  • Page 1 User Manual WASHER - DRYER User Manual WD 7512 VT...

  • Page 2: Table Of Contents

    CONTENTS IMPORTANT SAFETY WARNINGS BEFORE USING YOUR MACHINE • General warnings • Safety warnings -Danger of scalding/burning - Risk of death due to electrical shock - Explosion hazard - Danger of fire - Fall and injury hazard - Child safety PACKAGING and the ENVIRONMENT •...
  • Page 3 WASHING OPERATION • Sorting the laundry • Explanation of washing symbols • Placing laundry into the machine • Choice of detergent and placing into the machine • Programme selection • Auxiliary Functions • Half load detection system • Temperature selection •...

  • Page 4: Important Safety Warnings

    IMPORTANT SAFETY WARNINGS Read the instructions. This appliance is intended for domestic household use only and should not be used for any other pur- pose or in any other application, such as for non- domestic use or in a commercial environment. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience...
  • Page 5 The maximum mass of dry textile material in kilog- rams to be used in the appliance is 7 kg. The tumble dryer is not to be used if industrial che- micals have been used for cleaning. The lint trap has to be cleaned frequently. Lint must not be allowed to accumulate around the tumble dryer.
  • Page 6 The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are left at a temperature that ensures that the items will not be damaged. Remove all objects from pockets such as lighters and matches.

  • Page 7: Before Using Your Machine

    BEFORE USING YOUR MACHINE • Do not let your pets near the machine. • Please check the packaging of your machine befo- re installation, and the outer surface of the machine after the packaging has been removed. Do not ope- rate damaged machines or machines with opened packaging.

  • Page 8: General Warnings

    • You must remove the transportation safety screws before your machine’s first use. The machine will malfunction if it is operated with the transportation safety screws still in place and this will void your warranty. • Your machine warranty does not cover damage caused by external factors (floods, fire, rodents etc.) •...
  • Page 9 • It is recommended to perform the first washing operation in 95˚ White Cotton programme and without laundry by inserting ½ scale of detergent in the 2nd compartment of the detergent drawer. • As detergent or softener exposed to air for a long time may cause residues, only put your detergent or softener in the detergent drawer at the beginning of each wash.
  • Page 10 • When loading your machine, do not exceed the maximum amount of laundry specified for the prog- ramme you have chosen. • In case of any malfunction, unplug the machine and close the tap first. Do not attempt to repair by yourself and consult the nearest authorized service company.

  • Page 11: Safety Warnings

    Safety warnings You must read these warnings. Ignoring these warnings may put you or your loved ones at risk of fatal injuries. Burn risk! • Do not touch the discharge hose or the water disc- harged during the discharging process as the appli- ance may reach high temperatures when running.

  • Page 12: Danger Of Scalding/Burning

    Electrocution risk! • Do not use multiple plugs or extension cords. • Do not plug in damaged plugs or plugs with torn cables. • Never pull from the cable when unplugging. • Grab the plug when unplugging. • Do not plug-in or out the plug from the receptacle with wet hands to prevent electric shock.

  • Page 13: Explosion Hazard

    Explosion risk! • As there is a drying function on your machine, make sure that materials like stain removing chemi- cals or washing gas that you might have applied on your laundry earlier are properly rinsed and purged. There might be a risk of explosion when you run your machine with the drying function otherwise.
  • Page 14 • Laundry must not be dried in the machine under the conditions specified below due to the risk of fire: - Stuffed and damaged parts (pillows or jackets). The sponge parts dangling outside these stuffings might catch fire during the drying process. - The sulphur in paint-removing materials might cau- se corrosion.

  • Page 15: Fall And Injury Hazard

    - Never use products that contain solvent material (like washing gas) in your machine. Fall and injury risk! • Do not climb on your machine. The upper table of your machine may break and you might get injured. • Tidy the hose, cable and packaging of your machi- ne during installation.

  • Page 16: Child Safety

    Child safety! • Do not allow your children to play with the machi- ne. It is an electrically driven appliance. • Do not leave children unattended near the machi- ne. Children might lock themselves into the machi- • The door glass and machine surfa- ce might be extremely hot during your machine’s operation.

  • Page 17: Packaging And The Environment

    PACKAGING AND THE ENVIRONMENT DISPOSING OF PACKAGING AND YOUR OLD MACHINE RESPONSIBLY Removal of packaging materials Packaging materials protect your machine from the damage that might occur during transportation. Please recycle your packaging materials. Recycled material provides both raw material savings and decre- ases waste production Removal of old machine Old electrical devices might still contain salvageable parts.

