Uc4000 series self-contained undercounter refrigerator/freezer
Hide thumbs Also See for UC4048:

Advertisement

UC4000 Series
Self-Contained Undercounter Refrigerator/Freezer
Models
UC4048
Undercounter refrigerator

Two section

UC4148
Undercounter freezer
Two section
UC4048

Specifications

Exterior top shall be one-piece, 22-gauge stainless steel with
front edge turned down to form nosing and rear edge turned
down.
Exterior bottom shall be one-piece, 14-gauge galvanized
metal. Exterior ends shall be 22-gauge stainless steel.
Base interior shall be one-piece thermoformed ABS plastic
material, with integral shelf supports. ABS interior is backed
by a limited lifetime warranty. Cabinet shall have (4) epoxy-
coated wire shelves installed. Base shall be fully insulated with
high-density foamed-in-place environmentally friendly, Kyoto
Protocol Compliant, Non ODP (Ozone Depletion Potential),
Non GWP (Global Warming Potential) polyurethane.
Doors shall have a 22-gauge stainless steel exterior, with a
thermoformed ABS plastic interior liner, and shall be fully
insulated with foamed-in-place polyurethane. Door handles
shall be black, recessed ABS.
Electrical connections shall be 115 volt, 60 Hertz, single
phase. Unit shall have a 6' (1.8m) long electrical cord and
NEMA 5-15P plug. Cord and plug shall be located on rear of
cabinet, 16" (41 cm) above floor, 12" (30 cm) from left side.
Equipment is shipped with loose 6" (15 cm) high metal legs
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858

Standard Features

Features Delfield's exclusive ABS interior. ABS
is extremely durable - it won't dent, chip or
corrode and is backed by a limited lifetime
warranty
Stainless steel front, sides and top
Environmentally friendly R404A refrigerant
Foamed in place environmentally friendly,
Kyoto Protocol Compliant, Non ODP (Ozone
Depletion Potential), Non GWP (Global
Warming Potential) polyurethane cuts energy
costs
Four epoxy coated wire shelves standard
installed per unit
Black recessed quick grip handle
Rugged 6" high heavy duty metal legs
Door hinging available on either right or left,
right side is standard
6' cord and plug supplied
One year parts and 90 day labor standard
warranty.
with black enamel finish unless mounting is specified on
original sales order.
REFRIGERATION SYSTEM
THE
FOLLOWING
(REFRIGERATOR) ONLY:
Refrigeration
Compressor shall be 1/5 h.p., with condenser coil and hot
gas condensate evaporator mounted on rear of cabinet.
Evaporator coil and temperature control shall be mounted on
the interior rear wall of the cabinet. Refrigerant flow shall be
controlled by a capillary tube. Cabinet shall maintain 36°F to
40°F (2°C to 4°C) interior cabinet temperature.
THE FOLLOWING APPLIES TO MODEL UC4148 (FREEZER)
ONLY:
Refrigeration
Compressor shall be 1/3 h.p., with condenser coil and hot
gas condensate evaporator mounted on the rear of cabinet.
Evaporator coil and temperature control shall be mounted on
the interior rear wall of the cabinet. Refrigerant flow shall be
controlled by a capillary tube. Cabinet shall maintain -5°F to
0°F (-21°C to -18°C) interior cabinet temperature.
Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
APPLIES
TO
MODEL
UC4048
system
shall
use
HFC-404A
refrigerant.
system
shall
use
HFC-404A
refrigerant.
www.delfield.com
Options &
Accessories
Stainless steel back
Plastic laminate on front
Additional shelf
3.5" (9 cm) diameter casters (recommended
for under counter)
5" (13 cm) diameter caster also available
Door lock
220 volt, 50 Hertz electrical system*
*
This option will alter the unit's electrical
specifications
Only
Model UC4048
