AKG DMS70 Specifications

•
•
•
•
•
•
•
•
•
DMS 70 is a true uncompressed digital wireless system. The DMS 70 operates with 24bit 48 kHz transmission to
ensure top-quality audio for every customer. The frequency is the 2.4GHz ISM range a worldwide license-free
frequency range. DMS 70 system offers exceptional studio-quality sound thanks to its uncompressed digital audio
transmission capability and it is designed for the most exacting applications where the highest level of wireless audio
performance is required. The bodypack (pocket) transmitter is especially recommended for guitar and bass because of
its ideal frequency response between 20 Hz to 20 kHz. DMS 70 works convincing for live and club sound,
conferences, seminars, schools and universities – whenever quick and easy setup up is required.
The entire DMS 70 package includes: AKG's DSR 70 Quattro or DSR 70 Dual Receiver, DPT 70 Digital Pocket
Transmitter and DHT 70 Digital Handheld Transmitter, available with patented D5 acoustics or DHT 70 Perception with
standard dynamic capsule.
The DSR 70 Quattro includes a rack mount kit, power supply and other accessories. The customers can use and
combine all system devices to their needs, as they are all fully compatible. All DMS 70 devices are available
separately or in the following prepared packages: The Vocal-, Instrumental- and the mixed version of
Vocal/Instrumental- set. The Quattro packs include two and the Dual sets one digital transmitter.
All DMS 70 devices feature bidirectional communication between the transmitter and receiver. The dynamic frequency
selection provides "intelligent" operation in the crowded 2,4 GHz band, enabled by digital diversity from receiver and
transmitter side. It's easy setup functions make the system simple to use, even for less experienced operators, while
the AES 128-bit encryption ensures secure 2-way wireless communication. The DSR 70 Quattro receiver can work
with up to four channels of audio in parallel, which can be mixed down directly to its balanced XLR sum output. The
DHT 70 mic employs AKG's patented dynamic D5 capsule to deliver outstanding sound quality with less feedback and
handling noise.
Based on the bidirectional communication DMS 70 offers a number of additional new and unique features, including
power off from receiver side for all connected transmitters, battery status monitoring and out of range warning.