  • Page 18: Savings Information

    SAVINGS & EFFICIENCY INFORMATION Some important information to get more efficiency out of your machine: • The amount of laundry you put in your washing machine should not exceed the maximum amount indicated. By avoiding overloa- ding, your machine shall run more efficiently. •...

  • Page 19: Overview Of The Appliance

    OVERVIEW OF YOUR DEVICE General Appearance Front view 1-Upper Tray 2-Detergent drawer 3-Programme button 5- Electronic Display and Additional Functions 6-Door 7-Pump filter cover...

  • Page 20: Overview

    General Appearance Rear view 8-Power cord 9-Drain hose 10-Transportation safety screws 11-Adjustable feet 12-Drain hose holding plastic: (The operation of the machine will be affected if this plas- tic part is removed. So please don’t remove this plastic part under any condition.)

  • Page 21: Technical Specifications

    Technical specifications Maximum washing capacity (dry laundry)(kg) * Maximum drying capacity (kg) Spin speed (rpm) 1200 Number of programmes Operation voltage / 220-240 / 50 Frequency (v / hz) Maximum:1 Water pressure (mpa) Minimum:0.1 Dimensions (HxWxD)(mm) 845x597x582 * You should not put dry laundry in your machine for drying. Energy consumption (washing, spinning, drying) 5.67 (kWh/cycle)

  • Page 22: Setting Up The Machine

    SETTING UP THE MACHINE Have your machine installed only by an authorized service company. Removing transportation safety screws Before operating your machine, you must remove the transportation safety screws on the backside of the machi- The transportation safety screws should be loosened by rotating them counter clockwise with an appropriate wrench.
  • Page 23 Transportation safety screws should then be removed by pulling them out. The removed transportation safety screws should be stored to be used again in case the machine needs to be transported again, e.g. if moving house. NOTE:You must remove the trans- portation screws from your machine before first use.

  • Page 24: Placing The Machine And Adjusting The Feet

    Placing the machine and adjusting the feet Do not install your machine on a carpet or such ground that will block ventilation from the base. To ensure silent and vibration- free operation of your machine, it should be deployed on a non- sliding and firm ground.
  • Page 25 • Tighten the plastic adjustment nut after balance is achieved. • Never put cardboard, wood or suchlike materials under your machine if you are intending to stabilize the distortions on the ground. • When cleaning the ground, on which your machine rests, be careful not to disrupt the machine’s stability.

  • Page 26: Electrical Connection

    Electrical connection • Your washer-dryer is adjusted for 220-240V and 50Hz. • The mains cord of your machine is equipped with a specific grounded plug. • The mains plug should always be inserted to a grounded receptacle of 10 amperes. The fuse cur- rent value of the power line connected to this plug should also be 10 amperes.

  • Page 27: Water Inlet Connection

    Water inlet connection • Operate your machine with cold water only. • Use only the new water inlet hoses given with your machine or purchased through authorized dealers. • 1 gasket is included in the hose packaging to prevent water leaks in connections.

  • Page 28: Water Draining Connection

    Note: Use only the new water inlet hose coming with your machi- ne when making the water inlet connections. Never use old, used or damaged water inlet hoses. Water draining connection • Connect the water drain hose to a waste water drain hole or a special apparatus connected to the outlet el- bow of the sink placed at a maximum height of 80 cm above the ground.

  • Page 29: Control Panel

    CONTROL PANEL...

  • Page 30: Detergent Drawer General View

    Detergent drawer general view When you want to wash your laundry with liquid detergent, you can use the liquid detergent apparatus. You can use your liquid detergent in all program- mes without pre-wash. For this, insert the liquid detergent appa- ratus to second compartment of the detergent drawer and adjust the liquid detergent amount (use...

  • Page 31: Detergent Drawer Compartments

    Detergent drawer compartments Main wash detergent compartment: In this compartment, use only materials like detergent (liquid or powder) or anti-lime. You can find the liquid detergent apparatus for your liquid detergent inside your machine during the first set up.(*) Softener, starching, detergent compartment: In this compartment, materials like softener for your wash laundry can be...

  • Page 32: Programme Knob

    Programme Knob Turn the programme knob to the desired washing programme. You may set the programme selection operation by rotating the programme knob in both directions. Ensure that the programme button is exactly on the programme you want to select. •...

