ENGLISH

PORTABLE DVD PLAYER

OWNER`S MANUAL
MODEL NO :DVP-70
Please read this manual before operating

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVP-70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LENCO DVP-70

Summary of Contents for LENCO DVP-70

  • Page 1: Portable Dvd Player

    ENGLISH PORTABLE DVD PLAYER OWNER`S MANUAL MODEL NO :DVP-70 Please read this manual before operating...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents..................................1 Safety Information..................................2 Remote Control....................................3 Description ....................................4 Using the Remote Control ................................5 Connecting Earphones to the DVD Player.............................6 Connecting to an External Component ............................7 Connecting to a TV..................................8 Using the AC Adaptor...................................9 Using the Battery Pack................................10 Cautions in Using Battery Pack ..............................11 Playing a Disc..................................12-16...

  • Page 3: Safety Information

    Safety Information Please read all of the safety and operating instructions before operating this Player, follow all warnings placed on the Player and in the user's manual. These safety and operating instructions should be retained for future reference. Safety Information Do not expose the system to excessive moisture, rain, sand, or heat sources.

  • Page 4: Remote Control

    Remote Control 13.DISPLAY Button 1.L/R Button Remote Control Displays the current disc playback 2.P/N Button information. Selects PAL/NTSC TV systems. 14.MUTE Button 3.TITLE Button 15.ANGLE Button 4.SUBTITLE Button MENU/PBC Use to access various Selects the subtitle's language. REMOTE CONTROL MODEL No.:RMC-220 camera angles on a DVD.

  • Page 5: Description

    Description Right View Front View IN 12V INPU VIDE IO OUT IO IN UM E 1.LCD 8. LCD on/off switch 2. REVERSE DISPLAY 9.MENU/PBC Button 3.(16:9/4:3)/MODE/DOWN/UP 10.ENTER Button 6.INPUT / OUTPUT 1.OPEN 4.SPEAKER 11.DIRECTION Button(UP/DOWN/ 2.EARPHONE / SPEAKER VOLUME 7.VIDEO 5.DISC COVER LEFT/ RIGHT) 6.OPEN...

  • Page 6: Using The Remote Control

    Using the Remote Control Installing the battery Using the remote control Point the remote control directly at the remote sensor on the front of the DVD Player. 1. Press the locking tab in the arrow direction. 2. Pull out the battery tray. 3.

  • Page 7: Connecting Earphones To The Dvd Player

    Connecting Earphones to the DVD Player You can attach an earphone with a stereo mini-jack plug to the phone jack ( ) for private listening. Its volume is adjustable using the VOLUME control dial. You can also connect a second earphone to the AUDIO OUT jack, but its volume cannot be adjusted.

  • Page 8: Connecting To An External Component

    Connecting to an External Component You can enjoy video from VCR or camcorder on your DVD player. 1. Turn off DVD player, VCR and other components. 2. Connect the audio and video cables as illustrated below. 3. Slide INPUT/OUTPUT to INPUT. 4.

  • Page 9: Connecting To A Tv

    Connecting to a TV You can enjoy DVD quality video on TV screen. 1. Turn off DVD player and TV. 2. Connect the audio and video cables as illustrated below. 3. Slide INPUT/OUTPUT to OUTPUT. 4.Turn on DVD player and TV. 5.

  • Page 10: Using The Ac Adaptor

    Using the AC Adaptor This portable DVD player can be powered by AC through the supplied switching power AC adaptor. It can also use the supplied battery pack to power. When the AC adaptor is connected to the unit and powered, the unit will be automatically and electrically disconnected from the battery pack and powered by the AC power.

  • Page 11: Using The Battery Pack

    Using the Battery Pack Installing the battery pack Align and insert the battery pack into the Slide the battery pack to the left until it clicks into place. corresponding slots on the back of the unit. Removing the battery pack Slide down the latch.

  • Page 12: Cautions In Using Battery Pack

    Cautions in Using Battery Pack Danger! Strictly follow these safety information when using the battery pack. Otherwise, a short circuit, overheating, smoke, fire, or damage to the product may result. Never disassemble or modify the battery pack in any way. Do not touch the terminal of the battery pack with a metal object. Do not place the battery pack in direct sunlight, dashboard of a vehicle, or high temperature place.

