan by the roof support beams. Position the intake fan at the bottom end so the intake air will be passive through the bottom vents. If you are installing a carbon filter inside, use the included straps to hang the carbon filter.
Page 24: Configuration Setup
CLOUDLAB CONFIGURATION SETUP LIGHT AND VENTILATION PLACEMENT There are many ways to configure these components to bring airflow into your grow space. A typical setup places the fan and the filter inside, which makes it easier to manage while dampening the fan noise. Both can be situated in any order within the ventilation chain if air is being pulled out of your grow space.
Page 26: Cloudline: Mixed Flow Inline Fan System
CLOUDLINE MIXED FLOW INLINE FAN SYSTEMS CLOUDLINE A4 shown...
Page 27: Product Contents
CLOUDLINE PRODUCT CONTENTS Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Tent Kit (2x2) Tent Kit (2x2) Tent Kit (2x4) Tent Kit (3x3) Tent Kit (4x4) Tent Kit (5x5) COMPACT AC-PKB22 AC-PKB24 AC-PKB33 AC-PKB44 AC-PKB55 AC-PKA22 CLOUDLINE A4 CLOUDLINE A4 CLOUDLINE A6...
Page 28: Mounting
CLOUDLINE MOUNTING STEP 1 Unscrew the bolts on both sides from the plastic rings using a Phillips screwdriver. Pliers are also required for removing the metal rings of the CLOUDLINE PRO T6. STEP 2 Remove the motor box from the flange bracket.
Page 29 CLOUDLINE MOUNTING STEP 3 Use the flange bracket to set your desired fan position. Mark the four mounting holes. STEP 4 Drill four holes into the marked locations. Make sure your mounting area is structurally sound and free from obstruction.
Page 30 CLOUDLINE MOUNTING STEP 5 If you are mounting onto anything other than a wood support or stud, insert the included four wall anchors into the drilled mounting holes. You may need to use a hammer to secure them through the holes. STEP 6 Align the flange bracket’s holes with the wall anchors.
Page 31 CLOUDLINE MOUNTING STEP 7 Place the wind circle back into the intake flange. Reposition the metal clamps over the flanges for the CLOUDLINE PRO T6. STEP 8 Slide the motor box back into the flange bracket, making sure its airflow arrow is pointing in the same direction as the flange bracket’s arrow.
Page 32 CLOUDLINE MOUNTING STEP 9 If installing ducting, use the included duct clamps to secure it to either end of the duct fan, making sure there is a tight seal. Tighten the duct clamps using a flathead screwdriver. POWERING AND SETUP Plug the fan’s power cord into an AC power outlet to power it and the controller.
Page 33: Overhead Hanging
CLOUDLINE OVERHEAD HANGING STEP 1 Loop the strap around the bracket and a pole. STEP 2 Slip the strap through the inner ladder lock slot from the bottom.
Page 34 CLOUDLINE OVERHEAD HANGING STEP 3 Route the strap into the outer ladder lock slot from the top. Adjust the length of the completed loop as needed. STEP 4 Tuck the loose end through the center gap of the ladder lock to secure the loop.
Page 35 CLOUDLINE OVERHEAD HANGING STEP 5(a) - Hanging Downward Let the fan hang by the pole once the straps are secure. Make sure the fan's airflow arrow is pointing towards your desired direction. STEP 5(b) - Hanging Upward To hang the fan right-side up, loop and tighten the straps, as shown in steps 1-4, around the pole.
Page 36: Motor Cap
CLOUDLINE MOTOR CAP STEP 1 Unscrew the motor cap using a screwdriver. STEP 2 Rotate the motor cap to your desired orientation. Reapply the screws. Rotating the motor cap will not void your warranty.
Page 37: Configuration Setup
CLOUDLINE CONFIGURATION SETUP INTAKE AND EXHAUST This fan can be used as either an intake fan or an exhaust fan in grow rooms and larger grow tents. To achieve optimal whole space ventilation, the intake fan or opening —if not using a fan— must be situated at a bottom corner of your grow space.
Page 38: Cleaning
CLOUDLINE CLEANING STEP 1 Remove the motor box from the mounting flange. Refer to steps 1-2 on page 28 to learn how to remove the motor box. STEP 2 Use a damp cloth to clear the impeller and fan blades of any dust and debris. Remove the wind circle in between the motor box and input flange.
