Panio HD1800K User Manual

PANIO

HD1800K User manual

Table of Contents

Need help?

Do you have a question about the HD1800K and is the answer not in the manual?

Page 1 PANIO HD1800K User manual...
Page 2 Contents 1. Packing ........................3 2. Panel description ....................3 3. EDID DIP switch .....................4 4. COM Control Commands ..................5 5. IR Control System ....................6...
Page 3 1. Packing Name Unit Name Unit HD1800K-HDBaseT Splitter 5-pin Phoenix Connector HD1800K-R receivers Rack accessories IR Blaster Cable (1.5 meters) IR Receiver cable RS-232 cables User manual 3-pin Phoenix Connector Power Cord 2. Panel description Front panel Power LED When the HDMI IN port connects an active source device, the green LED will be on.
Page 4 HDBT OUTPUT port (1~8). Link Signal Indicator lamp (Green) Data Signal Indicator lamp (Orange) DC 24V POWER switch HDBaseT Receiver Panel Power LED. SERVICE port: Firmware update port. DC 24V/1A power supply input port. Note: The Matrix supports POC function, it means that either transmitter or receiver is powered on by 24V/1A power adapter, the other one doesn’t need power supply.
Page 5 4. COM Control Commands RS232 cable with straight-through connection(USB-RS232 can be used directly to control) Communication protocol:...
Page 6 Baud rate: 115200 Data bit: 8 Stop bit: 1 Power power on power on/off the device,z=0~1 s power z! System Initializing... Initialization (z=0 power off, z=1 power on) Finished! power off r power! get current power state power on /power off Reboot…...
