Lung Sound Auscultation Trainer "LSAT" ver.2 　
● Product Supervision
Chiharu Yoshii, MD., Ph.D., Professor,
Department of Respiratory Medicine,
Wakamatsu Hospital of the University of
Occupational and Environmental Health,
Japan
MW28
Caution
Instruction
Manual

Table of contents

■
・・・・・・・・・・・・・・・
■
・・・・・・・・・・・・・・・・・
■
■
・・・・・・・・・・・・・・・・・・・
■
■
Training
■
■
Turning on the unit
■
■
Starting up the software
■
・・・・・・・・・・・・・・
■
■
■
Trouble Shooting
■
■
■
■
■
Do not mark on the model and its
components with a pen or leave printed
materials in contact with the model surface.
Ink marks on the model are not removable.
・・・・・・
・・・・・・・・・
・・・・・・・・
・・・・・・・・・・
・・・・・・・・・
・・・・・・・・・・・・・
・・・・・・・・・・・・
・・・・・・・・・・・
・・・・・・・・・・・・・
・・・・・・・・・・・・・・
・・・・・・・・・・・・・
・・・・・・・・・
・・・・・・・・・・
・・・・・・・
・・・
Movie Site
English Site
https://youtu.be/hrYDVJCyfbY
P.1
P.2-3
P.4
P.5
P.6-7
P.8
P.9
P.10
P.11
P.12
P.13-14
P.15
P.16
P.17
P.18
P.19
P.20
P.21
P.22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSAT and is the answer not in the manual?

Questions and answers

Related Manuals for Kyoto Kagaku LSAT

Summary of Contents for Kyoto Kagaku LSAT

  • Page 1: Table Of Contents

    Ink marks on the model are not removable. MW28 Lung Sound Auscultation Trainer “LSAT” ver.2 　 ● Product Supervision Chiharu Yoshii, MD., Ph.D., Professor, Department of Respiratory Medicine,...

  • Page 2: Introduction

    ■ Before use MW28 Lung Sound Auscultation Simulator "LSAT" is designed for medical education training. Please do not use the product for other purposes. Any other use not in accordance with the instructions on this manual as well as on the help menu in the system is strongly discouraged.
  • Page 3 Introduction Supply voltage: AC100-240V 50/60Hz 450VA Altitude: 2.000meters above sea-level Environmental conditions: 5 degrees C.to 40degrees C. Relative humidity: Less than 80 per cent(no condensation) Overvoltage Category: 2 Pollution Degree: 2 Power cord supply: Do not use power supply cords other than the one included in the original set. Clean-up: Clean the simulator with water or mild detergent.

  • Page 4: Dos And Don'ts

    DOs and DON'Ts Introduction DOs and DONʼTs DONʼTs ●Operate the system under the designated ●Do not disassemble or open electric or circumstances precision components Power input: AC100V～230V plus or minus 10％, 50Hz/60Hz Do not remove or alter cable connections in the inner machinery. Temperature range: between 0 degrees C and 40 degrees C (no Connection cables and their settings have been preset;...

  • Page 5: Set Includes

    Introduction Set includes ■Set includes Before you first use "LSAT", ensure all components listed below are included in the unit. A : 1 LSAT unit with respiratory torso manikin B: 1 control PC 1 power cable for control PC C : 1 AC adapter D : 1 power strip 0.5m 1.5ｍ...

  • Page 6: Parts Names And Functions

    Introduction Parts names and functions ■Unit Anterior Posterior Main power switch : Power is ON : Power is OFF Side Slider for adjusting the volume of light intensity. Light Light Hole for cables Shelf for control PC LAN port Handle Push to open Speaker ■Control PC Touch-panel monitor...

  • Page 7: Preparation

    Preparation Assembly Installation of external speaker Push the red circle area to open. Find two fixing belts at the floor of the housing and unbuckle them. ▼ Inside Hole for cables 2 belts Sound output Power cable Remove the cap of the hole for cables in the side panel. Pass the cable of AC adopter through the hole then connect it to the power cable at the upper area in the housing.
  • Page 8 Assembly Preparation Buckle and pull the belt tightly to secure the speaker in place.

  • Page 9: How To Use The Unit Separately

    Introduction How to use the unit separately The torso manikin is possible to be separated. POINT To separate : Push button Detach connection cables To attach : Push knob marked with red circles. Hold the simulator by the handles at the both Connect unit to an AC adapter to sides when separating.

