- Page 1 EWF 80121 A Washing Machine User’s Manual...
- Page 2 1 General safety instructions • While there is still water inside the product, never open the This section includes security loading door or remove the filter. instructions which may help prevent Otherwise, risk of flooding and the injuries and material damage risks. injury from hot water will occur.
- Page 3 1.3 Children’s safety CAUTION! • Do not forget to close the CAUTION! loading door when leaving the • This product can be used by room where the product is the children who are at the located. age of 8 and over and the •...
- Page 4 2. Important instructions for DANGER! environment • Plug the product into a 2.1 Compliance with WEEE Directive grounded outlet protected by This product complies with EU a 16 A fuse. Do not neglect to WEEE Directive (2012/19/EU). This product bears a classification have the grounding installation symbol for waste electrical and made by a qualified electrician.
- Page 5 Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark ELBA Model name EWF 80121 A Rated capacity (kg) Height (cm) Width (cm) Depth (cm) Net weight (±4 kg.) Single Water inlet / Double Water inlet • • Available...
- Page 6 4.1 Installation 4.1.3 Removing the transportation locks • Apply to the nearest authorised service agent for the installation of your product. 1 Loosen all bolts with an appropriate wrench until they turn freely. • Preparation of the location and electrical, tap water and waste water installations at 2 Remove the transport safety bolts by the place of installation is under customer's turning them slightly.
- Page 7 • In case the drain hose is elevated after laying it on the floor level or close to the ground (less than 40 cm above the ground), water discharge becomes more difficult and the laundry may come out excessively wet. Therefore, follow the heights described in the figure. •...
- Page 8 4.2 Preparation 4.1.7 Electrical connection Connect the product to a grounded outlet 4.2.1 Sorting the laundry protected by a 16 A fuse. Our company shall * Sort laundry according to type of fabric, not be liable for any damages that will arise color, and degree of soiling and allowable when the product is used without grounding in water temperature.
- Page 9 • Operate the product in the highest The detergent drawer capacity allowed by the programme you have selected, but do not overload; see, is composed of three "Programme and consumption table". See, compartments: “Programme and consumption table" – (1) for prewash • Always follow the instructions on the – (2) for main wash detergent packaging. – (3) for softener •...
- Page 10 • Do not use amounts exceeding the dosage not use liquid detergent. quantities recommended on the detergent Using gel and tablet detergent package to avoid problems of excessive • If the gel detergent thickness is fluidal and foam, poor rinsing, financial savings and your machine does not contain a special liquid finally, environmental protection.
- Page 11 4.2.7 Tips for efficient washing Clothes Light Colours and Black/Dark Delicates/ Colours Whites Colours Woolens/Silks (Recommended (Recommended (Recommended (Recommended temperature temperature range based temperature range temperature range based range based on on soiling level: cold-40 based on soiling on soiling level: 40-90 oC) soiling level: cold level: cold -30 oC) -40 oC)
- Page 12 4.3 Operating the product 1 - Programme Selection Knob (Uppermost position On / Off) 4.3.1 Control panel 2 - Display 3 - End Time Adjustment Button 4 - Programme Follow-up Indicator 5 - Start/Pause Button 1200 90° 60° 1000 6 - Auxiliary Function Button 3 40°...
- Page 13 4.3.5 Main programmes • : Selectable Depending on the type of fabric, use the * : Automatically selected, cannot be cancelled. following main programmes. ***: If the maximum spin speed of the machine • Cottons is lower, you can select values up to the You can wash your durable cotton laundry maximum spin speed value.
- Page 14 • Shirts • Hygiene This programme is used to wash the shirts Applying a steam step at the beginning of the made from cotton, synthetic and synthetic programme allows to soften the dirt easily. Use blended fabrics altogether. It reduces wrinkles. this programme for your laundry (baby clothes, Steam is applied at the end of the programme bed sheets, bedlinen, underwear, etc.
- Page 15 INFORMATION • the automatic stain programme, you can wash 24 types of stains divided into two • Use a lower spin speed for different groups according to quick function delicate laundries. selection. You can see stain groups based on the selection of the quick function. 4.3.8 Temperature selection You can find stain groups based on quick Whenever a new programme is selected, the...
- Page 16 • PHR INFORMATION This function helps to remove pet hair that remain on your garments more effectively. • If the programme has not reached When you select this function, Prewash and the spin step, you can change Extra Rinse steps are added to the normal the spin speed without switching programme.
- Page 17 To enable Child Lock: to set the end time of the programme up to 19 Press and hold the Auxiliary Function button 2 hours. You can increase this time by 1-hour for 3 seconds. While you’re holding the button intervals. pressed for 3 seconds, C03, C02 and C01 will INFORMATION be displayed respectively.
- Page 18 of the machine that prevents opening of the 2. Then, select the programme you want to loading door in cases when the water level is run again. unsuitable. 3. Press Start/Pause button to start the programme. machine is switched to Pause mode. The 4.3.12 Starting the programme machine checks the level of the water inside.
- Page 19 4.4 Maintenance and cleaning 4.3.16 Cancelling the programme To cancel the programme, turn the Programme Service life of product extends and frequently Selection knob to select another programme. experienced problems will be reduced if it is Previous programme will be cancelled. End/ cleaned at regular intervals.
- Page 20 4.4.5 Draining remaining water If the holes on the bellow shown in the figure is blocked, open the holes using a toothpick. and cleaning the pump filter The filter system in your machine prevents INFORMATION solid items such as buttons, coins and fabric fibers clogging the pump impeller during •...
- Page 21 5 Troubleshooting 3 Follow the below procedures in order to drain water. Program does not start after closing the door. • Start / Pause / Cancel button was not pressed. >>>*Press The product does not have an emergency the Start / Pause / Cancel button. water drain hose, in order to drain the water: •...
- Page 22 Machine directly discharges the water it takes in. Machine does not switch to spinning step. (*) • Draining hose might not be at adequate height. • There might be unbalanced load in the machine. >>>Connect the water draining hose as described in the >>>Automatic unbalanced load detection system might operation manual.
- Page 23 Colour of the clothes faded. (**) • There is a problem with the detergent drawer valves. >>>Call the Authorised Service Agent. • Excessive laundry was loaded in. >>>Do not load the • Detergent might be mixed with the softener. >>>Do not machine in excess.
- Page 24 WARRANTY & SERVICE To activate your warranty, please register your appliance. Warranty registration can be done via our website or scan the QR code below Website https://shop.casa.sg/E-Warranty QR Code Scan the QR Code below. It will redirect straight to our “Warranty Registration” page. Casa (S) Pte Ltd.