Page 39 CLOUDLINE CLEANING STEP 3 Clear the stator blades of any dust and debris on the opposite end. Clean the area inside the output and exhaust flanges. STEP 4 Secure the motor box onto the mounting flanges. Refer to steps 7-9 on pages 31-32 to learn how to secure the motor box.
Page 40: Duct Carbon Filter Premium Australian Charcoal
DUCT CARBON FILTER PREMIUM AUSTRALIAN CHARCOAL...
Page 41: Product Contents
CARBON FILTER PRODUCT CONTENTS Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Tent Kit (2x2) Tent Kit (2x2) Tent Kit (2x4) Tent Kit (3x3) Tent Kit (4x4) Tent Kit (5x5) COMPACT AC-PKB22 AC-PKB24 AC-PKB33 AC-PKB44 AC-PKB55 AC-PKA22 Inline Carbon Inline Carbon...
Page 42: Installation
CARBON FILTER INSTALLATION STEP 1 Connect your duct tube over your filter. Use duct clamps to secure the connection. You may also apply ducting tape before using the duct clamps for even further security. STEP 2 You may also connect your filter directly to your inline duct fan.
Page 43: Overhead Hanging
CARBON FILTER OVERHEAD HANGING (STRAPS) STEP 1 Loop the strap around a hanging pole. STEP 2 Slip the strap through the inner ladder lock slot from the bottom.
Page 44 CARBON FILTER OVERHEAD HANGING (STRAPS) STEP 3 Route the strap into the outer ladder lock slot from the top. Adjust the length of the completed loop as needed. STEP 4 Tuck the loose ends through the center gap of the ladder lock to secure the loop.
Page 45 CARBON FILTER OVERHEAD HANGING (STRAPS) STEP 5 Connect your filter to your ductwork using your preferred method, as shown on page 42.
Page 46 CARBON FILTER OVERHEAD HANGING (ROPE CLIPS)* STEP 1 Loop the rope clip hangers around your grow tent’s support beams. STEP 2 Hook the carabiners into the steel hooks located on the flanges. *Sold separately...
Page 47: Configuration Setup
CARBON FILTER CONFIGURATION SETUP PREFILTER When placing your filter inside your grow space, slip the cloth over your filter to block dust and other particles from passing through. Make sure the entire metal mesh is covered by the cloth. INTERIOR HANGING To use this filter in intake applications, place the filter inside your grow space.
Page 48 CARBON FILTER CONFIGURATION SETUP EXTERIOR MOUNTING To use this filter in exhaust applications, place the filter outside of your grow space. Make sure your filter is connected to your inline duct fan's exhaust end before completing the installation. Stuff the prefilter inside of the filter to lengthen the carbon bed's lifespan.
Page 49 CARBON FILTER CONFIGURATION SETUP OVERSIZED GROW SPACE Use a dual fan and filter combination inside your grow space to completely scrub away odor in larger grow rooms and tents. Set the secondary filter on the floor and the inline fan on top of it so that the exhaust end points up.
Page 50: Maintenance
CARBON FILTER MAINTENANCE REVERSING THE FLANGES To extend the filter's lifespan and utilize its entire carbon bed, rotate the flanges from either end. Remove the screws from the flanges to release them from the filter. Replace the flanges on the other ends and screw them back into place.
Page 52: Ionboard / Ionframe Evo: Grow Light System
IONBOARD / IONFRAME EVO GROW LIGHT SYSTEM IONBOARD S22 shown...
Page 53: Product Contents
GROW LIGHT SYSTEM PRODUCT CONTENTS: IONBOARD Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Tent Kit (2x2) Tent Kit (2x2) Tent Kit (2x4) Tent Kit (3x3) Tent Kit (4x4) COMPACT AC-PKB22 AC-PKB24 AC-PKB33 AC-PKB44 AC-PKA22 IONBOARD S22, IONBOARD S22, IONBOARD S24, IONBOARD S33, IONBOARD S44,...
