Sitecom WL-330v2 Full Manual page 25

2-8 WPS Setting (WL-331 only)
Wi-Fi Protected Setup (WPS) is the simplest way to build connection between wireless
network clients and this access point. You don't have to select encryption mode and
input a long encryption passphrase every time when you need to setup a wireless client,
you only have to press a button on wireless client and this access point, and the WPS
will do the setup for you.
This access point supports two types of WPS: Push-Button Configuration (PBC), and PIN
code. If you want to use PBC, you have to switch this access point to WPS mode and
push a specific button on the wireless client to start WPS mode. You can push
Reset/WPS button of this access point, or click 'Start PBC' button in the web
configuration interface to do this; if you want to use PIN code, you have to provide the
PIN code of the wireless client you wish to connect to this access point and then switch
the wireless client to WPS mode. The detailed instructions are listed follow:
Note: WPS function of this access point will not work for those wireless clients do
not support WPS.
Note (2): The WPS function is only present in the WL-331 Access Point.
The WL-330 Universal Repeater doesn't support WPS.
To use WPS function to set encrypted connection between this access point and WPS-
enabled wireless client by WPS, click 'WPS Setting' on the left of web management
menu, and the following information will be displayed:
Enable WPS
Wi-Fi Protected
Setup
Information
Check this box to enable or disable WPS function
All information related to WPS will be displayed here, they're
helpful when you're setting up connections by WPS.
WPS Status: Displays WPS status. If data encryption settings of
this access point has never been set, 'unConfigured' message
will be displayed her. (see Section 2-7 for detailed information);
if data encryption settings has been set before, 'Configured'
message will be displayed here.
Self PinCode: This is the WPS PIN code of this access point. This
code is useful when you need to build wireless connection by
WPS with other WPS-enabled wireless devices.
