- Page 1 PH-79 X-Ray Training Phantom PBU-POSE Instruction manual Contents Please read before training ● General information P. . 1 P. 3 Preparation ● Assembly manual P. . 4 P. 9 Anatomical Landmarks P.10 ●...
- Page 2 Please read General information X-Ray Training Phantom PBU-POSE Thank you for purchasing the "X-ray Training Phantom". This product is a whole-body phantom for general imaging that specializes in positioning and is significantly lighter than the "Whole Body Phantom PBU-50". The shoulder, elbow, hip, and knee joints are flexible, and each joint can be assembled / disassembled. For the separate parts and joints, the shape of the bone is truthfully reproduced to the human shape.
- Page 3 Main Body d. Pajama b. Head fixing base instruction manual Specifications Model：PBU-POSE Intended application: Positioning phantom for plain radiography Length: approx.165cm Weight: approx. 18kg Can be dismantled at: shoulders elbows, hip joints, knees, neck (10 parts) Embedded organs: heart and kidneys...
- Page 4 Please read General information PBU-POSE Components Parts Parts Parts name Parts name Connector for left hip joint Head Neck-head connection plate Supporting plate for right hip joint Trunk Supporting plate for left hip joint Connector for right knee Right upper arm...
- Page 5 Assembly manual The number indicated on the photos above correspond to the page numbers in this manual. ※Please note, that the appearance of each part may differ from the actual product...
- Page 6 Assembly manual The circled numbers in the assembly images are parts numbers on the components table ※ on page 3. < > NECK AND HEAD 1. Remove the two bolts for the neck connection (part #26) and remove the neck head connection plate (part #2) from the trunk.
- Page 7 Assembly manual < > Elbow Joints (the photo shows left elbow joint) Connector for left Assemble upper arm parts (part #4 or 5) and and right elbow (medial side) forearm parts (part #6 or 7) at joint section. Fix these parts with elbow connectors (part #16 or 18 and #17 or 19).
- Page 8 Assembly manual < > Knees （photos show right knee） 1. Connect the thigh (#8, 9) and lower leg (#10, 11) at the knee joint. Insert the dowel of the upper thigh through the hole of knee joint of lower thigh. Set the connector for knee (#24, 25) to the medial side then screw the two knee joint bolts (#32) to fix it.
- Page 9 Assembly manual < > Hip Joints （photo shows right hip joint） Left and right leg Connector for left connection 21 22 20 and right hip joint reinforcement parts 1. Remove the three bolts (part #31) to remove the hip joint connectors (parts #20 and #21).
- Page 10 Assembly manual < > HEAD AND STAND 1. Mount the head phantom to the neck connector (part#36) and fix it with two screws. Screw bolt for neck connection M10×15×2 2. Assemble the two panels. Attach the height adjustment panel (#34) to the 39 Screw bolt base panel (#35) at right angle and fix with two screws.
- Page 11 Anatomical Landmarks external auditory foramen mastoid 7th cervical spine sternum manubrium, clavicle xiphoid process lower costal arch iliac crest large trunker superior border of pubic symphysis medial and lateral epicondyle of femur patella medial and lateral malleoli radial and ulnar styloids (wrist)
- Page 12 Don’t mark on the phantom with pen or leave printed materials contacted on its surface. Caution Ink marks on the phantom will be irremovable. ・If you have any questions, please contact the dealer you purchased the product or Kyoto Kagaku Co., Ltd. below. ■ ■...
