GREAT PLAINS CT8400-24 Assembly Manual

Field cultivator, rigid hitch

Advertisement

Quick Links

Table of Contents
Assembly Manual
CT8400-24, CT8400-29, CT8400-33 & CT8400-36
Read the operator's manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit.
ORIGINAL INSTRUCTIONS
