- Page 1 PANIO CH8810K User Manual V2.1...
- Page 2 Contents 1、Packing ........................2 2、Panel description ..................... 2 3、Font buttons switching operation ..............2 4、WEB GUI Browser control ..................3 5、TCP/IP/RS232 control .................... 4 6、Remote Control ......................5 7、APP control ........................ 5 １...
- Page 3 1、Packing 1 x CH8810K 1 x DC24V 1A 1 x IR (battery not provided) 1 x Quick guide 2、Panel description Front panel INPUT : HDMI1-HDMI8 input buttons OUTPUT : HDMI1-HDMI8 output buttons MENU：Press to enter main menu UP / DOWN：Up and down buttons ENTER : OK button POWER：Power indicator light, always on after power on.
- Page 4 1 to 1 switch : select the input button + select the corresponding output button. 1-to-many switch : Select the input button + select the corresponding multiple output buttons. 1-to-all switch: select the input button + select the UP button. 4、WEB GUI Browser control The default IP address is 192.168.1.188, Open the browser and enter the IP address of the matrix switch to perform web page control operations：...
- Page 5 EDID Management： Switch : Slecet the output, and then click the input, then will copy the EDID of input to output. Recall : Slecet the EDID in the system, and then slecet the input, it's mean copy the EDID in the system to input. Save : Slecet the output, and then slecet the system, then will save the output EDID to system.
- Page 6 Commend Function #SW:[X]to[Y]. Switch input [X] to output [Y] #ASW:[X],[Y]. output [X]，slecet the swich mode [Y]- 0:off, 1:Automode, 2:Lastmode #SAVE:[X]. Save sence，[X] is 1--32 #RECALL:[X]. Racall sence，[X] is 1--32 #BUZZER:[X]. On or Off the Buzzer，[X]- 0:OFF, 1:ON #RESET. Restore to factory setting #VSW:?.
