  • Page 1 User manual Washing machine...
  • Page 2 Thank You Thank you for purchasing a ELBA Product. Please read these instructions carefully before using this appliance. The instructions con- tain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance.
  • Page 3: Table Of Contents

    Content 1-Safety information ......................4 2-Product description ....................3-Control panel ......................10 4-Programmes ........................ 15 5-Daily use ........................17 6-Eco-friendly washing ..................23 7-Care and cleaning ..................
  • Page 4: 1-Safety Information

    1- Safety information ing safety hints: Trade mark ELBA HWD100-BD14756 Model identifier HWD100-BD14756S Maximum spin speed in rpm 1400 Washing capacity in kg Drying capacity in kg Dimension (HxWxD in mm) 850x595x600 Voltage in V Current in A Max power in W...
  • Page 5 1- Safety information WARNING! ▶ This appliance is intended to be used in household and similar applications such as: – staff kitchen areas in shops, offices and ot her working environment s; – farm houses; – by clients in hotels, motels and other residential type environments; –...
  • Page 6 1-Safety information ing safety hints! WARNING! Make sure there is no transport damage. Make sure all tran sport bolts are removed. Remove all packaging and keep out of children´rearch. Handle the appliance always with at least two persons because it is heavy. Daily use This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental ca-...
  • Page 7 1-Safety information WARNING! Daily use Do not remove or insert the plug in the presence of flammable gas. Do not hot wash foam rubber or sponge-like materials. Do not wash any laundry which is polluted with flour. Do not open detergent drawer during any wash cycle. Do not press the door during the washing process, it gets hot.
  • Page 8 1-Safety information WARNING! Installation Install or use the appliance only where the temperature is above 5 ℃. Do not place the appliance directly on a carpet, or close to a wall or furniture. Do not install the appliance in direct sunlight or near heat sources (e.g.
  • Page 9: 2-Product Description

    2-Product description 2.1 Picture of appliance Front (Fig. 2-1): Rear side (Fig. 2-2): ELBA Cotton Daily Wash HW100-BD14756 HW80-BP14636 BLDC motor Synthetic Ultra White Fast Express Wool 15 min Under- Baby Care wear Sport Delicate Temp. Speed Intense Extra rinse...
  • Page 10 HWD100-BD14756 10kg 1400 Capactiy a b c d f g h 5 Function bu ttons (a-h) 6 Function indicators 1 Display 7 Detergent /Softener 2 Programme selector a) “Smart Dosing” e) “Wash” drawer 3 “Start/Pause” button b) “Delay” f) “Rinse”...
  • Page 11: 3-Control Panel

    3-Control panel 3.1 Display The display (Fig.3.1) shows following information: Washing time End time delay Error codes and service information During operation display will be deactivated after two minutes until programme selector is turned or a but ton is touched. Symbols of the display: Programme cycle indication Status indication...
  • Page 12 3-Control panel To delete the setting or to cancel the setting process, press the function button until the Note: Factory settings there is no special requirement default settings are recommended. 3.5.1 “Smart Dosing” With this function (Fig. 3.5.1) the dispensing of liquid detergent and softener from the compartment 1 and 3 of the detergent drawer is performed automatically;...
  • Page 13 3-Control panel 3.5.3 “Speed” ress this button (Fig. 3.5.3) to change or deselect the spin of the programme. If there is no value the laundry will not spun. 3.5.4 “Temp.” Press this button (Fig.3.5.4) to change the washing temperature of the programme. If there is no value the water is not heated.
  • Page 14 3.5.9 Child lock Press button “Dry” and “I-time” (Fig. 3.5.9-1) for 3 se- conds simultaneously to block all panel elements ainst activation. For unlocking please press again the two buttons. cLo1- The display shows (Fig.3.5.9-2) if a button will be pressed, when the child lock is activated.The change is not running.
  • Page 15: 4-Programmes

    4-Programmes Synthetic Synthetic or mixed fabric Detergent compartment for: 10.0 Softener reservoir Powder detergent Liquid detergent reservoir Optional, Programme Cloth type Max. load in kg Cotton 10.0 Cotton 10.0 Lightly soiled mixed-laundry of cotton and synthetic Delicate Delicate laundry and silk Machine-washable fabric made of wool or with Wool wool content...
  • Page 16 4-Programmes 4.2 Functions Function Smart Delay Speed Temperture Wash Rinse I-time Programme Dosing in °C Selec- Preset in table P reset Preset range Preset in min in no. Cotton 1400 0 to 90 1000 0 to 60 Delicate 0 to 30 Wool 0 to 40 Shirts...
  • Page 17: 5-Daily Use

