Summary of Contents for LENCO DVP-74
- Page 1 ENGLISH PORTABLE DVD PLAYER PORTABLE DVD PLAYER PORTABLE DVD PLAYER OWNER`S MANUAL OWNER`S MANUAL OWNER`S MANUAL OWNER`S MANUAL Please read this manual before operating...
-
Page 3: Table Of Contents
Table of Contents Table of Contents...................................1 Safety Information..................................2 Remote Control..................................3 Description....................................4 Using the Remote Control...............................5 Connecting Earphones (Optional Accessory)..........................6 Connecting to a TV.................................7 Using USB Port..................................8 Using the AC Adaptor................................9 Using the Battery Pack................................10 Cautions in Using Battery Pack..............................11 Installing Carrying Bag/Car Harness Kit(Optional Accessory)....................12 Playing a Disc.................................13-15 Playing MP3 and Regular Audio CD............................16 Playing Picture CD................................17... -
Page 4: Safety Information
Safety Information Please read all of the safety and operating instructions before operating this Player, follow all warnings placed on the Player and in the user's manual. These safety and operating instructions should be retained for future reference. Safety Information Do not expose the system to excessive moisture, rain, sand, or heat sources. -
Page 5: Remote Control
Remote Control Remote Control 14.DVD/USB Button 1.MENU/PBC Button Switches between DVD and USB Brings up the disc menu. mode. 2.L/R Button 15.DISPLAY Button Selects left, right and stereo Displays the current disc playback sound tracks. information. 3.P/N Button 16.MUTE Button Selects PAL/NTSC/AUTO TV systems. -
Page 6: Description
Description Right View Front View 1.OPEN 7.MENU/PBC 2.DISC COVER 8.SETUP/LCD adj. 3.LCD 9.DVD/USB 4.SPEAKER 10.STOP 1.EARPHONE JACK 4.VIDEO OUTPUT 5.LCD on/off switch 11.PLAYBACK BUTTONS 2.DC IN 12V 5.AUDIO OUTPUT (RIGHT) FAST REVERSE/SKIP-PREVIOUS 6.CURSOR(UP/DOWN/LEFT/ RIGHT), FAST FORWARD/SKIP-FORWARD ENTER( 3.POWER ON/OFF 6.AUDIO OUTPUT (LEFT) VOL+ VOL- Left View... -
Page 7: Using The Remote Control
Using the Remote Control Installing the battery Using the remote control Point the remote control directly at the remote sensor 1. Press the locking tab in the arrow direction. on the front of the DVD Player. 2. Pull out the battery tray. 3. -
Page 8: Connecting Earphones (Optional Accessory)
Connecting Earphones (Optional Accessory) You can attach an earphone with a stereo mini-jack plug to the phone jack ( ) for private listening. The volume can be adjusted using VOL + and VOL - on the remote control or on the Player . Note: When the earphone is connected to the Phone Jack ( ), the speaker will be disconnected. -
Page 9: Connecting To A Tv
Connecting to a TV You can enjoy DVD quality video on your TV screen. 1. Turn off DVD player and TV. 2. Connect the audio and video cables as illustrated below. 3.Turn on DVD player and TV. 4.Repeatedly press TV/Video button on your TV to select the input from the DVD player. AUDIO IN VIDEO IN Video out: Yellow... -
Page 10: Using Usb Port
Using USB Port The player accepts most USB devices such as MP3, DSC, USB- drive, Digital Camcorder etc. The USB in this Player supports version 1.1/2.0. USB slot Pluging a USB device 1.Plug in the USB device to the USB port on the player. 2.Repeatedly press DVD/USB to select USB mode. -
Page 11: Using The Ac Adaptor
Using the AC Adaptor This portable DVD player can be powered by AC through the supplied switching power AC adaptor. It can also use the supplied battery pack to power. When the AC adaptor is connected to the unit and powered, the unit will be automatically and electrically disconnected from the battery pack and powered by the AC power. -
Page 12: Using The Battery Pack
Using the Battery Pack Installing the battery pack Removing the battery pack <1>.Align and insert the battery <2>.Slide the battery pack to the <1>.Slide down the latch. <2>.Slide the battery pack to the pack into the corresponding left until it clicks into place. right, and remove. -
Page 13: Cautions In Using Battery Pack
Cautions in Using Battery Pack Danger! Strictly follow these safety information when using the battery pack, Otherwise, a short circuit, overheating, smoke, fire, or damage to the product may result. Never disassemble or modify the battery pack in any way. Do not touch the terminal of the battery pack with a metal object. Do not place the battery pack in direct sunlight, dashboard of a vehicle, or high temperature place. -
Page 14: Installing Carrying Bag/Car Harness Kit(Optional Accessory)
Installing Carrying Bag/Car Harness Kit(Optional Accessory) You can install the Carrying case/Car harness kit to a car seat to enjoy the movie in the car. Following these steps: Insert the player into the bag and place Open the cover of the player and place Unzip the carrying bag and flip the elastic strap over the battery pack. -
Page 15: Playing A Disc
Playing a Disc Preparation for Playback Resume 1.Make sure the Player has the power either from the battery pack When you press or STOP, the player remembers where you or the AC adaptor. stopped, and when you press PLAY later, it will play from where 2.Load a disc, following these steps: you stopped it. - Page 16 Playing a Disc pressing to start playing the bookmarked scene. The Slow Motion Playback continues until the end of the disc. Repeat the above to play the other marked scenes. 1.During playback, repeatedly press SLOW to play at 1/2, 1/4, 1/8, 1/16, 1/32 speeds.
