- Page 1 IRB-X50™ R e t r o r e f l e c t i v e P h o t o e y e 4564 Johnston Parkway, Cleveland, Ohio 44128 P. 800 426 9912 F. 216 518 9884 Sales Inquiries: salessupport@emxinc.com Technical Support: technical@emxinc.com...
- Page 2 Contents Cautions and Warnings Specifications Ordering Information Installation Wiring Connections Troubleshooting Warranty EMX Industries, Inc. Tech support: 216-518-9889 Document No. 10500104 Rev. 1.0 technical@emxinc.com...
- Page 3 Since the reflector directs the beam back to the photoeye, wiring to the other side of the detection zone is not needed. The IRB-X50 operates up to 50 feet over a voltage range of 12-240 VDC and 24-240 VAC. Two LED indicators provide status information at a glance making set-up and alignment easy.
- Page 4 2. Set the sensitivity adjustment to 1/3 of the maximum setting. 3. Mount the IRB-X50 at the desired location. Hold the reflector and stand at least 1 foot away from the photoeye. Align the reflector and slowly back up to the opposite end of the detection zone where it will be mounted.
- Page 5 Black Relay – NC (normally closed contact) The relay contacts labeled on the wiring diagram are shown in the energized state, aligned with the reflector and no obstruction. EMX Industries, Inc. Tech support: 216-518-9889 Document No. 10500104 Rev. 1.0 technical@emxinc.com...
- Page 6 Warranty EMX Industries, Inc. products have a warranty against defects in materials and workmanship for a period of two years from date of sale to our customer. EMX Industries, Inc. Tech support: 216-518-9889 Document No. 10500104 Rev. 1.0...