Page 54 GROW LIGHT SYSTEM PRODUCT CONTENTS: IONFRAME EVO Advance Grow Tent Kit (5x5) AC-PKB55 IONFRAME EVO8, 5x5 Coverage LED GROW LIGHT LED DRIVER DRIVER BRACKETS DRIVER EXTENSION CORD STAINLESS STEEL WIRE HANGERS ROPE CLIP HANGERS UIS Male-Male Controller Cord CONTROLLER CORD WIRE TIE WITH 3M BASE NYLON...
Page 55: Installation
GROW LIGHT SYSTEM INSTALLATION: IONBOARD S22 / S24 STEP 1 Hang the steel hooks over your grow tent’s support beams. STEP 2 While supporting your grow light, bend the steel hooks to insert the ends into the slotted holes of the end caps. Repeat this step on the other side of your grow light.
Page 56 GROW LIGHT SYSTEM INSTALLATION: IONBOARD S33 / S44 STEP 1 Insert the steel hooks into your grow light's slotted holes of the end caps. STEP 2 Position your grow tent's pole under the steel hooks. Install the pole onto your grow tent's frame.
Page 57: Driver Mounting: Ionframe Evo
GROW LIGHT SYSTEM DRIVER MOUNTING (FRAME): IONFRAME EVO STEP 1 Align the brackets' mounting holes with the driver's mounting points located on the driver's underside, making sure the brackets' legs are pointing up. Secure the brackets by screwing in the driver screws using a Phillips screwdriver.
Page 58 GROW LIGHT SYSTEM DRIVER MOUNTING (WALL): IONFRAME EVO STEP 1 Align the brackets' mounting holes with the driver's mounting points located on the driver's underside, making sure the brackets' legs are pointing down. Secure the brackets by screwing in the driver screws using a Phillips screwdriver.
Page 59 GROW LIGHT SYSTEM DRIVER MOUNTING (WALL): IONFRAME EVO STEP 4 If you are mounting onto anything other than a wood support or stud, insert the included four wall anchors into the drilled mounting holes. You may need to use a hammer to secure them through the holes.
Page 60: Overhead Hanging
GROW LIGHT SYSTEM HANGING: IONBOARD STEP 1 Insert the steel hooks into your grow light’s slotted holes of the end caps. STEP 2 Loop the rope clip hangers around your grow tent’s support beams. Hook the carabiners into the steel hooks.
Page 61 GROW LIGHT SYSTEM HANGING: IONFRAME EVO STEP 1 Clip the lanyard hooks onto the four anchors located at the corners of your grow light. STEP 2 Clip the two carabiners onto your grow tent's roof support beams. You may also use rope clip hangers to hang your grow light lower.
Page 62 GROW LIGHT SYSTEM POWERING AND SETUP: IONBOARD STEP 1 Plug the power cord into an AC power outlet to power your grow light. STEP 2 You may connect an external controller to set smart programming. Plug one end of the controller cord into the LED driver, and the other end into your chosen controller.
Page 63: Powering And Setup
GROW LIGHT SYSTEM POWERING AND SETUP: IONFRAME EVO STEP 1 Plug the power cord into an AC power outlet to power your grow light. STEP 2 Plug one end of the UIS extension cord into the LED driver, and the other end into your chosen controller.
Page 64 GROW LIGHT SYSTEM STARTER GUIDE: IONBOARD The charts below offer suggested mounting heights and light intensities for each stage in the growing process of your preferred method. These factors will vary based on the plant you are growing. Height refers to distance from the canopy (tip of the plant). HEIGHT Seeding Vegetative...
Page 65: Starter Guide
GROW LIGHT SYSTEM STARTER GUIDE: IONFRAME EVO The chart below lists the coverage area of each grow light size in each growth stage. The supplemental CO2 column refers to sealed grow spaces that use a CO2 enrichment system with a 1300+ PPM. AREA Supplemental Vegetative...
Page 66: Programming
GROW LIGHT SYSTEM PROGRAMMING: IONBOARD OFF/ON MODE Turning the knob to UIS switches the grow light off, or passes control over to your smart controller if one is connected. INTENSITY LEVEL Turning the knob from UIS will establish a set light intensity level in 20% increments, up to 100%.
Page 68: Cloudray: Oscillation Fan System
CLOUDRAY OSCILLATING FAN SYSTEM...
