  • Page 1 PANIO CH1612 User Manual V1.1.05...
  • Page 2 Contents 1、Packing ........................ 2 2、Panel description ....................2 3、Font buttons switching operation ............... 3 4、WEB GUI Browser control ................3 5、TCP/IP/RS232 control ..................5 6、Remote Control ....................5 7、APP control ......................6 １...
  • Page 3 1、Packing 1 x CH1612 1 X Power cord 1 x IR (battery not provided) 1 x Quick guide 2、Panel description Front panel INPUT : HDMI1-HDMI16 input buttons OUTPUT : HDMI1-HDMI16 output buttons MENU：Press to enter main menu UP / DOWN：Up and down buttons ENTER : OK button POWER：Power indicator light, always on after power on.
  • Page 4 OUTPUT : HDMI output ports RS232 ports for the 3rd party control RJ45 port for the WEB GUI/TCP/IP control 3、Font buttons switching operation Before switching, press any key to enter the main menu, and the words menu will appear on the front panel screen before switching.
  • Page 5 Step3 : select the output for the video wall. Step4 : select the on to open the video wall. EDID Management： Switch : select the output, and then click the input, then will copy the EDID of input to output. Recall : select the EDID in the system, and then select the input, it's mean copy the EDID in the system to input.
  • Page 6 switch the input 1 to the screen, if input 1 also have not source connected, the matrix will auto switch input 2 to the screen, matrix will follow the principle from input 1 to input 16 based connect some input sources. Last Mode : that means the screen will be showed the last signal of connection, and will off the auto switch function, when the input source are disconnected, the display will be black.
  • Page 7 1 to 1 switch : select the input button + select the corresponding output button. 1-to-many switch : Select the input button + select the corresponding multiple output buttons. 1-to-all switch: select the input button + select the UP button. Scene Save: Press SAVE then press the scene number from 1~16, and finally press ENTER Scene Recall : Press RECALL then press the scene number from 1~16,...
