LENCO DVP-706 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

ENGLISH
PORTABLE DVD PLAYER
PORTABLE DVD PLAYER
PORTABLE DVD PLAYER
OWNER`S MANUAL
OWNER`S MANUAL
OWNER`S MANUAL
OWNER`S MANUAL
Please read this manual before operating
DVP-706

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVP-706 and is the answer not in the manual?

Questions and answers

Related Manuals for LENCO DVP-706

Summary of Contents for LENCO DVP-706

  • Page 1 ENGLISH PORTABLE DVD PLAYER PORTABLE DVD PLAYER PORTABLE DVD PLAYER OWNER`S MANUAL OWNER`S MANUAL OWNER`S MANUAL OWNER`S MANUAL DVP-706 Please read this manual before operating...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents...................................1 Safety Information..................................2 Remote Control..................................3 Description of the DVD Player..............................4 Using the Remote Control...............................5 Connecting Earphones (Optional Accessory)..........................6 Connecting to a TV.................................7 Using USB Port..................................8 Using the AC Adaptor................................9 Charging the battery pack ..............................10 Playing a Disc.................................11-13 Playing MP3 and Regular Audio CD............................14 Playing Picture CD................................15 Displaying and Sorting Files..............................16...

  • Page 4: Safety Information

    Safety Information Please read all of the safety and operating instructions before operating this Player, follow all warnings placed on the Player and in the user's manual. These safety and operating instructions should be retained for future reference. Safety Information Do not expose the system to excessive moisture, rain, sand, or heat sources.

  • Page 5: Remote Control

    Remote Control Remote Control 14. DVD/USB Button 1. MENU/PBC/LCD Button Switches between DVD and USB Brings up the disc menu and adjusts mode. screen 15. DISPLAY Button 2. L/R Button Displays the current disc playback Selects left, right and stereo information.

  • Page 6: Description Of The Dvd Player

    Description of the DVD Player ENTER ENTER DVD / USB MENUL CD OP EN USB slot 9. AUDIO (LEFT) OUTPUT 17. MENU/LCD: Short press the button for MENU, long press for LCD adjustment 2. LED light 10. Earphone jack 18. PLAYBACK BUTTONS PLAY/PAUSE 3.

  • Page 7: Using The Remote Control

    Using the Remote Control Installing the battery Using the remote control 1. Open the battery compartment cover using a coin. Point the remote control directly at the remote sensor on the front of the DVD Player. 2. Insert a 3V lithium battery into the battery compartment with the polarity ( + ) facing up as marked.

  • Page 8: Connecting Earphones (Optional Accessory)

    Connecting Earphones (Optional Accessory) You can attach an earphone with a stereo mini-jack plug to the phone jack ( ) for private listening. The volume can be adjusted using VOL + and VOL - on the remote control or on the Player . Note: When the earphone is connected to the Phone Jack ( ), the speaker will be disconnected.

  • Page 9: Connecting To A Tv

    Connecting to a TV You can enjoy DVD quality video on TV screen. 1. Turn off DVD player and TV. 2. Connect the audio and video cables as illustrated. 3. Slide AV OUT ON/OFF to ON. The screen displays " LCD OFF 3" and the screen turns off in 3 seconds. 4.

  • Page 10: Using Usb Port

    Using USB Port The player accepts most USB devices such as MP3, DSC, USB- drive, Digital Camcorder etc. The USB in this Player supports version 1.1/2.0. USB slot Connecting a USB device 1. Plug in the USB device to the USB port on the player. 2.

  • Page 11: Using The Ac Adaptor

    Using the AC Adaptor This portable DVD player can be powered by AC through the supplied switching power AC adaptor. It can also use the supplied battery pack. When the AC adaptor is connected to the unit and powered, the unit will be automatically disconnected electrically from the battery pack and powered by the AC power.

  • Page 12: Charging The Battery Pack

    Charging the battery pack Charging the battery pack This PLAYER has a built-in rechargeable battery, follow these steps to recharge. 1. Connect the A.C adaptor as illustrated. 2. Slide POWER to OFF. ( The Player must be turned off to charge the battery). 3.

