ENGLISH

PORTABLE DVD PLAYER

OWNER`S MANUAL
MODEL NO :DVP-722
Please read this manual before operating
16:9 / 4:3
16:9 / 4:3
REVERSE
REVERSE
MODE
MODE
UP
UP
DOWN
DOWN
MPEG4
UNIVERSAL SERIAL BUS
E N T E R
SD/MMC/MS
CARD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVP-722 and is the answer not in the manual?

Questions and answers

Summary of Contents for LENCO DVP-722

  • Page 1: Portable Dvd Player

    ENGLISH PORTABLE DVD PLAYER OWNER`S MANUAL MODEL NO :DVP-722 Please read this manual before operating 16:9 / 4:3 16:9 / 4:3 REVERSE REVERSE MODE MODE DOWN DOWN E N T E R SD/MMC/MS CARD MPEG4 UNIVERSAL SERIAL BUS...
  • Page 3: Table Of Contents

    Table of Contents Table of Contents...1 Safety Information...2 Remote Control...3 Description...4 Using the Remote Control...5 Connecting Earphones to the DVD Player...6 Connecting to an External Component ...7 Connecting to a TV...8 Connecting to a Stereo Component...9 Using Card Reader ...10 Using USB Port ...11 Using the AC Adaptor...12...
  • Page 4: Safety Information

    Safety Information Please read all of the safety and operating instructions before operating this Player, follow all warnings placed on the Player and in the user's manual. These safety and operating instructions should be retained for future reference. Safety Information Do not expose the system to excessive moisture, rain, sand, or heat sources.
  • Page 5: Remote Control

    Remote Control Remote Control STANDBY MENU/PBC MUTE DISPLAY ANGLE LANGUAGE SUBTITLE TITLE SLOW ENTER SETUP REPEAT MARK GOTO ZOOM REMOTE CONTROL 1.MENU/PBC Button Brings up the disc menu. 2.L/R Button Selects left, right and stereo sound tracks. 3.P/N Button Selects PAL/NTSC TV systems. 4.TITLE Button 5.SUBTITLE Button Selects the subtitle's language.
  • Page 6: Description

    Description Front View 7.CURSOR(UP/DOWN/LEFT/ RIGHT), 1.(16:9/4:3)/REVERSE/MODE/ ENTER( DOWN/UP 8.MENU/PBC 2.OPEN 9.STOP 3.DISC COVER 10.PAUSE/STEP 4.LCD 11. PLAYBACK BUTTONS PLAY 5. LCD on/off switch FAST REVERSE FAST FORWARD 6.SPEAKER SKIP-FORWARD SKIP-PREVIOUS Left View 1.LED LIGHT 2.REMOTE CONTROL SENSOR 3.3-in-1 card slot 4.LED LIGHT 5.USB slot Right View...
  • Page 7: Using The Remote Control

    Using the Remote Control Installing the battery 1. Press the locking tab in the arrow direction. 2. Pull out the battery tray. 3. Insert a 3V lithium battery into the tray with the polarity ( + ) facing up as marked. 4.
  • Page 8: Connecting Earphones To The Dvd Player

    Connecting Earphones to the DVD Player You can attach an earphone with a stereo mini-jack plug to the phone jack ( using the VOLUME control dial. You can also connect a second earphone to the AUDIO OUT jack, but its volume cannot be adjusted.
  • Page 9: Connecting To An External Component

    Connecting to an External Component You can enjoy video from VCR or camcorder on your DVD player. 1. Turn off DVD player, VCR and other components. 2. Connect the audio and video cables as illustrated below. 3. Slide INPUT/OUTPUT to INPUT. 4.Turn on power.
  • Page 10: Connecting To A Tv

    Connecting to a TV You can enjoy DVD quality video on TV screen. 1. Turn off DVD player and other components. 2. Connect the audio and video cables as illustrated below. 3. Slide INPUT/OUTPUT to OUTPUT. 4.Turn on power. 5.Repeatedly press TV/Video button on your TV to select the input from the DVD player. TIPS If you wish to view video on your TV only, close the display panel of your Player.
  • Page 11: Connecting To A Stereo Component