    5-Daily use 5.1 Power supply Connect the washing machine to a power supply (230V~/ 0Hz;Fig.5.1).Please refer also to section INSTALLATION. 5.2 Water connection Before connecting check the cleanliness and clarity of the water inlet. Tun on the tap (Fig.5.2). Note: Tightness Before use check for leakage in the joints between the tap and the inlet hose by turning on the tap.
  • Page 18 5-Daily use Care chart Washing Washable up to 90℃ Washable up to 60℃ Washable up to 60℃ normal process very process mild process Washable up to 40℃ Washable up to 40℃ Washable up to 40℃ normal process very process mild process Washable up to 30℃...
  • Page 19 5-Daily use 5.5 Selecting detergent Use only machine wash approved detergent. Mind al ways detergent manufacturer recommendations. Do not use dry cleaning agents such as trichloroethylene and similar products. Choose the best detergent Kind of detergent Programme Universal Colour Delicate Special Softener Cotton...
  • Page 20 Do not fill above the MAX.marking: Max. filling in ml 5.6-2 Compartment Model HWD100-BD14756 1300 HWD100-BD14756S Close the flaps Note: “Smart Dosing” Smart Dosing function is default setting for all programms and must be deacti- vated when you use powder detergent.
  • Page 21 5-Daily use 5.7 Switch on the appliance Press the “Power” button to switch on the appliance (Fig. 5.7) . The display is shining. 5.8 Select a programme To get the best washing results, select a programme Note: Odour removal Before first use we recommended to run programme Drum Clean with no load,without “Smart Dosing”function and add a small amount of detergent in washing agent comp- arment(2)or special machine cleaner to remove possibly corruptiveresidues.
  • Page 22 5-Daily use Note: Door lock For safety reasons the door is locked partially during the washing cycle. It is only pos- sible to open the door at the end of the programme or after the programme was can- celled correctly (see description above). In case of high water level, high water temperature and during spinning it is not pos- sible to open the door;...
  • Page 23: 6-Eco-Friendly Washing

    6-Eco-friendly washing Environmentally responsible use To achieve best use of energy, water, detergent and time you should use the recom mended maximum load size. Do not overload (hand width clearance above laundry). For slightly soiled laundry select a short programme. For manual detergent dosing appl y exact dosages of each washing agent.
  • Page 24: 7-Care And Cleaning

    7-Care and cleaning 7.1 Emptying and cleaning the detergent drawer Take always care there are no detergent residues in the manual l y dosage compartment Clean the drawer regularly: 1. Pull out the drawer until it stops (1) (Fig. 7.1-1). 2.
  • Page 25 7-Care and cleaning Note: Hygiene For regular maintenance we recommend to run programme Drum Clean with no load order to remove possible corruptive residues quarterly. Deactivate the “Smart Dosi- ng” function and add a small amount of detergent in washing agent compartment (2) use a special machine cleaner.
  • Page 26 7-Care and cleaning 7-6.3 7-6.4 7-6.5 7-6.6 CAUTION! The filter must be in place,or it may lead to leakage.
  • Page 27: 8-Troubleshooting

    8-Troubleshooting Many occuring problems could be solved by yourself without specific expertise.In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service.See CUSTOMER SERVICE. WARNING! Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket.
  • Page 28 8-Troubleshooting Water protective level error Contact the After sales service. Contact the After sales service. Water level senso error. Contact the After sales service. Abnormal communication error. Check and balance laudry load in the Unbalanced load-error. drum.reduce the load. Temperature in the drum is Will release automatically if tempera- higher than 80℃.
  • Page 29 8-Troubleshooting Operation stops Water or electric failure. Check power and water before completing supply. wash cycle. Operation stops for Appliance displays error code. Consider display codes. a period of time. Problem due to load pattern. Reduce or adjust load. Cancel programme and restart. Excessive foam flo- Detergent is not a appropriate.
  • Page 30 8-Troubleshooting Note: Foam formation If too much foam is inspected during spin cycle, motor stops and drain pump will be ac- tivated for 90 seconds. If that elimination of foam fails up to 3 times, programme ends without spinning. the error messages reappear even after the taken measures,switch off the S hould appliance, disconnect the power supply and contact the customer service.
  • Page 31: 9-Installation

    9-Installation 9.1 Preparation Take the appliance out of the packaging. Remove all packaging material including polystyrene base, keep them out of childrens reach. While opening the package, water drops may be seen on plastic bag and port- hole. This normal phenomenon results from water tests in the factory. Note: Packaging disposal Keep all packaging materials out of children’s reach and dispose them in an environmen- tally friendly manner.
  • Page 32 9-Installation 9.4 Aligning the appliance Adjust all feet (Fig. 9.4) to achieve a complete level position. This will minimize vibrations and thus noise duringuse.It will also reduce wear and tear.We rec- ommend to use a spirit level for adjustment.Floor should be as stable and flat as possible. 1.
  • Page 33 9-Installation Foll owing connections a re possible: 9.5.1 Drain hose to sink Hang the drain hose with the U-support over the edge of a sink with adequate size (Fig. 9.5-1). Protect the U-support sufficiently against slipping. 9.5.2 Drain hose to waste water connection The internal diameter of the stand pipe with vent-hole must be minimum 40 mm.
  • Page 34 9-Installation 9.6 Fresh Water Connection Make sure that the gaskets are inserted. 1. Connect the water inlet hose with the angled end to the appliance (Fig. 9.6-1). Tighten the screw joint by hand. 2. The other end connect to a water tap with a 3/4 thread (Fig.
  • Page 35: 10-Technical Data

    10-Technical data 10.1 Additional technical data HWD100-BD14756 HWD100-BD14756S Dimension in mm Height Width Voltage in V 230V~ /60Hz Current in A Max power in W 2000 Water Pressure in MPa Max. water inlet- cold temperature Net to weight in kg...
