INSTALLATION AND MAINTENANCE INSTRUCTIONS
1100 Direct Wire Ionization
Smoke Detector
Specifications
Diameter:
Height (including adapter bracket): 1.7 inches (43 mm)
Weight:
Operating Temperature Range:
Operating Humidity Range:
Latching Alarm:
Electrical Ratings
System Voltage:
Maximum Ripple Voltage:
Start-up Capacitance:
Average Standby Current:
Alarm Ratings:
Reset Voltage:
Reset Time:
Start-up Time:
Before Installing
Please thoroughly read the System Sensor manual I56-407-
XX, Guide for Proper Use of System Smoke Detectors, which
provides detailed information on detector spacing, place-
ment, zoning, wiring, and special applications. Copies of
this manual are available at no charge from System Sensor.
NOTICE: This manual should be left with the owner/user
of this equipment.
IMPORTANT: This sensor must be tested and maintained
regularly following NFPA 72 requirements. This sensor
should be cleaned at least once a year.
D200-55-00
5.5 inches (140 mm)
5.3 oz. (150 g)
32° to 120°F (0° to 50° C)
10% to 93% Relative Humidity, Noncondensing
Reset by momentary power interruption
12 or 24 VDC
Minimum 8.5 VDC
Maximum 35 VDC
30% of nominal voltage (peak to peak)
0.1 µF maximum
50 µA maximum
4.2 VDC minimum at 10 mA.
6.6 VDC minimum at 100 mA.
(Alarm current must be limited to 100 mA maximum by the
control panel. The optional RA400Z Remote Annunciator
operates within the specified detector alarm currents.)
2.5 VDC minimum
0.3 seconds maximum
30 seconds maximum (after 60 second reset)
General Description
The 1100 is a 2-wire ionization smoke detector that uses a
state-of-the-art sensing chamber. This detector is designed
to provide open area protection and to be used with com-
patible UL-listed, 2-wire panels only.
Installation of these detectors is simplified by the use of an
adapter bracket and a plug-in screw terminal block that can
be prewired to the system, allowing the detector to be eas-
ily installed or removed for cleaning. The detector's sensi-
tivity can be tested in place using the MOD400R Test
Module.
An LED on the detector provides a local visual indication of
the detector's status. If power is applied to the detector, and
it is functioning normally in standby, the status LED blinks
every five seconds. The LED also latches on in alarm.
Model 1100 features a visual indication that maintenance is
required – if the sensing chamber drifts out of its sensitivity
limits, the LED ceases to blink.
The detector also includes an output that allows an op-
tional RA400Z Remote Annunciator to be connected.
1
A Division of Pittway
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
I56-713-02