Page 69: Product Contents
CLOUDRAY PRODUCT CONTENTS Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Tent Kit (2x2) Tent Kit (2x2) Tent Kit (2x4) Tent Kit (3x3) Tent Kit (4x4) Tent Kit (5x5) COMPACT AC-PKB22 AC-PKB24 AC-PKB33 AC-PKB44 AC-PKB55 AC-PKA22 CLOUDRAY S6, CLOUDRAY S6, CLOUDRAY S6,...
Page 70: Recommended Usage
CLOUDRAY RECOMMENDED USAGE REDUCING CORD TENSION Please make sure to provide enough slack for the power cord and the extension cord. The fan should be able to oscillate freely without tugging on its cords. MAXIMIZING LIFESPAN This fan utilizes the latest in step motor 6 hr.
Page 71: Installation
CLOUDRAY INSTALLATION STEP 1 Twist to remove the bigger knob piece from the grip clip. Pull the smaller button piece from the vice grip. STEP 2 Slide the grip clip into the swivel as shown.
Page 72 CLOUDRAY INSTALLATION STEP 3 Replace the knob and button on either side of the mounting point as desired. STEP 4 Clamp the fan onto a pole or post.
Page 73 CLOUDRAY INSTALLATION STEP 5 Plug the fan’s power cord into an AC power outlet to power the fan. Plug the fan into the closest AC outlet to allow for cable slack and avoid cable tension. STEP 6 You may manage the cords using the included cable ties or cable mounting set.
Page 74: Cleaning
CLOUDRAY CLEANING STEP 1 Unplug your clip fan. STEP 2 Remove the front grille by twisting the grille counter-clockwise and pulling it off.
Page 75 CLOUDRAY CLEANING STEP 3 Wipe off any dust and debris from the grille and fan blades using a damp cloth. Set aside to dry as needed. STEP 4 Realign the grille over your clip fan and twist clockwise to lock it in place.
Page 76: Programming
CLOUDRAY PROGRAMMING FAN SPEED ADJUSTING Your clip fan features a button that cycles through the fan speed from 0-10, indicated by the ring of LED lights. Fan Speed Press the speed button to increase the Indicator fan speed level by one. Pressing the button past speed 10 will cycle the fan speed back to 0.
Page 77 CLOUDRAY PROGRAMMING OSCILLATION In addition to the standard features, S-Series models can oscillate to provide airflow at a wide angle. The oscillation function is manually activated using the oscillation button and cannot be controlled using external UIS programming. If set to off, your clip fan will not oscillate regardless of any external programs.
Page 78: Controller 69 Pro: Uis
CONTROLLER 69 PRO MULTI-DEVICE CONTROLLER...
Page 79: Product Contents
CONTROLLER 69 PRO PRODUCT CONTENTS Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Advance Grow Tent Kit (2x2) Tent Kit (2x2) Tent Kit (2x4) Tent Kit (3x3) Tent Kit (4x4) Tent Kit (5x5) COMPACT AC-PKB22 AC-PKB24 AC-PKB33 AC-PKB44 AC-PKB55 AC-PKA22 CONTROLLER...
Page 80: Powering And Setup
CONTROLLER 69 PRO POWERING AND SETUP STEP 1 Plug your devices’ UIS connectors into the following numbered ports: Port 1 – Inline Fan Port 2 – Grow Light Port 3 – Clip Fan Port 4 – Clip Fan (AC-PKB44 and AC-PKB55 models only).
Page 81 CONTROLLER 69 PRO POWERING AND SETUP STEP 3 Plug your devices’ power cord into an AC power outlet to power them and the controller. STEP 4 You may use the included tie mounts, wood screws, and wire ties to manage the cords.
Page 82: Mounting
CONTROLLER 69 PRO MOUNTING STEP 1 — WALL MOUNTING Locate a spot free of obstruction and secure the anchors into your wall. Twist the wood screws into the anchors. STEP 2 — WALL MOUNTING Hang the controller by the screws using the holes on the backside.
Page 83 CONTROLLER 69 PRO MOUNTING PLATE MOUNTING Screw the bolts into the slot or mounting holes at the upper half of the plate. Hang the controller by the bolts using the holes on the backside. CORD ARRANGEMENT Cords may be routed into or outside of the kickstand grooves, and through a cut hole behind the controller.
