TOUCH FREE Infrared Thermometer
NT61B
EN
RoHS REACH
MDSS GmbH
Schiffgraben 41
30175 Hannover Germany
AViTA Corporation
9F., No. 78, Sec. 1, Kwang Fu Rd.,
San Chung Dist., New Taipei City 24158, Taiwan, China
China, AViTA(WUJIANG)
Importer
Distributor
INSTRUCTION MANUAL
Please read this instruction manual carefully
before using your forehead thermometer
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avita NT61B
Summary of Contents for Avita NT61B
- Page 1 TOUCH FREE Infrared Thermometer NT61B RoHS REACH MDSS GmbH Schiffgraben 41 30175 Hannover Germany AViTA Corporation 9F., No. 78, Sec. 1, Kwang Fu Rd., San Chung Dist., New Taipei City 24158, Taiwan, China China, AViTA(WUJIANG) Importer Distributor INSTRUCTION MANUAL Please read this instruction manual carefully...
-
Page 2: Table Of Contents
Contents Introduction ........................1 Important Information before Use ................2 Product Identification ..................... 4 Description of LCD Display ................... 5 Battery Installation ......................6 Switching on and setting the thermometer............7 Setting the basic functions ................... 7 Measuring Object and Room Temperature ............11 Cleaning and Disinfecting ................... -
Page 3: Introduction
Introduction Intended use This Touch Free Infrared Thermometers is intended for home use and the intermittent measurement of human body forehead temperature in people of all ages. Type of Use/ Reuse Multiple patient multiple use Intended User The Patient is an intended operator. Patient selection criteria: Handicapped persons and children are the exception of handicapped persons and children need assistance by another person to use the device. -
Page 4: Important Information Before Use
Important Information before Use When using this product, please be sure to follow all the notes listed below. Any action against these notices may cause injury or affect the accuracy. 1. Do not disassemble, repair, or remodel the thermometer. 2. Be sure to clean the thermometer lens each time after usage. 3. - Page 5 CAUTION: Please keep this device away from pets, pests, and children. CAUTION: Please keep away from children and pets, because small parts may be inhaled or swallowed. 17. If any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user is established.
-
Page 6: Product Identification
Product Identification Display MODE/MEM button MODE sets the measurement mode display stored measurement / SCAN button Switch on the device. SCAN Starts the temperature measurement. LIGHT/SET button LIGHT manual switch on/off the illuminated display sets the basic functions Measuring sensor Battery compartment lid... -
Page 7: Description Of Lcd Display
Description of LCD Display Bluetooth Object temperature mode Room temperature mode Forehead temperature mode Acoustic signal symbol Time Memory function Date Temperature/memory space number display Battery status indicator Measurement ≥ 38.0 °C ( ≥ 100.4 °F) “fever” Measurement < 37.5 °C (< 99.5 °F) “no fever” Illuminated display symbol Temperature measurement unit Celsius Temperature measurement unit Fahrenheit... -
Page 8: Battery Installation
Battery Installation Low battery warning: If the batteries run out completely, the low battery symbol “ ” will be displayed. In this case, the batteries will need to be replaced before using the thermometer again. CAUTION: Risk of explosion if battery is replaced by an incorrect type. It is recommended not to use rechargeable, unqualified or different spec of batteries as it may damage the device or cause circuit shortcut. -
Page 9: Switching On And Setting The Thermometer
Switching on and setting the thermometer To switch on the thermometer, briefly press the / SCAN button. After a brief self-test and two short beeps the thermometer is ready for forehead measurement. The device always starts up in forehead temperature mode Setting the basic functions This menu allows you to set the following functions individually, one after another. - Page 10 Date The year flashes on the display • Use the MODE/MEM button to set the year, and confirm with the LIGHT/SET button. The day/month flashes on the display • Use the MODE/MEM button to set the day and month, and confirm with the LIGHT/SET button If the hour format is set as 12 h, the day/month display sequence is reversed.
- Page 11 • To activate the automatic illuminated display, use the MODE/MEM button to select , and confirm with the LIGHT/SET button. • To deactivate the automatic illuminated display, use the MODE/MEM button to select , and confirm with the LIGHT/SET button. Acoustic signal The acoustic signal symbol flashes on the display.