  • Page 33: Washing Operation

    WASHING OPERATION • Open the tap. • Plug in your machine. Sorting laundry Your laundry has product labels on them that specify their appropriate washing conditions. Wash or dry your laundry according to the specifications on the product label. • Sort your laundry according to their type (cotton, synthetic, delicates, wool, etc.), washing temperature (cold, 30°C, 40°C, 60°C, 90°C), their level of dirtiness (less dirty, dirty, very dirty).

  • Page 34: Explanation Of Washing Symbols

    Explanation of washing symbols...

  • Page 35: Placing Laundry Into The Machine

    Placing laundry into the machine • Open the loading door of your machine. • Check inside the drum of your machine. There might be laundry left inside from previous washes. If there is, empty your machine before selecting your programme. •...
  • Page 36 • Put each item of laundry in separately. • Ensure that no laundry is stuck between the cover and bellow seal when closing the door of your machine. • Ensure that the machine door is completely closed. • Tightly shut the door of your machine or the machine won’t start the washing operation.

  • Page 37: Choice Of Detergent And Placing Into The Machine

    Choice of detergent and placing into the machine The amount of detergent you will put in your machine will depend on the following criteria: • Your detergent utilization will be based on the degree of contami- nation of your laundries. •...

  • Page 38: Programme Selection

    Programme selection • Turn the knob to select the desired washing programme.

  • Page 39: Auxiliary Functions

    AUXILIARY FUNCTIONS Before starting the programme, you can optionally select an auxiliary function. Spin Speed Delay Timer Auxiliary Start/Pause Temp. Spin Delay Start/Pause Drying Leve l Function Temp. • Press on the button of auxiliary function you would like to select. •...

  • Page 40: Half Load Detection System

    HALF-LOAD DETECTION SYSTEM Your machine features a half-load detection system. In case you put approximately half or less amount of laun- dries of maximum laundry capacity in your machine, your machine will run so as to save washing time, water con- sumption and energy in some programmes.When the half- load function is active, the machine can complete the pro- gramme you have set in a shorter time.

  • Page 41: Temperature Selection

    1- Temperature selection You can select the washing water temperature with the washing water temperature adjustment button. Whenever you select a new programme, the maximum washing water temperature is shown on the washing water temperature display. You can gradually decrease the washing water temperature between the maximum temperature and cold washing (--) by pressing washing water...

  • Page 42: Spin Speed Selection

    2- Spin speed selection Spin Speed You can set the spin revolution for your laundries via revolution speed setting button. When you select a new programme, the maximum spin revolution speed of the programme you have selected will be viewed on the display of revolution speed.

  • Page 43: Drying Level Selection

    3- Drying level selection: If you want your laundry dried at the end of the washing cycle: • Press the drying level button to select the level of dryness you want. • When you press the drying level button, on the display level 1 ”...

  • Page 44: Drying Duration Selection

    If you want your laundry dried for a period of time at the end of the washing cycle: • Press the drying level button to select the desired drying duration. • When you press the drying level button, on the display level 1 ”...

  • Page 45: Drying Level Selection

    Drying level selection: Please see selection table for drying level and duration. STATUS OF DRYING FACTORY PROGRAMMES SELECTABLE LEVELS SELECTABILITY PROFILE PRESET Cotton Cotton dry Level 1 Level 2 Level 3 Cotton eco Cotton dry Level 1 Level 2 Level 3 Eco 20°C Cotton dry Level 1...

  • Page 46: Delay Timer

    4- Delay timer This auxiliary function enables you to delay the start time of your machine from 1 up to 23 hours. To use auxiliary function of delay timer: - Press the Delay button once. - Expression of “1 h” will appear on the display.

  • Page 47: Start Pause Button

    5- Start/Pause button Press the Start/Pause button to start the pro- gramme you have selected or suspend a run- ning programme. If you switch your machine to the standby mode, the Start/Pause led on the electronic display will blink.

  • Page 48: Child Lock

    Child lock Child lock function enables you to prevent the appliance from being operated unintentionnally or by unsupervised children. To activate child lock, press auxiliary function buttons Drying Level and Delay at the same time for more than 3 seconds. ‘’CL’’...

  • Page 49: Cancelling The Programme

    Cancelling a running programme If you want to cancel any running programme: 1- Switch the programme knob to “CANCEL” position. 2- Your machine will stop the washing operation and the programme will be cancelled. 3- To get rid of the water accumulated in the machine, switch the programme knob to any other programme.

  • Page 50: Finishing The Programme

    Finishing programme Your machine will stop by itself as soon as the programme you have selected finishes. - The expression of “END” will flash on the electronic dis- play. - You can open the machine’s door and remove the laundry. - Leave the door of your machine open to allow the inner part of your machine to dry after removing your laun- dries.

