TOUCH FREE Infrared Thermometer
NT17B
EN
RoHS REACH
MDSS GmbH
Schiffgraben 41
30175 Hannover Germany
AViTA Corporation
9F., No. 78, Sec. 1, Kwang Fu Road,
San Chung District., New Taipei City, Taiwan,24158,China
China, AViTA(WUJIANG)
Importer
Distributor
INSTRUCTION MANUAL
Please read this instruction manual carefully
before using your forehead thermometer
Advertisement
Table of Contents
Related Manuals for Avita NT17B
Summary of Contents for Avita NT17B
- Page 1 TOUCH FREE Infrared Thermometer NT17B RoHS REACH MDSS GmbH Schiffgraben 41 30175 Hannover Germany AViTA Corporation 9F., No. 78, Sec. 1, Kwang Fu Road, San Chung District., New Taipei City, Taiwan,24158,China China, AViTA(WUJIANG) Importer Distributor INSTRUCTION MANUAL Please read this instruction manual carefully...
-
Page 2: Table Of Contents
Contents Introduction ........................1 Important Information before Use ................ 2 Product Identification ....................4 Description of LCD Display ..................5 Battery Installation ....................... 6 Switching Between Fahrenheit or Celsius ............7 Switching between 4 Kinds of Measuring Mode ..........7 Tips for Measuring Human Temperature ............ -
Page 3: Introduction
Introduction Intended Use: Touch Free Infrared Thermometer is intended for home use and the intermittent measurement of human body forehead temperature in people of all ages. Features: 1. Multi functions Human Body/ Object/ Night Mode Option/ Fever Alarm/ Backlight 2. Night Mode Option Switch to Night mode can mute the sound to reduce the interference of buzzer during your baby sleeping. -
Page 4: Important Information Before Use
Important Information before Use When using this product, please be sure to follow all the notes listed below. Any action against these notices may cause injury or affect the accuracy. 1. Do not disassemble, repair, or remodel the thermometer. 2. Be sure to clean the thermometer lens each time after usage. 3. - Page 5 CAUTION: Please keep this device away from pets, pests, and children. CAUTION: Please keep away from children and pets, because small parts may be inhaled or swallowed. 17. If any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user is established.
-
Page 6: Product Identification
Product Identification LCD Display LED Light Mode Button Measure Button Memory Button Measurement Sensor Sound Hole Battery Compartment Lid... -
Page 7: Description Of Lcd Display
Description of LCD Display Measuring sequence in process Night Mode (Mute Mode) Human Mode Object Mode Degree of measurement Celsius Scale Fahrenheit Scale Low battery indicator Frowning Face (temperature is equal or higher than 38°C) Smiling Face (temperature is lower than 38°C) Memory Symbol and sets of records... -
Page 8: Battery Installation
Battery Installation Low battery warning: When the battery power becomes low, the low battery symbol “ ” will appear on the display. The thermometer can still be used during this time, but the batteries should be replaced as soon as possible. If the batteries run out completely, “Lo”... -
Page 9: Switching Between Fahrenheit Or Celsius
Switching Between Fahrenheit or Celsius Your thermometer can display results in either degrees Celsius (°C) or degrees Fahrenheit (°F). With combination of Memory and Mode button are able to change the mode to either °C or °F with a beep sound. -
Page 10: Tips For Measuring Human Temperature
Tips for Measuring Human Temperature Bear in mind that the thermometer needs to have been in the room in which the measurement is taken for at least 30 minutes before use. NOTE: • Attempting to take temperature readings from sites on the body other than the forehead may produce inaccurate results. -
Page 11: Measuring Human Temperature
Measuring Human Temperature Taking a Measurement 1. Press the Power Button to power on the thermometer. The unit will run a self-test and the LCD will briefly display all of its symbols during this time. When the device is ready, “--“appear on the screen, and the thermometer is ready to take a measurement. -
Page 12: Measuring Object/Liquid Temperature
