EMX ULT-PLG Instruction Manual

Instruction Manual
The ULT-PLG plug-in style vehicle loop detector senses metallic objects near an induction loop.
This vehicle detector may be used in center, reverse and exit loop positions. The ULTRAMETER™ display
allows for easy set-up by displaying the optimum sensitivity setting for detecting a vehicle near the loop
while ignoring interference. Ten sensitivity settings allow for fine adjustment of the detection level.
The ULT-PLG features a user configurable Output B for fail safe/secure, pulse on entry/exit, presence or
EMX exclusive, Detect-on-Stop™ (DOS
in multi-loop applications.

Cautions and Warnings

This product is an accessory or part of a system. Install the ULT-PLG according to
instructions from the gate or door operator manufacturer. Comply with all applicable
codes and safety regulations.

Specifications

Power
Draw Current
Loop Frequency
Loop Inductance Range
Surge Protection
Operating Temperature
Connector
Dimensions (L x W x H)

Ordering Information

ULT-PLG
•
PR-XX
•
TSTL
•
EMX Industries, Inc.
ULT-PLG_Rev1.8_082619
ULT-PLG
™
Plug-In Vehicle Loop Detector
® ). Four frequency settings provide flexibility in preventing crosstalk
Plug-in vehicle loop detector (included)
Lite preformed loop (XX – specify size)
Test loop, troubleshooting tool
Tech support: 216-834-0761
technical@emxinc.com
12-24 VDC
15 mA
4 settings (low, med-low, med-hi, high)
20-2000 µH (Q factor ≥ 5)
Loop circuitry protected by surge suppressors
-40º to 180ºF (-40º to 82ºC) 0 to 95% relative humidity
10 pin female
3.0" (76 mm) x 0.9" (22 mm) x 2.75" (70 mm)
1/6