  • Page 51: Programme Table

    PROGRAMME TABLE COTTON 90° Temp. (°C) *90°-80°-70°-60°-50°-40°-30°-”--” Maximum washing 7.0 / 5.0 / drying capacity (kg) Detergent Drawer Programme duration (min) Heat resistant, cotton and linen Laundry type / Remarks textiles. (Underwear, bed sheet, tablecloths, (towels, max. 3.5 kg) COTTON ECO Temp.
  • Page 52 PROGRAMME TABLE ECO 20° Temp. (°C) *20°-”--” Maximum washing 3.5 / 3.5 / drying capacity (kg) Detergent Drawer Programme duration (min) Lightly soiled, cottons and linen textiles. (underwears, bed sheet, Laundry type / Remarks tablecloth, (towel max. 2 kg.) Bedding, etc.) SYNTHETICS Temp.
  • Page 53 PROGRAMME TABLE WOOL Temp. (°C) 30°-”--” Maximum washing capacity (kg) Detergent Drawer Programme duration (min) Woollen and wool blended textiles hav- Laundry type / Remarks ing machine washable label CURTAIN Temp. (°C) 40°- 30°- ”--” Maximum washing capacity (kg) Detergent Drawer Programme duration (min) Use this programme for only to Laundry type / Remarks...
  • Page 54 PROGRAMME TABLE RINSE Temp. (°C) ”--” Maximum washing 7.0 / 5.0 / drying capacity (kg) Detergent Drawer Programme duration (min) If you want to get an additional rinse after washing your laundry, you can Laundry type / Remarks use this programme for all kinds of laundry.
  • Page 55 PROGRAMME TABLE SPIN Temp. (°C) ”--” Maximum washing 7.0 / 5.0 / drying capacity (kg) Detergent Drawer Programme duration (min) If you want to get an additional spin Laundry type / Remarks after washing your laundry, you can use this programme for all kinds of laundry.
  • Page 56 PROGRAMME TABLE DAILY FAST 60 MIN. 60°-50°-40°-30° ”--” Temp. (°C) Maximum washing 3.0 / 3.0 / drying capacity (kg) Detergent Drawer Programme duration (min) Soiled, cotton, colored and linen Laundry type / Remarks textiles. (*Black parts are factory presets) If you want to select more than one auxiliary function, the functions you want to select may have incompatibility among them.

  • Page 57: Gentle Dry

    PROGRAMME TABLE GENTLE DRY Temp. (°C) ”--” Maximum amount of laun- 3.5 Detergent Drawer Programme duration Delicate laundry bearing the Laundry type / Remarks suitable for machine dry label. COTTON DRY Temp. (°C) ”--” Maximum amount of laun- dry for drying (kg) Detergent Drawer Programme duration (min) Laundry type / Remarks...
  • Page 58 PROGRAMME TABLE QUICK WASH & DRY Temp. (°C) 30°-”--” Maximum washing 0.5 kg. 33 min (3 shirts) (33 minutes) / drying capacity (kg) Detergent Drawer Programme duration (min) Cotton, colored and linen laundry Laundry type / Remarks bearing suitable for machine dry label. Note: You machine determine the programme duration based on the amount of laundry that you will load.

  • Page 59: Cleaning And Maintenance (Warning)

    CLEANING AND MAINTENANCE (WARNING) Unplug your machine before starting the maintenance and cleaning of your machine. Turn the water tap off before starting the maintenance and cleaning of your machine. CAUTION: Your machine’s parts might be damaged if cleaners with solvent agents are used.

  • Page 60: Cleaning And Maintenance (Water Inlet Filters)

    CLEANING AND MAINTENANCE (WATER INLET FILTERS) Filters to avoid dirt and foreign substances in the water from penetrating into the machine are available both on the side of faucet and on the ends of water valves along the water inlet hose of your machine.

  • Page 61: Cleaning And Maintenance (Pump Filter)

    CLEANING AND MAINTENANCE (PUMP FILTER) This appliance is fitted with a filter system which avoids threads remaining from your laundries and tiny materials from entering into the pump during water discharging operation carried out by your machine after completing washing, thus prolonging the life- cycle of your pump.

  • Page 62: Cleaning And Maintenance (Pump Filter)

    CLEANING AND MAINTENANCE (PUMP FILTER) • Clean the foreign materials in the filter with a brush. • After cleaning the filter, fit the filter cover and tighten it by rotating it in clockwise direction. • While closing the pump cover, ensure that the parts on the inner side of the cover match the holes on the front panel side.