Measuring Object/Liquid Temperature 1. Press the “Measure Button” to turn the thermometer on. All symbols on the display will momentarily appear. 2. Ensure that the thermometer is in Object Mode; the Object symbol “ ”will be on the display. To alternate between modes press and release the Human/Object Mode Button until you see the desired measurement symbol on the display. -
Page 13: Memory Function
Memory Function Memory Recall: You can recall up to 30 measurements currently stored in memory to share with your physician or trained healthcare professional. 1. When the device is on, press once briefly on the Memory Button, then pass it again to show the last measurement accompanied by “... -
Page 14: Cleaning And Disinfecting
Cleaning and Disinfecting For home use device disinfection, 75% alcohol (available in the pharmacy) can be used. • Measurement Sensor Clean the measurement sensor with an alcohol swab before and after each measurement. • Thermometer: Use a soft, dry cloth to clean thermometer body. Never use abrasive cleaning agents, thinners or benzene for cleaning. -
Page 15: Error Codes
Error Codes When a malfunction or incorrect temperature measurement occurs, an error message will appear as described below. Display Cause Solution Operate the thermometer The temperature measured is only between the specified higher than measurement range. temperature ranges. If Human mode: 43°C (109.4°F) necessary, clean the sensor Object mode:... -
Page 16: Troubleshooting
Troubleshooting Trouble Probable Case Recommended Action Failed to power Batteries are drained. Replace with a new battery Batteries are not Reinsert batteries correctly aligned with correctly. terminals. The thermometer is Contact your retailer or damaged. Customer Services. Low battery Low battery. Replace with a new symbol appears. - Page 17 from extreme room at least for 30 temperatures minutes. environment. The thermometer has Put the thermometer in been stored in a cold steady state room at room or exposed to least for 30 minutes. direct sunlight. Measurement was Switch mode to human taken in surface mode.
-
Page 18: Operating The Bluetooth Function
Set Up Process (1) Please determine your mobile phone or computer has BLE4.2. (2) Turn on the NT17B device, when the Bluetooth icon shows on the device , it means NT17B device is under broadcast condition. (3) Please check the connecting condition from your mobile phone or computer. -
Page 19: Technical Specification
90 minutes (Depends on different brand of batteries.) • For Customer Service To obtain further service please contact AViTA Corp. for the address of the repair location. Enclose the Proof of Purchase. Include $10.00 USD for the return shipping and handling. Include a letter, with your name, address, phone number, and description of the specific problem. -
Page 20: Emc Tables
EMC Tables NT17B is intended for use in the electromagnetic environment specified below. The customer or the user of NT17B must make sure that it is used in such an environment. Guidance and manufacturer’s declaration - Electromagnetic emissions Professional healthcare... - Page 21 RF communications equipment (transmitters) and the NT17B can be requested from supplier using the contact information provided in this manual. However, it is advisable to keep the equipment at an adequate distance of, at least, 0.5 m from...
-
Page 22: Federal Communications Commission Interference Statement
Federal communications commission interference statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 23: Explanation Of Symbols
Explanation of Symbols Medical Device Manufacturer Date of manufacture (YYYY-MM-DD or YYYY-MM) Batch code (YYMMWWWW) Serial number (YYMWWWXXXXX) Keep dry Temperature limit Humidity limitation Atmospheric pressure limitation... - Page 24 Caution Consult the instruction for use Disposal information: Should you wish to dispose of the article, do so in accordance with current regulations. Details are available from your local authority. WEEE 2012/19/EU Directives This product fulfilling the requirements of the RoHS RoHS Directive 2011/65/EU.
- Page 25 The empty, completely flat batteries must be disposed of through specially designated collection boxes, recycling points or electronics retailers. You are legally required to dispose of the batteries. Importer Distributor Model Number Country of Manufacturer Unique Device Identifier Keep away from sunlight This device complies with part 15 of the FCC Rules.