Page 84: Uis Tm Platform
By creating this fully integrated system, you can power and program all your devices together or separately for optimized grow tent management. Your grow system can be regulated using your controller hub or remotely on the AC Infinity app (paired with compatible controllers), where you will have access to automation programming and climate data.
Page 85: Uis Tm Compatibility
The expansion dongle will allow you to connect 4 devices with a single port and can support additional splitters to create up to three tiers of expansion ports. Intended for exclusive use with AC Infinity controllers built with UIS ports. UIS M - M...
Page 86: Adding More Devices
CONTROLLER 69 PRO ADDING MORE DEVICES The CONTROLLER 69 PRO is built with four ports that enable you to power and control multiple devices at the same time. See image below for a sample configuration. USING THE DONGLE EXTENDING THE CHAIN When using a 4-port dongle, plug your When plugging additional dongles into Port first device into Port 1 for the controller to...
Page 87 CONTROLLER 69 PRO ADDING MORE DEVICES DAISY-CHAINING Each of the included controller’s ports can support up to 20 devices using a daisy-chain adapter (not included). All devices must be from the same series but can be of differing sizes. Plug the male end of the daisy-chain adapter into your device. Connect your UIS controller to the daisy-chain adapter’s INPUT port using a M-M connector cord.
Page 88: Programming
CONTROLLER 69 PRO PROGRAMMING 1. PORT BUTTON 2. MODE BUTTON 3. SETTING BUTTON Cycles through up to four Cycles through the controller’s Cycles through the controller’s connected devices. Each modes: OFF, ON, AUTO (4 settings: DISPLAY, CLOCK, device is programmed triggers), VPD (2 triggers), TIMER °F / °C, CALIB.
Page 89 CONTROLLER 69 PRO PROGRAMMING PORTS Pressing the port button will cycle through the controller’s available ports: ALL, 1, 2, 3, and 4. Dot indicates the current device. No digit is displayed if a device is not plugged into the corresponding port. The controller is pre-programmed with the following settings: Port 1 –...
Page 90 CONTROLLER 69 PRO PROGRAMMING CONTROLLER MODES Pressing the mode button will cycle through the controller’s available programming modes: OFF, ON, AUTO (4 triggers), VPD (2 triggers), TIMER TO ON, TIMER TO OFF, CYCLE (On and Off), and SCHEDULE (On and Off). OFF MODE Your devices will not run while in this mode.
Page 91 CONTROLLER 69 PRO PROGRAMMING ON MODE Your devices will actively run at the level set here, regardless of the probe’s reading. The ON Mode setting also serves as the maximum level the other modes will run at. *Example shown MAXIMUM LEVEL Your devices will run at the level set in ON Mode, as the maximum level, when triggered ON, as well as in the AUTO Mode, CYCLE...
Page 92 CONTROLLER 69 PRO PROGRAMMING AUTO MODE (HIGH TEMPERATURE TRIGGER) Pressing the up or down button sets the high temperature trigger. The devices will activate if the probe’s reading meets or exceeds this threshold. Once triggered, the devices will gradually ramp up to the level set in ON mode.
Page 93 CONTROLLER 69 PRO PROGRAMMING AUTO MODE (LOW TEMPERATURE TRIGGER) Pressing the up or down button sets the low temperature trigger. The devices will activate if the probe’s reading meets or falls below this threshold. Once triggered, the devices will gradually ramp up to the level set in ON mode.
Page 94 CONTROLLER 69 PRO PROGRAMMING AUTO MODE (HIGH HUMIDITY TRIGGER) Pressing the up or down button sets the high humidity trigger. The devices will activate if the probe’s reading meets or exceeds this threshold. Once triggered, the devices will gradually ramp up to the level set in ON mode.
Page 95 CONTROLLER 69 PRO PROGRAMMING AUTO MODE (LOW HUMIDITY TRIGGER) Pressing the up or down button sets the low humidity trigger. The devices will activate if the probe’s reading meets or falls below this threshold. Once triggered, the devices will gradually ramp up to the level set in ON mode.
Page 96 CONTROLLER 69 PRO PROGRAMMING VPD MODE (HIGH VPD TRIGGER) Pressing the up or down button sets the high VPD trigger. The devices will activate if the probe’s reading meets or exceeds this threshold. Once triggered, the devices will gradually ramp up to the level set in ON mode. If the probe’s reading falls below this trigger point, the devices will gradually slow down to a stop or at the level set in OFF mode.