  • Page 13: Playing A Disc

    Playing a Disc Preparation for Playback 1. Press STOP ( ), the Player remembers where you stopped. 2. To resume, press PLAY, the Player will play from where you 1. Make sure the Player has the power either from the battery stopped.
  • Page 14 Playing a Disc pressing to start playing the bookmarked scene. The Slow Motion Playback continues until the end of the disc. Repeat the above to play the other marked scenes. 1.During playback, repeatedly press SLOW to play at 1/2, 1/4, 1/8, 1/16, 1/32 speeds.
  • Page 15 Playing a Disc TITLE Mute Press TITLE, it takes you to the very beginning of the title and Press MUTE to silence the audio, press MUTE again to restore play, or to the MENU if it has title menu. Displaying disc's MENU/PCB DISPLAY During DVD playback, press MENU/PBC/LCD to return to the Repeatedly press DISPLAY during playback to display various...

  • Page 16: Playing Mp3 And Regular Audio Cd

    Playing MP3 and Regular Audio CD Valid MP3 CD Your MP3 files should be ISO 9660 or JOLIET format. Play In most cases, when MP3 or audio disc is placed into the player, the first song file of the first folder plays. In other cases, the file manager appears.

  • Page 17: Playing Picture Cd

    Playing Picture CD Valid Picture Rotate The player can play both Kodak Picture CD that you order from The picture can be rotated and flipped. photo processing store, and home-made CD by burning JPEG 1.During playback, use direction keys ( ) to files onto a CD-R or CD-RW disc.

  • Page 18: Displaying And Sorting Files

    Displaying and Sorting Files Sorting files Displaying files You can list the file in the order according to its type, name or When a disc or USB device contains multiple file types, you date. can select and display only certain file types. 1.

  • Page 19: Setting Language For Osd, Menu, Audio, Subtitle

    Setting Language for OSD, Menu, Audio, Subtitle 1. Press SETUP on the remote control. Changing voice language 2. Use the direction keys ( ) to select Language Setup and its sub-menu. 3. Press to confirm your selection. Language Setup 4. Press SETUP to exit. English Menu Chinese...

  • Page 20: Setting Screen For Display Format, Screen Saver, Tv System

    Setting Screen for Display Format, Screen Saver, TV System 1. Press SETUP on the remote control. Turning on/off screen saver 2. Use the direction keys ( ) to select Screen Setup and its sub-menu. 3. Press to confirm your selection. Screen Setup 4.

  • Page 21: Setting Audio For Downmix

    Setting Audio for Downmix 1. Press SETUP on the remote control. 2. Use the direction keys ( ) to select Audio Setup and its sub-menu. 3. Press to confirm your selection. 4. Press SETUP to exit. Changing Downmix Audio Setup Downmix Lo/Ro Lt/Rt...

  • Page 22: Setting Parental Control, Password, Camera Angle, Default

    Setting Parental Control, Password, Camera Angle, Default 1. Press SETUP on the remote control. Turning on/off camera angle 2. Use the direction keys ( ) to select Custom Setup and its sub-menu. When ON is selected, the player will display multi-angle mark 3.

  • Page 23: Adjusting Lcd Screen

    Adjusting LCD Screen You can adjust screen"s Brightness, Contrast, Color, as well as to reverse the screen image 180 degrees. Adjusting Brightness, Contrast and Color 1. Press and hold MENU/LCD (on the player) or MENU/PBC/LCD (on the remote control) for a few seconds to display the Adjustment Menu.

  • Page 24: Troubleshooting

    Troubleshooting If your DVD player dose not seem to be functioning properly, check the items below before you contact a service center. Symptom Check Power does not turn on Make sure the AC Power cord is securely plugged into an AC outlet. or suddenly turns off Turn the power off and then back on.
  • Page 25 Troubleshooting Symptom Check No sound Check the volume setting. If set to zero, turn up volume level. Check that the headphones are plugged into the PHONES and Audio jack. Speakers cannot be used in conjunction with the headphones. Battery won't charge Check if the DVD player is turned off.

  • Page 26: Specifications

    Specifications Power Requirements Input AC 100V~240V, 50/60 Hz, Output DC 12V General Power Consumption > 12 W Weight 894g (with battery) Dimensions 225mm ( W ) x 175.5mm ( D ) x 40.5mm ( H ) Operating T emperature Range +10 C~ +40 C Readable DVD, DVD-R, DVD+R, DVD-RW,DVD+RW, VCD, CD, HDCD, Picture CD, CD-R, CD-RW,...
  • Page 27 If at any time in the future you should need to dispose of this product please note that: Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.

This manual is also suitable for:

Dvp-806

Table of Contents
