TOUCH FREE Infrared Thermometer
NT1G
EN
RoHS REACH
MDSS GmbH
Schiffgraben 41
30175 Hannover Germany
AViTA Corporation
9F., No. 78, Sec. 1, Kwang Fu Rd.,
San Chung Dist., New Taipei City 24158, Taiwan, China
China, AViTA(WUJIANG)
Importer
Distributor
INSTRUCTION MANUAL
Please read this instruction manual carefully
before using your forehead thermometer
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avita NT1G
Summary of Contents for Avita NT1G
- Page 1 TOUCH FREE Infrared Thermometer NT1G RoHS REACH MDSS GmbH Schiffgraben 41 30175 Hannover Germany AViTA Corporation 9F., No. 78, Sec. 1, Kwang Fu Rd., San Chung Dist., New Taipei City 24158, Taiwan, China China, AViTA(WUJIANG) Importer Distributor INSTRUCTION MANUAL Please read this instruction manual carefully...
-
Page 2: Table Of Contents
Contents Introduction ........................1 Important Information before Use ................2 Product Identification ..................... 4 Description of LCD Display ................... 5 Switching Between Fahrenheit or Celsius .............. 6 Tips for Measuring Human Temperature ............... 6 Power-On Method ......................7 Measuring Human Temperature ................8 Low-Power Indication ..................... -
Page 3: Introduction
Introduction Intended Use: Touch Free Infrared Thermometer is intended for home use and the intermittent measurement of human body forehead temperature in people of all ages. Features: 1. Multi functions Human Body/ Fever Indication 2. °C/°F Switch-able Function 3. One-second Reading 4. -
Page 4: Important Information Before Use
Important Information before Use When using this product, please be sure to follow all the notes listed below. Any action against these notices may cause injury or affect the accuracy. 1. Do not disassemble, repair, or remodel the thermometer. 2. Be sure to clean the thermometer lens each time after usage. 3. - Page 5 CAUTION: Please keep this device away from pets, pests, and children. CAUTION: Please keep away from children and pets, because small parts may be inhaled or swallowed. 17. If any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user is established.
-
Page 6: Product Identification
Product Identification LCD Display Measure Button Measurement Sensor Wheel... -
Page 7: Description Of Lcd Display
Description of LCD Display Memory Mode Measuring sequence in process Degree of measurement Celsius Scale Fahrenheit Scale Power indicator Frowning Face (temperature is equal or higher than 38°C) Smiling Face (temperature is lower than 38°C) -
Page 8: Switching Between Fahrenheit Or Celsius
Switching Between Fahrenheit or Celsius Your thermometer can display results in either degrees Celsius (℃ ) or degrees Fahrenheit ( ℉ ). To switch between Celsius and Fahrenheit, while the unit is on press and hold the Measure button for approximately 5 seconds in the power-on state. -
Page 9: Power-On Method
Power-On Method For the first time using, or the thermometer hasn't been used for a long time, to restore power simply scroll back and forth to gain power. When start scrolling the wheel, locate at the end of the device, the golden capacitor will store electrical power and when the thermometer detects enough power, the power indicator icon will pop up promptly. -
Page 10: Measuring Human Temperature
Measuring Human Temperature 1. Position the thermometer under 3cm (around 1 inch) from the center of the patient's forehead with the sensor aimed between the eyebrows. 2. Press and release the Measure Button. As you hear a short beep means this temperature reading has been completed. 3. -
Page 11: Cleaning And Disinfecting
Cleaning and Disinfecting For home use device disinfection, 75% alcohol (available in the pharmacy) can be used. • Measurement Sensor Clean the measurement sensor with an alcohol swab before and after each measurement. • Thermometer: Use a soft, dry cloth to clean thermometer body. Never use abrasive cleaning agents, thinners or benzene for cleaning. -
Page 12: Error Codes
Error Codes When a malfunction or incorrect temperature measurement occurs, an error message will appear as described below. Display Cause Solution Operate the thermometer The temperature measured is only between the specified higher than measurement range. temperature ranges. If Human mode: 43°C (109.4°F) necessary, clean the sensor Object mode:... -
Page 13: Troubleshooting
Troubleshooting Trouble Probable Case Recommended Action Failed to power Batteries are drained. Replace with a new battery Batteries are not Reinsert batteries correctly aligned with correctly. terminals. The thermometer is Contact your retailer or damaged. Customer Services. Low battery Low battery. Replace with a new symbol appears. - Page 14 from extreme room at least for 30 temperatures minutes. environment. The thermometer has Put the thermometer in been stored in a cold steady state room at room or exposed to least for 30 minutes. direct sunlight. Measurement was Switch mode to human taken in surface mode.
-
Page 15: Technical Specification
90 minutes (Depends on different brand of batteries.) • For Customer Service To obtain further service please contact AViTA Corp. for the address of the repair location. Enclose the Proof of Purchase. Include $10.00 USD for the return shipping and handling. Include a letter, with your name, address, phone number, and description of the specific problem. -
Page 16: Emc Tables
EMC Tables NT1G is intended for use in the electromagnetic environment specified below. The customer or the user of NT1G must make sure that it is used in such an environment. Guidance and manufacturer’s declaration - Electromagnetic emissions Professional healthcare... - Page 17 RF communications equipment (transmitters) and the NT1G can be requested from supplier using the contact information provided in this manual. However, it is advisable to keep the equipment at an adequate distance of, at least, 0.5 m from...
-
Page 18: Explanation Of Symbols
Explanation of Symbols The CE marking with the Registration Number of the Notified Body. This denotes the compliance of Regulation (EU) 2017/745 Medical Device Manufacturer Authorized representative in the European Community Date of manufacture (YYMMDD or YYYY-MM) Batch code (YYMMWWWW) Serial number (YYMWWWXXXXX) Keep dry... - Page 19 Humidity limitation Atmospheric pressure limitation Caution Consult the instruction for use Disposal information: Should you wish to dispose of the article, do so in accordance with current regulations. Details are available from your local authority. WEEE 2012/19/EU Directives This product fulfilling the requirements of the RoHS RoHS Directive 2011/65/EU.
- Page 20 Model Number Country of Manufacturer Unique Device Identifier Data Element Data Type/Format (01) Device Identifier(GTIN) Numeric (11) Manufacturing Date Numeric: YYMMDD (10) Lot Number Alphanumeric (21) Serial Number Alphanumeric Keep away from sunlight Electronic IFU available at http://www.avita.com.tw NT1GP-22432AV 2023-05-30...
