- Page 2 Table of contents: The complete DSM 700 family Die komplette DMS 700 Familie DHT 700 Digital handheld transmitter DHT 700 Digitaler Handsender DPT 700 Digital bodypack transmitter DPT 700 Digitaler Taschensender DSR 700 Digital stationary receiver DSR 700 Digital Empfänger CU 700 Charging unit CU 700 Ladegerät Last modification :...
- Page 3 DHT 700 DPT 700 Digital handheld Digital bodypack transmitter transmitter DSR 700 Digital stationary receiver CU 700 Charging unit Mains cable: 0110E03160 0110E03170 Frequency range, Mhz, DSR 700 Antenna: Band 1 548,100 – 697,900 / 50mW Band 1 (long) 9999N07440 710,100 –...
- Page 4 DHT 700 D5 3157Z00… DHT 700 C5 3157Z00… DHT 700 D7 3157Z00… 25,26 Wiring / Verkabelung Sleeve 5 to be glued on end cap 9 after it is completely screwed onto part 4 (thread part). Use UHU PLUS ENDFEST 300. inphase inphase (red)
- Page 5 DHT 700 Parts list / Stückliste Quantity Part number Bezeichnung Description Pos. Stück Bestellnummer Wire-mesh cap 3157M12010 Gitterkappe Wire-mesh cap 3157M12020 Gitterkappe Wire-mesh cap 3157M12030 Gitterkappe Foam insert 3138Z25020 Innenwindschutz Foam insert 3138Z25010 Innenwindschutz Electret capsule C5 3157M15010 Elektretkapsel C5 Dynamik capsule D5 2610Z00050 Dynamische Kapsel D5...
- Page 6 Frequency band and power / Frequenzband und Leistung Preset-- BD1 U BD2 RO B2 NZ BD2 AU BD2 JP BD2 TH BD2 HK BD2 KR BD2 BY BD2 IT BD2 IL Main board 50mW 50mW 10/50mW 30mW 10/50mW 50mW 10mW 50mW 10/20mW 10mW...
- Page 7 DPT 700 D5 3156Z00… DPT 700V2 D5 3156Z02… 19,20 Wiring / Verkabelung All charging contact solder joints: pre-solder related pads on pcb assemble pcb and frame assy. melt solder by heating up charging contacts with soldering tip (apply some pressure) All cables from pcb carrier assy.
- Page 8 DPT 700 Parts list / Stückliste Quantity Part number Description Pos. Stück Bezeichnung Bestellnummer Housing compl.*, upper 3156M11010 Gehäuseoberteil kompl. Housing, bottom 3156Z11010 Gehäuseunterteil Battery cover assy. 3156M14010 Batteriedeckel Frame assy. 3156M12010 Rahmen kompl. Frame assy. 3156M12020 Rahmen kompl. LCD display 0050E00070 LCD Display Display holder...
- Page 9 DSR 700 3155Z00… 20,21 15,16...
- Page 10 Frontpanel...
- Page 11 DSR 700 Parts list / Stückliste Quantity Bezeichnung Part number Stück Description Pos. Bestellnummer Housing, upper 3155Z11010 Gehäuseoberteil Housing, bottom 3155M10010 Gehäuseunterteil Power supply unit 3155M04010 Netzteil IEC power socket 0017E15070 IEC Einbaustecker Isolation plate 3155Z45010 Isolationplatte Cable assy. 0110E03220 Kabel DSP Main board 3155M02010...
- Page 12 Important! For ordering the DSR 700 front board we need following information Preset programming: Bd1, Bd2, BD2/IL, BD2/IT…etc. (please see table below) Frequency band / Frequenzband Preset-- BD1 U BD2 RO B2 NZ BD2 AU BD2 JP BD2 TH BD2 HK BD2 KR BD2 BY...
- Page 13 CU 700 3158Z00010 Wiring / Verkabelung...
- Page 14 CU 700 Parts list / Stückliste Part number Quantity Description Pos. Bezeichnung Bestellnummer Stück Housing bottom 3158Z12010 Gehäuseunterteil DC-Jack socket 0016E03760 DC-Buchse Fan holder 3158Z23010 Lüfterhalter 0027E00710 Lüfter Insert part assy. 3158M11120 Einsteckteil Main board 3158M01010 Hauptprint Light guide 3158Z13010 Lichtleiter Housing top 3158Z10010...
