2-4-3 Universal Repeater
In this mode, the access point can act as a wireless repeater; it can be Station and AP at
the same time. It can use Station function to connect to a Root AP and use AP function
to service all wireless stations within its coverage. The WL-330 Universal Repeater uses
this mode as default setting.
NOTE: For Repeater Mode, this access point will demodulate the received
signal, checking if this signal is noise for the operating network then have the
signal modulated and amplified again. The output power of this mode is the
same as that of WDS and normal AP mode.
Band
MAIN ESSID
Channel
Number
Associated
Clients
Root AP SSID
Select Site
Survey
Please select the wireless band you wish to use. By selecting
different band setting, you'll be able to allow or deny the
wireless client of a certain band.
Please input the ESSID (the name used to identify this
wireless access point) here. You can input up to 32
alphanumerical characters. PLEASE NOTE THAT ESSID IS
CASE SENSITIVE.
Please select a channel number you wish to use. The channel
number must be same with another wireless access point you
wish to connect
Click 'Show Active Clients' button and a new popup window
will appear which contains the information about all wireless
clients connected to this access point.
In 'Universal Repeater' mode, this device can act as a station
to connect to a Root AP. You should assign the SSID of the
Root AP here or click 'Select Site Survey' button to choose a
Root AP.
Click 'Select Site Survey' button, then a "Wireless Site Survey
Table" will pop up. It will list all available access points near
by.