Page 97 CONTROLLER 69 PRO PROGRAMMING VPD MODE (LOW VPD TRIGGER) Pressing the up or down button sets the low VPD trigger. The devices will activate if the probe’s reading meets or falls below this threshold. Once triggered, the devices will gradually ramp up to the level set in ON mode. If the probe’s reading rises above this trigger point, the devices will gradually slow down to a stop or at the level set in OFF Mode.
Page 98 CONTROLLER 69 PRO PROGRAMMING TIMER TO ON MODE Pressing the up or down button sets a countdown time. During the countdown, your device will be set to OFF. Once the timer ends, your device will trigger to turn on. If there is a level set in OFF Mode, the devices will run at that level during the countdown and when triggered to turn off.
Page 99 CONTROLLER 69 PRO PROGRAMMING CYCLE MODE (ON AND OFF) 30min. Set an on duration and an off duration for the devices to cycle through continuously. 1hr. Press the up or down button to first set a duration for the devices to activate. Then press the mode button again and set a duration for the devices to deactivate.
Page 100 CONTROLLER 69 PRO PROGRAMMING 12:00 SCHEDULE MODE (ON AND OFF) Sets an on clock-time and an off clock-time schedule for the devices to follow daily. Press the up or down button to first set up an on clock-time to trigger ON mode, then 9:00 press the mode button to set an off clock- time to trigger OFF mode.
Page 101 CONTROLLER 69 PRO PROGRAMMING CONTROLLER SETTINGS Pressing the setting button will cycle through the controller’s available settings: DISPLAY, CLOCK, °F / °C, CALIB. T° / H% / kPa, TRANS. T° / H% / kPa, BUFF. T° / H% / kPa, and LEAF OFFSET.
Page 102 CONTROLLER 69 PRO PROGRAMMING °F/°C SETTING Changes the displayed units to Fahrenheit or Celsius. Press the up or down button to cycle through F and C. All displayed units will automatically convert when adjusting this setting. CLOCK SETTING Adjusts the current clock time. Press the up or down button to increase or decrease the time.
Page 103 CONTROLLER 69 PRO PROGRAMMING CALIBRATION TEMPERATURE SETTING Adjusts the temperature reading the sensor probe is measuring. Press the up or down button to increase or decrease the data figure in 2°F (or 1°C) increments. The calibration cycle ranges from -20°F to 20°F (or -10°C to 10°C) and will be applied to the sensor probe’s measurements.
Page 104 CONTROLLER 69 PRO PROGRAMMING TRANSITION TEMPERATURE SETTING Adjusts how gradually your device will shift between levels when triggered ON by the AUTO Mode’s temperature trigger. This will determine how much the probe temperature needs to increase to step up to the next level setting. The higher the transition setting is, the wider the temperature gap is between levels.
Page 105 CONTROLLER 69 PRO PROGRAMMING TRANSITION HUMIDITY SETTING Adjusts how gradually your device will shift between levels when triggered ON by the AUTO Mode’s humidity trigger. This will determine how much the probe humidity needs to increase to step up to the next level setting.
Page 106 CONTROLLER 69 PRO PROGRAMMING TRANSITION VPD SETTING Adjusts how gradually your device will shift between levels when triggered ON by the VPD trigger. This will determine how much the probe VPD needs to increase to step up to the next level setting. The higher the transition setting is, the wider the VPD gap is between levels.
Page 107 CONTROLLER 69 PRO PROGRAMMING BUFFER TEMPERATURE SETTING The buffer figure will create a trigger-off point below your set trigger point to prevent your device from shutting off too quickly. Press the up or down button to cycle through buffer range from 0°F to 8°F (or 0°C to 4°C).
Page 108 CONTROLLER 69 PRO PROGRAMMING BUFFER HUMIDITY SETTING The buffer figure will create a trigger-off point below your set trigger point to prevent your device from shutting off too quickly. Press the up or down button to cycle through buffer range from 0% to 10%.
Page 109 CONTROLLER 69 PRO PROGRAMMING BUFFER VPD SETTING The buffer figure will create a trigger-off point below your set trigger point to prevent your device from shutting off too quickly. Press the up or down button to cycle through buffer range from 0.1 kPa and 1.0 kPa.
