- Page 1 PANIO HD4420K User manual...
-
Page 2: Table Of Contents
Contents 1. Packing ........................3 2. Panel description ....................3 3. Matrix Switcher control ..................5 Remote Control ..................... 5 WEB GUI Browser control ..................5 COM Control Commands ..................8 IR Control System ....................10... -
Page 3: Packing
1. Packing Name Unit Name Unit HD4420K-Matrix Switcher 5-pin Phoenix Connector HD4420K-R receivers Rack accessories Remote Control IR Blaster&Receiver cable Battery not provided RS-232 cables User manual 3-pin Phoenix Connector Power Cord 2. Panel description Front panel OLED screen: Display matrix switching status, input / output port, EDID, Baud rate, IP Address. - Page 4 POWER button: Press and hold the POWER button for 3 seconds to enter the standby mode, then press the button again to wake up the device. IR Window IR receiver window, it only receives the IR remote signal from this product. LOCK button Press the LOCK button to lock front panel buttons (Except the power button);...
-
Page 5: Matrix Switcher Control
Power LED. SERVICE port: Firmware update port. DC 24V/1A power supply input port. Note: The Matrix supports POC function, it means that either transmitter or receiver is powered on by 24V/1A power adapter, the other one doesn’t need power supply. RJ45 connector for connecting the HDBT OUTPUT port of Matrix with a CAT cable. - Page 6 Status page: The buttons at the top right of the web interface are always available and provide the following function: •The Log out button will disconnect the current user from display the log in screen. •The Power on button changes the power status of the Switcher between On and Stand-by mode. Video page: The Video page allows selection of the inputs source and set the Scene.
- Page 7 The EDID data from any input or from the User 1 and User 2 locations can be read and stored on your Output page: The outputs can also be assigned meaningful names, if desired. The Output page provides information about the signal status of the outputs. You can do the following operations on the Output page: ①...
-
Page 8: Com Control Commands
CEC page: You can perform CEC management on this page: ① Input Control: You can control the operation of each input source by pressing the icons on the page. (You can control multiple inputs simultaneously.) ② Output Control: You can control the operation of each display, such as power on/off, volume +/-, active source switching. - Page 9 Baud rate: 115200 Data bit: 8 Stop bit: 1 Check bit: None Command Explanation Feedback Power power on power on/off the device,z=0~1 System Initializing... s power z! (z=0 power off, z=1 power on) Initialization Finished! power off r power! get current power state power on /power off Reboot…...
-
Page 10: Ir Control System
s id z! Set the control ID of the product, z=000~999 id 888 Output Setting s in x av out y! input 1 -> output 2 Set input x to output y，x=1~4，y=0~4(0=all) input 1 -> output 1 input 2 -> output 2 r av out y! Get output y signal status y=0~4(0=all) ……... - Page 11 At HDBaseT receiver (Remote end): IR signal follows video switch to change. For example, the HDMI output signal on the HDBaseT Receiver 1 is from the HDMI INPUT 2 port, so IR input signal of the HDBaseT Receiver 1 will emit to IR OUT 2 port of the Matrix. The HDMI output signal on the HDBaseT Receiver 3 is from the HDMI INPUT 4 port.
