Kyoto Kagaku AbdoAbby Instruction Manual

Abdominal examination simulator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ＭＷ43
"AbdoAbby" Abdominal
Examination Simulator
Production Supervision：
Takahiro Amano, M.D.
Vice Pres ident, International University of Health and Welfare
Kyoko Arai,
Professor, School of Nursing, University of Shizuoka
Do not mark on the product and its
Caution
components with a pen or allow printed
materials to come in contact with the
surface. Ink marks cannot be removed.
Instruction
Manual
Contents
Introductio n
●
Manufacturerʼs note ····························P.1-2
●
Setting o f t he liver ································
Setting o f t he liver ································ P.5
Setting of the spleen ····························· P.6
Setting of the kidne ys ·························· P.7
lymphoma in the inguinal area ············· P .8
······························································
Palpation and auscultation ····················· P.12
······························································
·······································
Movie Site
https://youtu.be/v-qKDvmsoeI
P.3
P.4
····
P.9
P.10-11
P.13
English Site

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AbdoAbby and is the answer not in the manual?

Questions and answers

Related Manuals for Kyoto Kagaku AbdoAbby

Summary of Contents for Kyoto Kagaku AbdoAbby

  • Page 1: Table Of Contents

    Caution components with a pen or allow printed materials to come in contact with the surface. Ink marks cannot be removed. ＭＷ43 ”AbdoAbby” Abdominal Examination Simulator Production Supervision： Takahiro Amano, M.D. Vice Pres ident, International University of Health and Welfare...
  • Page 2 Please use the product carefully and refrain from subjecting it to any unnecessary stress or wear. Should you have any questions about this simulator, please feel free to contact our distributor in your area or KYOTO KAGAKU at any time. (Our contact address is on the back cover of this manual) Features ...
  • Page 3 Introduction Manufacturerʼs Note DOs and DONʼTs DONʼTs ●Operate the system under the designated ●Do not disassemble or open electric or circumstances precision components Power input: AC100V～230V plus or minus 10％, 50Hz/60Hz Do not open up or disassemble the housing for electric parts Temperature range: between 0 degrees C and 40 degrees C or precision components.

  • Page 4: Preparation

    Preparation Set Includes Set Includes Before you start, ensure that you have all components listed below. 1 simulated stethoscope 1 torso unit 1 controller Caution 1 AC adapter At times liner sharing may be seen on the skin surface.　 These are color shading due to the manufacturing process and do not affect the strength or quality of the product.

  • Page 5: Unpack The Torso Unit/Setting O F T He Liver

    Unpack the torso unit/Setting of the liver Preparation 1. Unpack the torso unit ●The torso manikin is covered with the protection sheet The torso manikin is by covered with the non-woven protection sheet in the storage box. Take out the torso manikin from the box and remove the sheet.
  • Page 6 Preparation Setting of the liver 2. Setting of the respiratory motion control unit ● Operation check of the control unit Step on the foot switch of the respiratory motion control unit to see whether the unit works properly. The liver pusher comes out when the pedal is pressed down and it is stowed when the pedal is released.

  • Page 7: Setting Of The Spleen

    Preparation Setting of the spleen 1. Setting of the spleen ● Remove the back cover Remove the back cover (left side) of the torso head unit. The torso manikin without a spleen unit represents a person with healthy (normal) spleen. ●Set the spleen There is an arrow mark on the back of each spleen inserts.

  • Page 8: Setting Of The Kidneys

    Preparation Setting of the kidneys 1. Setting of the kidneys ● Remove the back cover Remove the back cover (right side) of the torso head unit. The torso manikin without kidney units represents a person with healthy (normal) kidneys. ● Set the kidneys. There is an arrow mark on the back of head each kidney inserts.

  • Page 9: Setting Of The Uterus And Lymphoma In The Inguinal Area

    Setting of the uterus and lymphoma Preparation in the inguinal area 1. Setting of the uterus and lymphoma in the inguinal area ●Remove the setting base Pull out the setting base for the uterus and lymphoma from the lower side of the torso unit.

  • Page 10: Setting Of The Simulated Stethoscope

    Setting of the simulated stethoscope Preparation 1．Guide to the parts names of the simulated stethoscope Jack for data cable Site selection Case selection Volume control Case number (0-5) Sound volume (0-100) Micro SD card ※Do not remove i. 1 simulated stethoscope・ ・ ・ ・ １ Power switch j. 1 controller ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ １ k.

  • Page 11: Setting Of Bowel Sounds And Vascular Bruits

    Setting of bowel sounds and Preparation vascular bruits 1．Select auscultation site and case ●Select an auscultation site Four areas for auscultation: renal artery. aorta, CIA bruits and bowel sounds. To select a site press in a red circle Green light shows that the site is selected. Aorta ①...
  • Page 12 No.0;Normal bruits (No data in No.2-5) CIA area ; No.0;Normal Bowel sounds ; No.1; Increased No.2; Decreased No.3; Obstruction No.4; Ileus(Silent) No.5;(No data) ※ Sound data can be added to unused numbers. Ask your distributor or Kyoto Kagaku for details.

  • Page 13: Training Sessions

    Training Palpation and auscultation Sessions 1. Palpation and auscultation ●Vascular bruits and bowel sounds for ● Landmarks for palpation: auscultation: ・Liver (precirrhosis, cirrhosis, chronic hepatitis、 ・Renal bruit normal） ・Aortic bruit *Step on the foot switch to simulate ・Iliac artery bruit respiratory motion.

  • Page 14: After Training

    After Training Storage of the torso unit and organ parts 1. Store the torso unit ●Wipe off dirt, apply talcum powder and cover with the protective sheet. Take off the respiratory motion control unit from the torso unit. Cover the torso unit with Clean with wet wipe or cloth, using mildly the protection sheet.
  • Page 15 Do not let ink from pens, newspapers, product manual or other sources Caution contact the manikin. Ink marks on the manikin will be irremovable. ・本製品についてのお問い合わせや不具合等ございましたら、お手数ですがお買い上げの販売店、 もしくは下記（株） 京都科学まで御連絡ください。 For inquiries and service, please contact your distributor or KYOTO KAGAKU CO., LTD. ・ URL http://www.kyotokagaku.com e-mail rw-kyoto@kyotokagaku.co.jp ●...
