INSTALLATION AND MAINTENANCE INSTRUCTIONS
2112/24B and 2112/24TB
Photoelectronic
Smoke Detectors
Specifications
Diameter:
Height (including mounting bracket):
Weight:
Operating Temperature Range
Model 2112/24B:
Model 2112/24TB:
Operating Humidity Range:
Latching Alarm:
Heat Sensor (2112/24TB only):
Electrical Ratings
System Voltage (nominal):
Minimum:
Maximum:
Maximum Ripple Voltage:
Standby Current:
Alarm Current:
Reset Voltage:
Reset Time:
Start-up Time:
EOL Relay:
Alarm Initiation Contact Ratings
Resistive or inductive load (60% power factor)
Form A:
Before Installing
Please thoroughly read the System Sensor manual I56-407,
Guide for Proper Use of System Smoke Detectors, which pro-
vides detailed information on detector spacing, placement,
zoning, wiring, and special applications. Copies of this
manual are available at no charge from System Sensor.
NOTICE: This manual should be left with the owner/user
of this equipment.
IMPORTANT: This detector must be tested and maintained
following NFPA 72 requirements. The detector should be
cleaned at least once a year.
General Description
Model 2112/24B is a 4-wire photoelectronic smoke detector
that uses a state-of-the-art optical sensing chamber. This
detector is designed to provide open area protection. Model
2112/24TB features a restoreable, built-in, fixed-tempera-
ture (135° F) thermal detector.
D200-62-00
5.5 inches (140 mm)
1.7 inches (43 mm)
5.3 oz. (150 g)
32° to 120° F (0° to 50° C)
32° to 100°F (0° to 39° C)
10% to 93% Relative Humidity, Noncondensing
Reset by momentary power interruption
135°F Fixed Temperature Electronic Thermistor
12 or 24 VDC
8.5 VDC
35 VDC
30% of nom. Voltage (peak to peak)
50 µ A maximum
17 mA typical, 23 mA max. at 12V
19 mA typical, 25 mA max. at 24V
0.8 VDC minimum
0.3 seconds maximum
30 seconds maximum (after 60 sec. reset)
A77-716B, 12/24 Volt
0.5A @ 30 VAC/DC
Installation of these detectors is simplified by the use of a
mounting bracket and a plug-in screw terminal block that
can be prewired to the system, allowing the detector to be
easily installed or removed for cleaning. The detector's sen-
sitivity can be tested in place using the MOD400R Test
Module.
An LED on the detector provides a local visual indication of
the detector's status. If power is applied to the detector, and
it is functioning normally in standby, the status LED blinks
every ten seconds. The LED also latches on in alarm.
Models 2112/24B and 2112/24TB feature a visual indication
that maintenance is required – if the sensing chamber drifts
out of its sensitivity limits, the LED ceases to blink.
1
A Division of Pittway
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
I56-932-01