  • Page 10: Auscultation Sites/ Cases

    Introduction Auscultation sites Cases ■ Auscultation sites Anterior Posterior 1. trachea 5. middle right lung field 0. upper left lung field 4. lower left lung field 2. upper right lung field 6. lower right lung field 1. upper right lung field 5.

  • Page 11: Classification Of Lung Sounds

    Classification of lung sounds Introduction ■ Classification of lung sounds Normal Abnormal Coarse Crackles Discontinuous Sounds Fine Crackles Wheezes Rhonchi Continuous Sounds Adventitious Miscellaneous Sounds Continuous Sounds Miscellaneous Play Lists The American Thoracic Society developed a rational and clinically useful classification based on acoustic analysis of tape recordings and introduced the nomenclature.

  • Page 12: Turning On The Unit

    Training Turning on the unit When starting up the system follow the sequence of actions IMPORTANT . y l The unit may not work correctly when being turned on with Connect the power cable to the outlet. Turn on the control system's main power. Audio cable Main power Outlet...

  • Page 13: Error Indicator System

    When errors detected, the following screen is displayed. Verify that all results are normal. When any error is detected, contact your local distributor or Kyoto Kagaku with the error code. Do not operate the control PC when the error indicator system is working.

  • Page 14: Starting Up The Software

    Training Starting up the software Verifying the connection of wireless systems Verify the icon of the wireless connection. * Default is set to wireless. The softwares includes help menu for how to use the simulator. NOTES Tap the help menu for more details which are not described in this manual.
  • Page 15 Training Starting up the software Selecting unit Start up simulation software From top menu, select "LSAT2 Simulation" or "Playlist Maker". Softwares ■ LSAT2 Simulation Software All functions of LSAT2 are managed by this software. ■ LSAT2 Playlist Maker "Playlist" of cases can be created. To create a playlist, 1) Use the Playlist Maker.

  • Page 16: Operation Screen

    Training Operation screen Simulation Software Error indication has been completed, the simulation software is ready to begin. Volume setting of external speaker Volume setting of respiratory sound Preferences on control PC’s monitor screen Save to playlist Case information Control buttons Help menu Case name Home...

  • Page 17: Multi-Unit Operation

    Training Multi-unit operation Multi-unit operation Up to 5 units can be selected by one control PC at a time. Setting process varies between unison operations and multiple case operations. For details see incorporated HELP menu by tapping on the mark on the top right of the screen.

  • Page 18: After Training

    After Training Exiting the software Turning off the control system's main power Exit software Tap on the "Home" icon at the right top. "Do you want to exit?" message appears, select "Yes." Tap on the "Exit" icon at the top menu. "Do you want to exit?"...

  • Page 19: Trouble Shooting List

    Trouble shooting Trouble shooting list Cases Causes Solutions Network interference occurred. → Case: Unable to Boot The Main Unit ( → P.19) Unable to connect with wireless or unstable connection There are physical obstructions for wireless Clear the obstructions or close the control PC to connection or control PC is too far from the unit.

  • Page 20: Unable To Boot The Main Unit

    Trouble shooting Unable to boot the main unit Unable to boot the main unit Attention For the multi-unit operation, be sure the control PC’s own main unit is turned on. The control PC is not able to operate when its own main unit is turned off. ■...

  • Page 21: Unable To Select The Units

    Unable to select the units Trouble shooting Unable to select the units Attention For the multi-unit operation, be sure the control PC’s own main unit is turned on. The control PC is not able to operate when its own main unit is turned off. ■...

  • Page 22: An Error Occurs During The Session

    Trouble shooting An error occurs during the session An error occurs during the session ■ Case: The software closed with showing the error display below. ■ Cause: Wireless network confusion may be happened around the models. ■ Solution: Try with wired connection mode. How to change the connection mode to wired: P.20...
  • Page 23 Trouble shooting How to change the connection mode to wired The error occurs during the session Tap the connection switch on left upper display to change the connection mode. Connect the control PC to the LAN cable from the main unit . LAN port Attention In regard to multi-unit operation with the wired connection mode, unit.
  • Page 24 Do not mark on the model and its  MW28 Caution components with a pen or leave printed  materials in contact with the model  Lung Sound Auscultation Trainer “LSAT” ver.2 surface. Ink marks on the model are not  removable.  2023/02...
