Pediatric Lung Sound Ausculation Trainer
MW57 Pediatric Lung Sound Auscultation Trainer
● Product Supervision
Yuki Okamatsu, MD
Director of Pediatric department,
Aso Iizuka Hospital
Caution
Instruction
Manual

Table of contents

■
・・・・・・・・・・・・・・・
■
・・・・・・・・・・・・・・・・・
■
■
・・・・・・・・・・・・・・・・・・・
■
■
Training
■
■
■
■
Starting up the software
■
・・・・・・・・・・・・・・
■
■
■
Trouble Shooting
■
Unable to start the main unit
■
■
■
■
Do not mark on the model and its
components with a pen or leave printed
materials in contact with the model surface.
Ink marks on the model are not removable.
・・・・・・
・・・・・・・・・
・・・・・・・・
・・・・・・・・・・
・・・・・・・・・
・・・・・・・・・・・・・
・・・・・・・・・・・・
・・・・・・・・・・・
・・・・・・・・・・・・・
・・・・・・・・・・・・・・
・・・・・・・・・・・・・
・・・・・・・・・
・・・・・・・・・・・
・・・・・・・・
・・・・・
P.1
P.2-3
P.4
P.5
P.6-7
P.8
P.9
P.10
P.11
P.12
P.13-14
P.15
P.16
P.17
P.18
P.19
P.20
P.21
P.22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MW57 and is the answer not in the manual?

Questions and answers

Related Manuals for Kyoto Kagaku MW57

Summary of Contents for Kyoto Kagaku MW57

  • Page 1: Table Of Contents

    Ink marks on the model are not removable. Pediatric Lung Sound Ausculation Trainer MW57 Pediatric Lung Sound Auscultation Trainer ● Product Supervision Yuki Okamatsu, MD Director of Pediatric department, Instruction...

  • Page 2: Introduction

    ■ Before use MW57 Pediatric Lung Sound Auscultation Simulator is designed for medical education training. Please do not use the product for other purposes. Any other use not in accordance with the instructions on this manual as well as on the help menu in the system is strongly discouraged.
  • Page 3 Introduction Supply voltage: AC100-240V 50/60Hz 450VA Altitude: 2.000 meters above sea-level Environmental conditions: 5℃.to 40℃. Relative humidity: Less than 80%(no condensation) Overvoltage Category: 2 Pollution Degree: 2 Power cord supply: Do not use power supply cords other than the one included in the original set. Clean-up: Clean the simulator with water or mild detergent.

  • Page 4: Dos And Don'ts

    Introduction DOs and DON'Ts DOs and DONʼTs DONʼTs ●Operate the system under the designated ●Do not disassemble or open electric or precision circumstances components Power input: AC100V～240V plus or minus 10％, 50Hz/60Hz Do not remove or alter cable connections in the inner machinery. Temperature range: between 0 degrees C and 40 degrees C (no Connection cables and their settings have been preset;...

  • Page 5: Set Includes

    Introduction Set includes ■Set includes Before you first use "Pediatric LSAT", ensure all components listed below are included in the unit. A : 1 pediatric LSAT unit 　（with respiratory torso manikin, separable into 2 parts) B: 1 control PC 1 power cable for control PC C : 1 AC adapter D : 1 power strip E : 1 LAN cable ( 0.5m, 1.5m, 10m )

  • Page 6: Part Names And Functions

    Introduction Parts names and functions ■Unit Anterior Posterior Main power switch : Power is ON : Power is OFF Side Slider for adjusting the volume of light intensity. Light Light Hole for cables Shelf for control PC LAN port Handle Push to open Speaker ■Control PC Touch-panel monitor...

  • Page 7: Preparation

    Preparation Assembly Installation of external speaker Press the red circled area to open. Find two fixing belts at the floor of the housing and unbuckle them. ▼ Inside Hole for cables 2 belts Sound output Power cable Remove the cap of the hole for cables in the side panel. Pass the cable of AC adapter through the hole then connect it to the power cable at the upper area of the housing.
  • Page 8 Assembly Preparation Buckle and pull the belt tightly to secure the speaker in place. Ensure that the antennas are connected firmly to the main unit before use,or they CAUTION might come off accidentally.

  • Page 9: How To Use The Unit Separately

    Introduction How to use the unit separately The torso manikin is able to be separated. POINT To separate : Push button Detach connection cables To attach : Push knob marked with red circles. Hold the simulator by the handles at both Connect unit to AC adapter to sides when separating.

