Fresh Solutions, Fit For You
Compact Refrigerators & Freezers
400P & 4000P Series
Original Instructions
Installation, Operation and Maintenance Manual
This manual is updated as new information and models are released. Visit our website for the latest manual.
**Note - additional shelves shown above**
Caution
,
Read this instruction before operating this equipment.
Original Document
Part Number 9294045C 03/22
Advertisement
Table of Contents
Related Manuals for Delfield 400P Series
Summary of Contents for Delfield 400P Series
- Page 1 All manuals and user guides at all-guidesbox.com Fresh Solutions, Fit For You Compact Refrigerators & Freezers 400P & 4000P Series Original Instructions Installation, Operation and Maintenance Manual This manual is updated as new information and models are released. Visit our website for the latest manual. **Note - additional shelves shown above** Caution Read this instruction before operating this equipment.
- Page 2 All manuals and user guides at all-guidesbox.com Safety Notices Warning Do not use electrical appliances inside the food storage Warning compartments of the appliance, unless they are of the Read this manual thoroughly before operating, installing type recommended by the manufacturer. or performing maintenance on the equipment.
-
Page 3: Table Of Contents
All manuals and user guides at all-guidesbox.com Table of Contents Section 1 General Information Model Numbers ........................4 Serial Number Location ..................... 4 Warranty Information ......................4 Regulatory Certifications ....................4 Section 2 Installation Location ..........................5 Weight of Equipment ......................6 Clearance Requirements .................... -
Page 4: General Information
Undercounter Refrigerator With Subtop And 3.75” Casters 406CAP Warranty Information Visit Undercounter Freezer Base With Stainless Steel Top 407P http://www.delfield.com/warranty to: 407P-ES • Register your product for warranty. • Verify warranty information. Undercounter Freezer With Subtop And 3.75” Casters •... -
Page 5: Installation
All manuals and user guides at all-guidesbox.com Section 2 Installation Caution DANGER Installation must comply with all applicable fire and Do not position the air intake vent near steam or heat exhaust of another appliance. health codes in your jurisdiction. DANGER The location selected for the equipment must meet the following criteria. -
Page 6: Weight Of Equipment
All manuals and user guides at all-guidesbox.com Installation Section 2 Weight of Equipment Dimensions Model Length Depth Height Model Weight 402P 27” (69cm) 28.5” (72cm) 39.5” (100cm) 402P 176lbs (80kg) 403P 27” (69cm) 28.5” (72cm) 35.5” (90cm) 403P 176lbs (80kg) 406P 27”... -
Page 7: Electrical Service
All manuals and user guides at all-guidesbox.com Section 2 Installation Electrical Service RATED AMPERAGES, HORSEPOWER, VOLTAGE & POWER CORD CHART DANGER Units with plugs are supplied with approximately 6ft (183cm) cords. Check all wiring connections, including factory terminals, before operation. Connections can become Models 406P and 407P may be stacked using a stacking loose during shipment and installation. -
Page 8: Refrigeration
All manuals and user guides at all-guidesbox.com Installation Section 2 Refrigeration Drain Connections Model BTU/Hour Heat of Refg Charge Warning Capacity Rejection If a refrigerated base does not have a condensate 402P 1276 68g R290 evaporator supplied, you must connect the condensate 403P 68g R290 line to a suitable drain. -
Page 9: Leg Leveling
3.40” All manuals and user guides at all-guidesbox.com (86mm) 3.40” Section 2 Installation (86mm) 4. Repeat step 3 with the non-locking casters or legs in CASTER AND LEG MOUNTING DETAIL the rear of the unit. A universal bolt hole pattern is provided on the bottom of the cabinet. - Page 10 All manuals and user guides at all-guidesbox.com Installation Section 2 THIS PAGE INTENTIONALLY LEFT BLANK Part Number: 9294045C 03/22...
- Page 11 All manuals and user guides at all-guidesbox.com Section 2 Installation THIS PAGE INTENTIONALLY LEFT BLANK Part Number: 9294045C 03/22...
-
Page 12: Operation
All manuals and user guides at all-guidesbox.com Section 3 Operation Warning DANGER The on-site supervisor is responsible for ensuring that The operator of this equipment is solely responsible for ensuring safe holding temperature levels for all operators are made aware of the inherent dangers of food items. -
Page 13: Controls/Programming/Settings
All manuals and user guides at all-guidesbox.com Section 3 Operation Electronic Temperature Control Location & Adjustment Ed: Defrost ended on timeout rather than by temperature Controls/Programming/Settings R290 REFRIGERATORS The control will initiate a defrost at start up. This defrost will continue up to 41°F or a minimum runtime of 1 minute/ maximum runtime of 75 minutes. -
Page 14: Freezers
All manuals and user guides at all-guidesbox.com Operation Section 3 FREEZERS Freezer Automatic Defrost Plug the unit in to begin operation. At initial start-up or The control is set to defrost every 5 hours. The maximum anytime power is disconnected, then reconnected to the defrost duration is 35 minutes. -
Page 15: Maintenance
All manuals and user guides at all-guidesbox.com Section 4 Maintenance Warning DANGER It is the responsibility of the equipment owner to When cleaning interior and exterior of unit, care should be taken to avoid the front power switch and the rear perform a Personal Protective Equipment Hazard power cord. -
Page 16: Interior Cleaning
All manuals and user guides at all-guidesbox.com Maintenance Section 4 Interior Cleaning Cleaning the Condenser Coil The interior can be cleaned using soap and warm water. If In order to maintain proper refrigeration performance, the this isn’t sufficient, try ammonia and water or a nonabrasive condenser fins must be cleaned of dust, dirt and grease liquid cleaner. -
Page 17: Troubleshooting
All manuals and user guides at all-guidesbox.com Section 5 Troubleshooting Problem -> Cause -> Correction Chart Problem Cause Correction Cabinet not Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker. running Power cord unplugged. Plug in power cord. Thermostat set too high. -
Page 18: Wiring Diagrams
All manuals and user guides at all-guidesbox.com Troubleshooting Section 5 406P and 4048P Wiring Diagram Part Number: 9294045C 03/22... - Page 19 All manuals and user guides at all-guidesbox.com Section 5 Troubleshooting 407P Wiring Diagram Part Number: 9294045C 03/22...
- Page 20 All manuals and user guides at all-guidesbox.com DELFIELD 980 SOUTH ISABELLA ROAD, MOUNT PLEASANT, MI 48858 800-733-8821 WWW.DELFIELD.COM ©2019 Welbilt Inc. except where explicitly stated otherwise. All rights reserved. Part Number 9294045C 03/22...