    Connecting to a Stereo Component By connecting the digital output (SPDIF) on the DVD player through a coaxial cable (optional accessory) to a Dolby Digital/DTS amplifier or processor, you can enjoy full 5.1 channel surround sound. Follow these steps for making the connection. 1.Turn off both DVD player and your stereo system.
  • Page 12: Using Card Reader

    Using Card Reader The player has a 3-in-1 card reader, accepting MMC(Multimedia card), SD (Secure digital card) and MS (Memory stick). Inserting a memory card 1.Make sure that no disc is placed on the Player. 2.Insert the card into the slot with the gold contacts facing up. Gently push the card in all the way until the card is fixed in place.
  • Page 13: Using Usb Port

    Using USB Port The player accepts most USB devices such as MP3, DSC, USB- drive, Digital Camcorder etc. The USB in this player is version 2.0. Pluging a USB device 1.Remove the disc from the player. 2.Plug in the USB device to the USB port on the player. Removing a USB device You can remove the USB device anytime even it is playing.
  • Page 14: Using The Ac Adaptor

    Using the AC Adaptor This portable DVD player can be powered by AC through the supplied switching power AC adaptor. It can also use the supplied battery pack to power. When the AC adaptor is connected to the unit and powered, the unit will be automatically powered by the AC power.
  • Page 15: Using The Battery Pack

    Using the Battery Pack Installing the battery pack <1>.Align and insert the battery <2>.Slide the battery pack to the pack into the corresponding left until it clicks into place. slots on the back of the unit. Charging the battery pack 1.
  • Page 16: Cautions In Using Battery Pack

    Do not expose the battery pack to water, fire, or heat. Always use the included AC adaptor when charging the battery pack. This battery pack is designed exclusively for your portable DVD player. Do not use it with other devices. Warning! 1.
  • Page 17: Playing A Disc

    Playing a Disc Turning ON /OFF the player To Turn On The Player 1.Slide POWER on the Player to ON, this will put the Player on standby mode. 2.Press on the Player to turn on the power. 3.You can also press STANDBY on the remote control to turn on the power. To put the Player on standby mode Press STANDBY on the remote control.
  • Page 18: Fast Forward And Reverse

    Playing a Disc Resume This Player provides a unique resume function for making viewing movie more convenient. Follow these steps 1.When you want to interrupt the playback and come back later to play where you interrupted it, you can press OPEN on the Player to open the disc compartment cover.
  • Page 19: Repeat Playback

    Playing a Disc Repeat Playback You can play a chapter, a track, a title, a file or the entire disc repeatedly. 1.During playback, repeatedly press REPEAT to choose a Repeat option. Depending on the type of disc,the Repeat options may be different.
  • Page 20 Playing a Disc ZOOM 1.Press ZOOM repeatedly during playback or pause to enlarge (2X, 3x, 4x, ) or reduce (1/2, 1/3, 1/4) the image. 2.Use direction keys ( ) to move around (pan and scan) the enlarged image. MUTE 1. Repeatedly press MUTE until MUTE appears on the display to silence the audio. Press MUTE again to turn on audio. "...
  • Page 21: Playing A Disc

    Playing a Disc TITLE Press TITLE, it takes you to the very beginning of the title and play, or to the MENU if it has title menu. DISPLAY Repeatedly press DISPLAY during playback to display various playback information such as current title, chapter, track elapsed time, languages etc.
  • Page 22: Playing Mp3 And Regular Audio Cd

    Playing MP3 and Regular Audio CD Valid MP3 CD and CD-R/RW The MP3 files should be ISO9660 or Joliet format. Use mp3 as the file extension. " " Play In most cases, when a MP3 or CD is placed into the player, the first song file of the first folder palys. In other cases, the file manger appears.
  • Page 23: Playing Picture Cd