Page 110 CONTROLLER 69 PRO PROGRAMMING ALERT ICONS The alert icons are displayed at the top of the screen. Icons may flash when the controller signals an alert to notify you of any triggered function or alarm. ADVANCE PROGRAMMING Displays when an advance program set in the app is active. "ADV." will appear and override the controller if an automation program is in use.
Page 111 CONTROLLER 69 PRO PROGRAMMING WI-FI Appears when the physical controller is connected to the app via Wi-Fi. DISPLAY LOCK ALERT Displays when you lock the controller. The icon will flash and beep if you attempt to adjust the controller while it is still locked. ALERT Flashes and beeps with an alert whenever a plugged-in device experiences interference to its functioning.
Page 112: Other Settings
CONTROLLER 69 PRO OTHER SETTINGS FACTORY RESET Holding the mode, up, and down buttons together for 5 HOLD + seconds will reset your controller and restore factory settings. This clears all user parameters in each controller mode and setting. CONTROLLER LOCK Holding the setting button will lock the controller in your current mode.
Page 113: Download The App
114-120 to pair your controller with the app. QUICK TIP FOR EASY ACCESS Open the smart phone camera and scan the QR code below to download the AC Infinity app. Please visit our website at www.acinfinity.com for more information on the AC Infinity app.
Page 114: Add A Device
CONTROLLER 69 PRO ADD A DEVICE: BLUETOOTH SETUP AND PAIRING Power your device on before pairing your controller with the app. Logging in or creating an account beforehand will expedite the pairing process. Have your Wi-Fi network’s name and password ready. Tap on the “+”...
Page 115 CONTROLLER 69 PRO ADD A DEVICE: BLUETOOTH Select CONTROLLER 69 PRO. Hold the port button for 5 seconds to activate Bluetooth. Wait for the Bluetooth icon to start flashing on your controller’s screen.
Page 116 CONTROLLER 69 PRO ADD A DEVICE: BLUETOOTH Connect using Bluetooth. To Connecting with Bluetooth will connect using Wi-Fi, skip to step 8. disable Wi-Fi functionality. Go to the app settings page to re- enable and connect using Wi-Fi. When pairing the app around multiple controllers, move your mobile device closer to your desired controller.
Page 117 CONTROLLER 69 PRO ADD A DEVICE: BLUETOOTH Tap the DONE button to complete the pairing process.
Page 118 CONTROLLER 69 PRO ADD A DEVICE: WI-FI Repeat steps 1-5. Log in or create Enter your Wi-Fi network’s an account to continue. password. You may also connect to an alternate 2.4 GHz router*. When pairing the app around multiple controllers, move your mobile device closer to your desired controller.
Page 119 CONTROLLER 69 PRO ADD A DEVICE: WI-FI Follow these tips if the pairing Tap the DONE button to complete process is unsuccessful. the pairing process. DONE *This controller is only compatible with 2.4 GHz frequency band routers. When connecting using Wi-Fi, make sure your mobile device is not connected to a 5 GHz frequency band network.
Page 120 CONTROLLER 69 PRO ADD A DEVICE: WI-FI Your controller will appear in your smart device with a unique ID. G-G000G...
Page 121: Frequently Asked Questions
What devices are compatible with the CONTROLLER 69 PRO? All AC Infinity devices that contain a UIS connector are compatible. If your AC Infinity device has a 4-pin Molex connector and an EC-Motor, it may still be compatible with the use of an UIS adapter to convert its connector to fit with the controller.
Page 122 Please refer to pages 86-87 for details on adding more fan units. Will I be able to use this controller with my own devices? The CONTROLLER 69 PRO is only compatible with AC Infinity fans that use EC-motors. Does the controller retain its settings after power is shut off? Yes.
Page 123 CONTROLLER 69 PRO FREQUENTLY ASKED QUESTIONS Why does the app ask me for location permissions? The app requires location permissions to find the relative position of your smart controller and communicate with existing Bluetooth devices already paired with the app. All Android devices prior to system version 12.0 will require location permissions to be turned on for the Bluetooth scan to be successful.
Page 124: Warranty
WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues.
Page 125 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