- Page 12 Displaying stored measurements The device only stores measurements in forehead temperature mode . The device automatically stores the values from the last 60 measurements. When 60 memory spaces are exceeded, the oldest value is deleted. • The memory can be called up as follows: •...
-
Page 13: Measuring Object And Room Temperature
Measuring Object and Room Temperature Object temperature mode If you want to measure an object temperature with this thermometer, switch to object temperature mode. • With the thermometer switched on, briefly press the MODE/MEM button. The device switches to the object temperature mode •... -
Page 14: Cleaning And Disinfecting
Cleaning and Disinfecting For home use device disinfection, 75% alcohol (available in the pharmacy) can be used. • Measurement Sensor Clean the measurement sensor with an alcohol swab before and after each measurement. • Thermometer: Use a soft, dry cloth to clean thermometer body. Never use abrasive cleaning agents, thinners or benzene for cleaning. -
Page 15: Error Codes
Error Codes When a malfunction or incorrect temperature measurement occurs, an error message will appear as described below. Error Problem Solution message Measurement during Wait until the forehead self-test, device not yet symbol stops flashing. ready for measurement. Room temperature below 10 Room temperature must be °C or over 40 °C (<50 °F, between 10 °C and 40 °C... -
Page 16: Troubleshooting
Troubleshooting Trouble Probable Case Recommended Action Failed to power Batteries are drained. Replace with a new battery Batteries are not Reinsert batteries correctly aligned with correctly. terminals. The thermometer is Contact your retailer or damaged. Customer Services. Low battery Low battery. Replace with a new symbol appears. - Page 17 from extreme room at least for 30 temperatures minutes. environment. The thermometer has Put the thermometer in been stored in a cold steady state room at room or exposed to least for 30 minutes. direct sunlight. Measurement was Switch mode to human taken in surface mode.
-
Page 18: Operating The Bluetooth Function
Set Up Process (1) Please determine your mobile phone or computer has BLE4.2. (2) Turn on the NT61B device, when the Bluetooth icon shows on the device , it means NT61B device device is under broadcast condition. (3) Please check the connecting condition from your mobile phone or computer. -
Page 19: Technical Specification
2402~2480GHz Output power range <=4dBm For Customer Service To obtain further service please contact AViTA Corp. for the address of the repair location. Enclose the Proof of Purchase. Include $10.00 USD for the return shipping and handling. Include a letter, with your name, address, phone number, and description of the specific problem. -
Page 20: Emc Tables
EMC Tables NT61B is intended for use in the electromagnetic environment specified below. The customer or the user of NT61B must make sure that it is used in such an environment. Guidance and manufacturer’s declaration - Electromagnetic emissions Professional healthcare... - Page 21 RF communications equipment (transmitters) and the NT61B can be requested from supplier using the contact information provided in this manual. However, it is advisable to keep the electromechanical aerosol equipment at an adequate distance of, at least, 0.5 m from mobile phones...
-
Page 22: Explanation Of Symbols
Explanation of Symbols The CE marking with the Registration Number of the Notified Body. This denotes the compliance of Regulation (EU) 2017/745 Medical Device Manufacturer Authorized representative in the European Community Date of manufacture (YYMMDD or YYYY-MM) Batch code (YYMMWWWW) Serial number (YYMWWWXXXXX) Keep dry... - Page 23 Humidity limitation Atmospheric pressure limitation Caution Consult the instruction for use Disposal information: Should you wish to dispose of the article, do so in accordance with current regulations. Details are available from your local authority. WEEE 2012/19/EU Directives This product fulfilling the requirements of the RoHS RoHS Directive 2011/65/EU.
- Page 24 Model Number Country of Manufacturer Unique Device Identifier Data Element Data Type/Format (01) Device Identifier(GTIN) Numeric (11) Manufacturing Date Numeric: YYMMDD (10) Lot Number Alphanumeric (21) Serial Number Alphanumeric Keep away from sunlight Electronic IFU available at http://www.avita.com.tw NT61BP-22456AV 2023-05-30...