-
Page 17: Playing A Disc
Playing a Disc Mute TITLE Press MUTE to silence the audio, press MUTE again to restore Press TITLE, it takes you to the very beginning of the title and play, or to the MENU if it has title menu. Menu/PBC DISPLAY During DVD playback, press MENU/PBC to return to the disc's Start Menu. -
Page 18: Playing Mp3 And Regular Audio Cd
Playing MP3 and Regular Audio CD Valid MP3 CD Your MP3 files should be ISO 9660 or JOLIET format. Play In most cases, when a MP3 or audio disc is placed into the player, the first song file of the first folder plays. In other cases, the file manager appears. -
Page 19: Playing Picture Cd
Playing Picture CD Valid Picture Rotate The player can play both Kodak Picture CD that you order from The picture can be rotated and flipped. photo processing store, and home-made CD by burning JPEG 1.During playback, use direction keys ( ) to files onto a CD-R or CD-RW disc. -
Page 20: Displaying And Sorting Files
Displaying and Sorting Files Sorting files Displaying files You can list the file in the order according to its type, name or When a disc or USB device contains multiple file types, you date. can select and display only certain file types. 1. -
Page 21: Setting Language For Osd, Menu, Audio, Subtitle
Setting Language for OSD, Menu, Audio, Subtitle 1. Press SETUP on the remote control. Changing voice language 2. Use the direction keys ( ) to select Language Setup and its sub-menu. 3. Press to confirm your selection. Language Setup 4. Press SETUP to exit. English Menu Chinese... -
Page 22: Setting Screen For Display Format, Screen Saver, Tv System
Setting Screen for Display Format, Screen Saver, TV System 1. Press SETUP on the remote control. Turning on/off screen saver 2. Use the direction keys ( ) to select Screen Setup and its sub-menu. 3. Press to confirm your selection. Screen Setup 4. -
Page 23: Setting Audio For Downmix
Setting Audio for Downmix 1. Press SETUP on the remote control. 2. Use the direction keys ( ) to select Audio Setup and its sub-menu. 3. Press to confirm your selection. 4. Press SETUP to exit. Change Downmix Audio Setup Downmix Lo/Ro Lt/Rt... -
Page 24: Setting Parental Control, Password, Camera Angle, Default
Setting Parental Control, Password, Camera Angle, Default 1. Press SETUP on the remote control. Turning on/off camera angle 2. Use the direction keys ( ) to select Custom Setup and its sub-menu. When ON is selected, the player will display multi-angle mark 3. -
Page 25: Adjusting Lcd Screen
Adjusting LCD Screen You can adjust screen"s Brightness, Contrast, Color, as well as to reverse the screen image 180 degrees. 1. Press and hold SETUP/LCD adj . to display the menu. 2. Use to select the Brightness ( ), Contrast ( ),Color( ), and use to make the adjustment, Press ENTER to confirm.. -
Page 26: Troubleshooting
Troubleshooting If your DVD player dose not seem to be functioning properly, check the items below before you contact a service center. Symptom Check Power does not turn on Make sure the AC Power cord is securely plugged into an AC outlet. or suddenly turns off Turn the power off and then back on. - Page 27 Troubleshooting Symptom Check No sound Check the volume setting. If set to zero, turn up volume level. Check that the headphones are plugged into the PHONES and Audio jack. Speakers cannot be used with the headphones. Battery pack won't charge Check that the DVD player is turned off.
-
Page 28: Specifications
Specifications Power Requirements Input AC 100V~240V, 50/60 Hz, Output DC 12V General Power Consumption > 12 W Weight 835g (without battery pack) Dimensions 206mm ( W ) x 158.5mm ( D ) x 41.5mm ( H ) Operating T emperature Range +10 C~ +40 C Readable DVD, DVD-R, DVD+R, DVD-RW,DVD+RW, VCD, CD, HDCD, Picture CD, CD-R, CD-RW,...