  • Page 63: Cleaning And Maintenance (Detergent Drawer)

    CLEANING AND MAINTENANCE (DETERGENT DRAWER) Your detergents may deposit residue in the detergent draw- er and housing of the detergent drawer over time. To clean the residue formed, disassemble the detergent drawer. It is recommended that you clean your detergent drawer every 2 months.

  • Page 64: Flush Stopper/Body/Drum

    FLUSH STOPPER / BODY / DRUM Flush stopper Disassemble the detergent drawer. Disassemble the flush stop- per and clean the softener residues completely. Refit the flush stopper after cleaning it. Check whether it has settled properly. Body Clean the outer body of your machine with warm water and a non-inflammable cleaning agent that will not abrade the body of your machine.

  • Page 65: Troubleshooting

    Troubleshooting All repairing operations required for your machine should be carried out by an authorised service company. If your machine requires a repair or if you cannot solve an issue with the information provided below, then you should: • Unplug the machine. •...
  • Page 66 POSSIBLE FAULT REMOVING METHODS CAUSE Discharging hose Check the discharging clogged or twisted. Your machine hose. does not Pump filter discharge Clean the pump (**)filter. clogged. You machine’s feet Adjust the feet of your are not adjusted. machine. (***) Transportation Remove the transportation safety screws are safety screws from your...
  • Page 67 FAULT POSSIBLE CAUSE REMOVING METHODS Press the Start/Pause button. To eliminate foam formation, mix a spoon of softener with half a litre of water, and pour the Excessive amount mixture in the detergent of detergent used. drawer. After 5-10 minutes, press the Start/Pause button again.
  • Page 68 FAULT POSSIBLE CAUSE REMOVING METHODS The end of the As soon as the Set the water drain hose water drain hose machine is loaded to an appropriate height. is too low for the with water, water (*****) machine. discharges. No water No fault.
  • Page 69 FAULT POSSIBLE CAUSE REMOVING METHODS Appropriate drying programme is Select a drying not selected. Laundry remains programme appropriate for The maximum damp after the your laundry (see page 51 load capacity drying operation. to 58 for the programme for the selected table) programme might be exceeded.

  • Page 70: Automatic Fault Warnings And What Needs To Be Done

    Automatic fault warnings and what needs to be done Your machine is equipped with the systems which are capa- ble of both taking necessary precautions and warning you in case of any breakdown by means of continuous self-check- ing during washing operations. POSSIBLE ERROR WHAT TO DO...

  • Page 71: Practical Information

    PRACTICAL INFORMATION Alcoholic drinks: Spotted area should ini- tially be washed using cold water, and then be wiped with glycerine and water and rinsed with vinegar-mixed water. Shoe shine: Spot should be rubbed out gently without damaging the cloth and be scrubbed and rinsed with detergent.
  • Page 72 PRACTICAL INFORMATION Tomato paste: After rubbing out the dried substances without damaging your laundry, submerge it in water for 30 minutes, and then scrub and wash it with detergent. Grease and oil stains: Firstly, wipe the residues. Scrub the spot with detergent and wash it with warm soapy water.
  • Page 73 PRACTICAL INFORMATION Fruit: Stretch the spotted area of your laun- dry throughout the opening of a vessel, and pour cold water on it. Do not pour hot water on the spot. Wipe with cold water and apply glycerine. Allow 1-2 hours, wipe with a few drops of white vinegar, and rinse it.
  • Page 74 PRACTICAL INFORMATION Blood stain: Submerge your laundries in cold water for 30 minutes. If the stain is not removed, then submerge in a mixture of wa- ter and ammoniac (3 spoons of ammoniac in 4 litres of water) for 30 minutes. Cream, ice cream and milk: Submerge your laundries in cold water and scrub the spotted area with detergent.

  • Page 75: Describing Energy Label And Saving Energy

    DESCRIBING ENERGY LABEL AND SAVING ENERGY Energy and water consumption may vary based on water pressure, water hardness, water temperature, ambient tem- perature, laundry amount, additional function selection, volt- age fluctuations. It will reduce energy and water consump- tion to use your machine with the laundry capacity proposed for the selected programme, wash your laundries less dirty or daily laundries in short programmes, carry out cleaning and maintenance periodically, use your machine in conveni-...

  • Page 76: Disposal Information

    52153450 Disposal information The symbol on the product or its packaging indicates that this product may not be treated as household waste. Instead it should be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
