2-4-6 AP Bridge-WDS Mode
In this mode, this wireless access point will connect to up to four wireless access points
which uses the same mode, and all wired Ethernet clients of every wireless access points
will be connected together. You can use this mode to connect a network to other
networks which is physically isolated.
When you use this mode, this access point is still able to accept wireless clients.
When you select 'AP Bridge-WDS', the following options will be displayed:
Band
MAIN ESSID
Multiple ESSID
Channel
Number
Associated
Clients
MAC address
1-4
Set Security
After you finish with setting, please click 'Apply'. Hereafter, the settings you made are
successfully saved. You can click the 'Continue' button to go back to the previous page
and continue changing other settings, or click the 'Apply' button to restart the wireless
access point. The changes will take effect after about 30 seconds.
Please select the wireless band you wish to use. By selecting
different band setting, you'll be able to allow or deny the
wireless client of a certain band.
If you select 2.4GHz (B), 2.4GHz (N), or 2.4GHz (G), only
wireless clients using the wireless band you select (802.11b,
802.11 Draft-N, or 802.11g) will be able to connect to this
access point.
If you select 2.4GHz (B+G), then only wireless clients using
802.11b and 802.11g band will be able to connect to this
access point.
If you want to allow 802.11b, 802.11g, and 802.11 Draft-N
clients to connect to this access point, select 2.4GHz
(B+G+N).
Please input the ESSID (the name used to identify this
wireless access point) here. You can input up to 32
alphanumerical characters. PLEASE NOTE THAT ESSID IS
CASE SENSITIVE.
The access point supports multiple SSID function; up to four
SSIDs can be set. If you want to configure additional SSIDs,
please click this button. For detailed descriptions of the
function, please refer to Section 2-4-1-1.
Please select a channel number you wish to use. The channel
number must be same with another wireless access point you
wish to connect
Click 'Show Active Clients' button and a new popup window
will appear which contains the information about all wireless
clients connected to this access point. You can click 'Refresh'
button in popup window to keep information up-to-date.
Please input the MAC address of the wireless access point you
wish to connect
Click this button to select an encryption mode for this wireless
link, a new popup window will appear. Please refer to Section
2-7 for detailed descriptions.