  • Page 13: Playing A Disc

    Playing a Disc Preparation for Playback 1.Make sure the unit has the power either from the battery pack or the AC adaptor. 2.Loading a disc, following these steps: Open the top cover by pushing the latch to the right and lift the top cover. Press the OPEN button to open the disc lid.
  • Page 14 Playing a Disc Skip You can skip chapters on DVD-Video, tracks on CDs, and Video CDs. 1.To skip forward, press during play or while paused; it skips to the next chapter or track. Each press increases the numbers of skips. 2.To skip to previous chapter or track, press twice.
  • Page 15 Playing a Disc Mark (Bookmark) You can playback from a certain point using the MARK function. 1.During playback, press MARK to mark the point at which you want to start the playback. 2.At any time, when MARK is pressed again, it starts to playback from the marked point. GOTO GOTO lets you choose a specific elapsed playing time or a desired Chapter/Title/Track to begin playback.
  • Page 16 Playing a Disc Mute Press MUTE to silence the audio, press MUTE again to restore it. Menu/PBC During DVD playback, press MENU/PBC to return to the disc's Start Menu. If the disc does not have the Start Menu, or discs that refuse MENU function, appears.

  • Page 17: Playing A Disc

    Playing a Disc Display Press DISPLAY during DVD playback to display playback information such as current title, chapter, track, elapsed time etc. Press DISPLAY again to show additional information such as audio channels, TV system, language etc. Press DISPLAY again to remove information. Audio Channel When playing CD or VCD, repeatedly press L/R to change the sound output to Stereo, left/left, right/right Turn Off The Player...

  • Page 18: Playing Picture Cd

    Playing Picture CD Valid Picture CD The player can play both Kodak Picture CD that you order from photo processing store, and home-made CD by burning JPEG files onto a CD-R or CD-RW disc. Play In most cases, after the disc is placed into the player, the player will start to slide show automatically. In other cases, the file manager appears.

  • Page 19: Playing Mp3 And Regular Audio Cd

    Playing MP3 and Regular Audio CD Valid MP3 CD Your MP3 files should be ISO 9660 or JOLIET format. Play In most cases, when a MP3 or audio disc is placed into the player, the first song file of the first folder plays. In other cases, the file manager appears.

  • Page 20: Setting Language For Osd,Menu, Voice, Subtitle

    REMOTE CONTROL MODEL No.:RMC-220 DISPLAY MUTE ANGLE LANGUAGE SUBTITLE TITLE Setting Language for OSD,Menu, Voice, Subtitle 1. Press SETUP on the remote control. Changing voice language SETUP 2. Use the direction keys ( ) to select Language Language Setup SLOW Setup and its sub-menu.

  • Page 21: Setting Screen And Audio

    MENU/PBC REMOTE CONTROL MODEL No.:RMC-220 DISPLAY MUTE Setting Screen and Audio ANGLE LANGUAGE SUBTITLE TITLE Selecting TV system 1. Press SETUP on the remote control. SETUP Screen Setup 2. Use the direction keys ( ) to select Screen Setup SLOW ENTER TV Type NTSC...

  • Page 22: Setting Parental Control, Password, Camera Angle

    Setting Parental Control, Password, Camera Angle MENU/PBC REMOTE CONTROL MODEL No.:RMC-220 MUTE DISPLAY ANGLE LANGUAGE SUBTITLE TITLE Turning on/off camera angle 1. Press SETUP on the remote control. 2. Use the direction keys ( ) to select Custom Setup MENU/PBC and its sub-menu.

  • Page 23: Adjusting Lcd Screen

    Adjusting LCD Screen Following these steps to adjust the LCD quality during playback or while paused, 1.Repeatedly press MODE on the screen panel to select the parameters listed in the menu. You can change BRIGHTNESS, CONTRAST, SHARPNESS, COLOR and TINT. 2.Repeatedly press (or hold down) UP and DOWN to change the setting of the parameter selected.

  • Page 24: Troubleshooting

    Troubleshooting If your DVD player dose not seem to be functioning properly, check the items below before you contact a service center. Symptom Check Power does not turn on Make sure the AC Power cord is securely plugged into an AC outlet. or suddenly turns off Turn the power off and then back on.

  • Page 25: Troubleshooting

    Troubleshooting Symptom Check While in the input mode, no picture is Check that the video or audio cable is securely connected. output from the external component to the DVD player Check that the DVD player is in the INPUT mode and in the DVD mode. Battery pack won't charge Check that the DVD player is turned off.

  • Page 26: Specifications

    Specifications Power Requirements Input AC 100V~240V, 50/60 Hz, Output DC 12V General Power Consumption > 15 W Weight 913.5g (without battery pack) Dimensions 206mm ( W ) x 158.5mm ( D ) x 39.7mm ( H ) Operating T emperature Range +10 C~ +40 C Readable DVD, DVD-R, DVD+R, DVD-RW,...