    Playing Picture CD Valid Picture The player can play both Kodak Picture CD that you order from photo processing store, and home-made CD by burning JPEG files onto a CD-R or CD-RW disc. Play In most cases, after the disc is placed into the player, the first file will be shown. In other cases, the file manger appears.
  • Page 24: Setting Tv System, Screen Saver, Tv Type (4:3/16:9), Password, Rating, Default

    Setting TV system, Screen Saver, TV type (4:3/16:9), Password, Rating, Default 1.Press SETUP on the remote control. 2.Use the direction keys to select SYSTEM SETUP and its sub-menu. 3.Press ENTER to confirm your selection. 4.Press SETUP to exit, or select EXIT SETUP to exit. STANDBY MENU/PBC DISPLAY...
  • Page 25: Setting Rating

    Setting TV system, Screen Saver, TV type (4:3/16:9), Password, Rating, Default STANDBY MENU/PBC DISPLAY MUTE Setting rating ANGLE LANGUAGE SUBTITLE TITLE SYSTEM SETUP SLOW TV SYSTEM ENTER SCREEN SAVER SETUP TV TYPE PASSWORD RATING DEFAULT REPEAT MARK GOTO ZOOM EXIT SETUP REMOTE CONTROL MODEL No.:RMC-221 1.Go to PASSWORD and enter the password to open the lock...
  • Page 26: Setting Language For Osd, Voice, Subtitle, Menu

    Setting Language for OSD, Voice, Subtitle, Menu Although this Player supports a list of different languages for OSD, subtitle and voice, the disc must have the specific language(s) builted-in in order to effect the multi-language function of this Player. 1.Press SETUP on the remote control. 2.Use the direction keys to select LANGUAGE SETUP and its sub-menu.
  • Page 27: Setting Audio Output

    Setting Audio Output 1.Press SETUP on the remote control. 2.Use the direction keys to select AUDIO SETUP and its sub-menu. 3.Press ENTER to confirm your selection. 4.Press SETUP to exit, or select EXIT SETUP to exit. STANDBY MENU/PBC DISPLAY MUTE Changing AUDIO output ANGLE LANGUAGE...
  • Page 28: Setting Video's Brightness, Contrast, Hue, Saturation

    Setting Video's Brightness, Contrast, Hue, Saturation 1.Press SETUP on the remote control. 2.Use the direction keys to select VIDEO SETUP and its sub-menu. STANDBY MENU/PBC 3.Press ENTER to confirm your selection. DISPLAY MUTE 4.Press SETUP to exit, or select EXIT SETUP to exit. ANGLE LANGUAGE SUBTITLE...
  • Page 29: Adjusting Lcd Screen

    Adjusting LCD Screen Following these steps to adjust the LCD quality during playback or while paused. 1.Repeatedly press MODE on the screen panel to select the parameters listed in the menu. You can change BRIGHTNESS, CONTRAST, SATURATION and HUE. 2.Repeatedly press (or hold down) UP and DOWN to change the setting of the parameter selected. 3.To reset the setting to its defaulted value, select RESET by repeatedly pressing MODE then press UP or DOWN to confirm.
  • Page 30: Troubleshooting

    Troubleshooting If your DVD player dose not seem to be functioning properly, check the items below before you contact a service center. Symptom Power does not turn on or suddenly turns off Battery pack is in place but the power does not turn on or suddenly turns off Remote control does not work Disc does not play...
  • Page 31 Troubleshooting Symptom While in the input mode, no picture is output from the external component to the DVD player Battery pack won't charge Charging LED indicator does not light On charging the depleted battery, the red and green LED charging indicators quickly light, indicating battery is fully charged, but in fact it is not...
  • Page 32: Specifications

    Specifications Power Requirements General Power Consumption Weight Dimensions Operating T emperature Range Readable Disc DVD, DVD-R, DVD+R, DVD-RW, VCD,SVCD,DVCD, MP3,PICTURE CD, CD, CD-G, HDCD, CD-R, CD-RW, MPEG4/DivX Readable USB DSC, Camcorder, U-drive, MP3 player, and other USB storage devices Readable Card SD/MMC/MS card Video Composite Video...
