Page 1
TOUCH FREE Infrared Thermometer NT66B RoHS REACH MDSS GmbH Schiffgraben 41 30175 Hannover Germany AViTA Corporation 9F., No. 78, Sec. 1, Kwang Fu Rd., San Chung Dist., New Taipei City 24158, Taiwan, China China, AViTA(WUJIANG) Importer Distributor INSTRUCTION MANUAL Please read this instruction manual carefully...
Page 2
Contents Introduction ........................1 Important Information before Use ................2 Product Identification ..................... 4 Description of LCD Display ................... 5 Battery Installation ......................6 Switching Between Fahrenheit or Celsius .............. 7 Switching between 4 Kinds of Measuring Mode ..........7 Tips for Measuring Human Temperature ...............
Page 3
Introduction Intended Use: Touch Free Infrared Thermometer is intended for home use and the intermittent measurement of human body forehead temperature in people of all ages. Features: 1. 2 in 1 thermometer: Human Body/Object 2. Fever Indication (Human Body Mode only) 3.
Page 4
Important Information before Use When using this product, please be sure to follow all the notes listed below. Any action against these notices may cause injury or affect the accuracy. 1. Do not disassemble, repair, or remodel the thermometer. 2. Be sure to clean the thermometer lens each time after usage. 3.
Page 5
CAUTION: Please keep this device away from pets, pests, and children. CAUTION: Please keep away from children and pets, because small parts may be inhaled or swallowed. 17. If any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user is established.
Page 7
Description of LCD Display Measuring sequence in process Night Mode (Mute Mode) Human Mode Object Mode Degree of measurement Celsius Scale Fahrenheit Scale Low battery indicator Frowning Face (temperature is equal or higher than 38°C) Smiling Face (temperature is lower than 38°C) Memory Symbol and sets of records...
Page 8
Battery Installation Low battery warning: When the battery power becomes low, the low battery symbol “ ” will appear on the display. The thermometer can still be used during this time, but the batteries should be replaced as soon as possible. If the batteries run out completely, “Lo”...
Page 9
Switching Between Fahrenheit or Celsius Your thermometer can display results in either degrees Celsius (°C) or degrees Fahrenheit (°F). With combination of Memory and Mode button are able to change the mode to either °C or °F with a beep sound.
Page 10
Tips for Measuring Human Temperature Bear in mind that the thermometer needs to have been in the room in which the measurement is taken for at least 30 minutes before use. NOTE: • Attempting to take temperature readings from sites on the body other than the forehead may produce inaccurate results.
Page 11
3. Position the thermometer under 3cm (around 1 inch) from the center of the patient's forehead with the sensor aimed between the eyebrows. 4. Press and release the Measure Button. 5. Slowly move the device toward or farther from the forehead until you have reached the correct distance.
Page 12
Measuring Object/Liquid Temperature 1. Press the “Measure Button” to turn the thermometer on. All symbols on the display will momentarily appear. 2. Ensure that the thermometer is in Object Mode; the Object symbol “ ”will be on the display. To alternate between modes press and release the Human/Object Mode Button until you see the desired measurement symbol on the display.
Page 13
Memory Function Memory Recall: You can recall up to 10 measurements currently stored in memory to share with your physician or trained healthcare professional. 1. When the device is on, press once briefly on the Memory Button, then pass it again to show the last measurement accompanied by “...
Page 14
Cleaning and Disinfecting For home use device disinfection, 75% alcohol (available in the pharmacy) can be used. • Measurement Sensor Clean the measurement sensor with an alcohol swab before and after each measurement. • Thermometer: Use a soft, dry cloth to clean thermometer body. Never use abrasive cleaning agents, thinners or benzene for cleaning.
Page 15
Troubleshooting Trouble Probable Case Recommended Action Failed to power Batteries are drained. Replace with a new battery Batteries are not Reinsert batteries correctly aligned with correctly. terminals. The thermometer is Contact your retailer or damaged. Customer Services. Low battery Low battery. Replace with a new symbol appears.
Page 16
from extreme room at least for 30 temperatures minutes. environment. The thermometer has Put the thermometer in been stored in a cold steady state room at room or exposed to least for 30 minutes. direct sunlight. Measurement was Switch mode to human taken in surface mode.
Page 17
Set Up Process (1) Please determine your mobile phone or computer has BLE4.2. (2) Turn on the NT66B device, when the Bluetooth icon shows on the device , it means NT66B device is under broadcast condition. (3) Please check the connecting condition from your mobile phone or computer.
Page 18
• Reference body site: Ear temperature • For Customer Service To obtain further service please contact AViTA Corp. for the address of the repair location. Enclose the Proof of Purchase. Include $10.00 USD for the return shipping and handling. Include a letter, with your name, address, phone number, and description of the specific problem.
Page 19
EMC Tables NT66B is intended for use in the electromagnetic environment specified below. The customer or the user of NT66B must make sure that it is used in such an environment. Guidance and manufacturer’s declaration - Electromagnetic emissions Professional healthcare...
Page 20
RF communications equipment (transmitters) and the NT66B can be requested from supplier using the contact information provided in this manual. However, it is advisable to keep the equipment at an adequate distance of, at least, 0.5 m from...
Page 21
Explanation of Symbols The CE marking with the Registration Number of the Notified Body. This denotes the compliance of Regulation (EU) 2017/745 Medical Device Manufacturer Authorized representative in the European Community Date of manufacture (YYYY-MM-DD or YYYY-MM) Batch code (YYMMWWWW) Serial number (YYMWWWXXXXX) Keep dry...
Page 22
Humidity limitation Atmospheric pressure limitation Caution Consult the instruction for use Disposal information: Should you wish to dispose of the article, do so in accordance with current regulations. Details are available from your local authority. WEEE 2012/19/EU Directives This product fulfilling the requirements of the RoHS RoHS Directive 2011/65/EU.
Page 23
Model Number Country of Manufacturer Unique Device Identifier Data Element Data Type/Format (01) Device Identifier(GTIN) Numeric (11) Manufacturing Date Numeric: YYMMDD (10) Lot Number Alphanumeric (21) Serial Number Alphanumeric Keep away from sunlight Electronic IFU available at http://www.avita.com.tw NT66BP-22480AV 2022-12-22...