  • Page 10: Auscultation Sites Cases

    Introduction Auscultation sites Cases ■ Auscultation sites Anterior Posterior 1. trachea 4. lower left lung field 0. upper left lung field 4. lower left lung field 2. upper right lung field 5. lower right lung field 1. upper right lung field 5.

  • Page 11: Classification Of Lung Sounds

    Introduction Classification of lung sounds ■ Classification of lung sounds Normal Abnormal Coarse Crackles Discontinuous Sounds Fine Crackles Wheezes Rhonchi Continuous Sounds Adventitious Miscellaneous Sounds Continuous Sounds Miscellaneous Play Lists The American Thoracic Society developed a rational and clinically useful classification based on acoustic analysis of tape recordings and introduced the nomenclature.

  • Page 12: Turning On The Unit

    Training Turning on the unit When starting up the system follow the sequence of actions IMPORTANT instructed below so that the wireless connection works correctly. order. The unit may not work correctly when turned on with Connect the power cable to the outlet. Turn on the control system's main power.

  • Page 13: Error Indicator System

    After the error indication , the following screen shows up. Make sure that all results are normal. If error was detected, contact your local distributor or Kyoto Kagaku with the error code. Do not operate the control PC while the error indicator system is working.
  • Page 14 Training Starting up the software Check the connection of wireless systems Check the icon of the wireless connection. * Default is set to wireless. The softwares include help menu for how to use the simulator. NOTES Tap the help menu for more details which are not described in this manual.
  • Page 15 Training Starting up the software Selecting unit Start up simulation software From top menu, select "Pediatric LSAT Simulation" or "Playlist Maker". NOTES Please wait until the next page shows up. Softwares ■ Pediatric LSAT Simulation Software All functions of Pediatric LSAT are operated by this software. ■...

  • Page 16: Operation Screen

    Training Operation screen Simulation Software Error indication has been completed, the simulation software is ready to begin. Volume setting of external speaker Volume setting of respiratory sound Preferences on control PC’s monitor screen Save to playlist Case information Control buttons Help menu Case name Home...

  • Page 17: Multi-Unit Operation

    Training Multi-unit operation Multi-unit operation Up to 5 units can be operated by one control PC. Setting process varies between unison operations and multiple case operations. For details see incorporated HELP menu by tapping on the mark on the top right of the screen.

  • Page 18: After Training

    After Training Exiting the software Turning off the control system's main power Exit software Tap on the "Home" icon at the right top. "Do you want to exit?" message appears, select "Yes." Tap on the "Exit" icon at the top menu. "Do you want to exit?"...

  • Page 19: Trouble Shooting List

    Trouble shooting Trouble shooting list Cases Causes Solutions Network interference occurred. → Case: Unable to Boot The Main Unit ( → P.19) Unable to connect with wireless or unstable connection There are physical obstructions for wireless Clear the obstructions or close the control PC to connection or control PC is too far from the unit.

  • Page 20: How To Switch To Lan Connection Mode

    Trouble shooting Unable to boot the main unit Unable to boot the main unit Attention For the multi-unit operation, be sure the control PCʼs own main unit is turned on. The control PC is unable to operate when its own main unit is turned off. ■...
  • Page 21 Trouble shooting Unable to select the units Unable to select the units Attention For the multi-unit operation, be sure the control PCʼs own main unit is turned on. The control PC is unable to operate when its own main unit is turned off. ■...
  • Page 22 Trouble shooting Error occurs during the session Error occurs during the session ■ Case: The software is automatically closed with the error message below. ■ Cause: Wireless network is confused around the models. ■ Solution: Try LAN connection mode. How to switch to LAN connection mode: P.22...
  • Page 23 Trouble shooting How to switch to LAN connection mode Error occurs during the session Tap the network icon on left upper display to switch the connection mode. Connect the control PC to the LAN cable from the main unit . LAN port Attention Regarding multi-unit operation with the LAN connection mode, check the attached...
  • Page 24 Pediatric Lung Ausculation Trainer Do not mark on the model and its  Caution components with a pen or leave printed  materials in contact with the model  MW57 Pediatric Lung Sound Auscultation Trainer surface. Ink marks on the model are not  removable.  ■ Worldwide Inquiries and Orders Kyoto Kagaku Head Office and Factories: TEL：+81-75-605-2510　FAX：+81-75-605-2519 15 Kitanekoya-cho, Fushimi-ku, Kyoto, 612-8388, JAPAN ■ USA, Canada, and South America Kyoto Kagaku America Inc.
