- Page 1 EWF 1076 A Washing Machine User’s Manual Document Number 2820522174_EN/ 030113.1704...
-
Page 2: Important Safety Instructions
1 Important safety instructions • Never touch the plug with wet hands! Never unplug by pulling on the cable, always pull out This section contains safety instructions that will by grabbing the plug. help protect from risk of personal injury or property • Use detergents, softeners and supplements damage. Failure to follow these instructions shall suitable for automatic washing machines only. -
Page 3: Appropriate Installation Location
Make sure that the water inlet and discharge If you want to use both water inlets of the hoses as well as the power cable are not product, connect the hot water hose after folded, pinched or crushed while pushing removing the stopper and gasket group from the product into its place after installation or the hot water valve. -
Page 4: Adjusting The Feet
situations and to ensure smooth water intake and discharge of the machine, fix the end of the discharge hose tightly so that it cannot come out. • The hose should be attached to a height of at least 40 cm, and 100 cm at most. • In case the hose is elevated after laying it on the floor level or close to the ground (less than 40 cm above the ground), water discharge becomes more difficult and the laundry may come out excessively wet. - Page 5 3 Preparation To prepare the product for washing laundry, perform first operation in Drum Cleaning Things to be done for energy saving programme. If your machine is not featured with Following information will help you use the product Drum Cleaning programme, use Cottons-90 in an ecological and energy-efficient manner. programme and select Additional Water or Extra • Operate the product in the highest capacity Rinse auxiliary functions as well. Before starting allowed by the programme you have selected, the programme, put max. 100 g of powder but do not overload;...
-
Page 6: Correct Load Capacity
This will reduce pilling. ball. Place the detergent bag or the • Laundry that are subjected to materials such dispensing ball directly among the laundry in as flour, lime dust, milk powder, etc. intensely the machine. must be shaken off before placing into the • If you are using liquid detergent, do not forget machine. - Page 7 • Do not use bleaching agent and detergent by mixing them. • Use just a little amount (approx. 50 ml) of bleaching agent and rinse the clothes very well as it causes skin irritation. Do not pour the bleaching agent onto the clothes and do not use it for coloured clothes. • When using oxygen based bleaches, If the product does not contain a liquid follow the instructions on the package and detergent cup: select a programme that washes at a lower •...
-
Page 8: Tips For Efficient Washing
Tips for efficient washing Clothes Light colours and Delicates/ Colors Dark colors whites Woolens/Silks (Recommended (Recommended (Recommended (Recommended temperature range temperature range temperature range temperature range based based on soiling level: based on soiling based on soiling on soiling level: cold-40C) 40-90C) level: cold-40C) level: cold-30C) It may be necessary to pre-treat the... -
Page 9: Operating The Product Control Panel
4 Operating the product Control panel 1 - Programme Selection knob (Uppermost 5 - Auxiliary Function buttons position On/Off) 6 - Delayed Start button (in some models) 2 - Programme Follow-up indicator 7 - Start / Pause button 3 - Temperature Adjustment button 4 - Spin Speed adjustment button Preparing the machine When selecting a programme, always Make sure that the hoses are connected tightly. consider the type of fabric, colour, degree of Plug in your machine. Turn the tap on completely. soiling and permissible water temperature. -
Page 10: Additional Programmes
• Woollens If you wish to drain only the water without spinning Use this programme to wash your woolen clothes. your laundry, select the Pump+Spin programme Select the appropriate temperature complying and then select the No Spin function with the help with the tags of your clothes. Use appropriate of Spin Speed Adjustment button. Press Start / detergents for woolens. Pause button. Additional programmes Use a lower spin speed for delicate laundries. Temperature selection For special cases, additional programmes are available in the machine. -
Page 11: Programme And Consumption Table
Programme and consumption table Auxiliary functions Selectable Programme Programme temperature temperature range °C Cottons 2.30 1000 • • • Cold-90 Cottons 1.54 1000 • • • Cold-90 Cottons 0.85 1000 • • • Cold-90 Cotton Economic 60** 1.00 1000 40-60 Cotton Economic 0.84 1000... -
Page 12: Auxiliary Function Selection
Auxiliary function selection in the final rinsing water in order to prevent them from getting wrinkled when there is no water in Use the following auxiliary functions according the machine. Press Start / Pause button after this to your daily needs. Select the desired auxiliary process if you want to drain the water without functions before starting the programme. -
Page 13: Starting The Programme
Progress of programme Thus, Delayed Start function will be canceled. The End/Cancel light flashes continuously. Then, select Progress of a running programme can be followed the programme you want to run again. Press Start from the Programme Follow-up indicator. At / Pause button to start the programme. the beginning of every programme step, the Starting the programme relevant indicator light will turn on and light of the Press Start / Pause button to start the programme. -
Page 14: Canceling The Programme
5 Maintenance and cleaning follow-up light of the relevant step during which the machine was switched into the Service life of the product extends and pause mode will flash. frequently faced problems decrease if cleaned Wait until the Loading Door can be opened. at regular intervals. Open the Loading Door and add or take out Cleaning the detergent drawer the laundry. Close the Loading Door. Make Clean the detergent drawer at regular intervals changes in auxiliary functions, temperature (every 4-5 washing cycles) as shown below and speed settings if necessary. -
Page 15: Draining Remaining Water And Cleaning The Pump Filter
tool, through the gap above the filter cover. Do not use metal tipped tools to remove the cover. Some of our products have emergency draining hose and some does not have. Follow the steps below to discharge the water. Discharging the water when the product has an emergency draining hose: Close the taps. Remove the nuts of the water intake hoses to access the filters on the water intake valves. -
Page 16: Technical Speci Cations
6 Technical speci cations Models EWF 1076 A Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) Net weight (±4 kg.) Electrical input (V/Hz) 230 V / 50Hz Total current (A) 2200 Total power (W) 1000 Spin speed (rpm max.) 1.00... -
Page 17: Troubleshooting
7 Troubleshooting Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> To cancel the programme, turn the Programme Selection knob to select another programme. Previous programme will be cancelled. (See "Canceling the programme") Water in the machine. • Some water might have remained in the product due to the quality control processes in the production. >>> This is not a failure; water is not harmful to the machine. Machine vibrates or makes noise.
