Summary of Contents for Panio HD8820K

  • Page 1 PANIO HD8820K User manual...

  • Page 2: Table Of Contents

    Contents 1. Packing ........................3 2. Panel description ....................3 3. Matrix Switcher control ..................5 Remote Control ..................... 5 WEB GUI Browser control ..................5 COM Control Commands ..................8 IR Control System ....................10...

  • Page 3: Packing

    1. Packing Name Unit Name Unit HD8820K-Matrix Switcher 5-pin Phoenix Connector HD8820K-R receivers Rack accessories Remote Control IR Blaster&Receiver cable Battery not provided RS-232 cables User manual 3-pin Phoenix Connector Power Cord 2. Panel description Front panel OLED screen: Display matrix switching status, input / output port, EDID, Baud rate, IP Address.
  • Page 4 press the button again to wake up the device. IR Window IR receiver window, it only receives the IR remote signal from this product. LOCK button Press the LOCK button to lock front panel buttons (Except the power button); Press the button again to unlock.

  • Page 5: Matrix Switcher Control

    Power LED. SERVICE port: Firmware update port. DC 24V/1A power supply input port. Note: The Matrix supports POC function, it means that either transmitter or receiver is powered on by 24V/1A power adapter, the other one doesn’t need power supply. RJ45 connector for connecting the HDBT OUTPUT port of Matrix with a CAT cable.
  • Page 6 Status page: The buttons at the top right of the web interface are always available and provide the following function: •The Log out button will disconnect the current user from display the log in screen. •The Power on button changes the power status of the Switcher between On and Stand-by mode. Video page:The Video page allows selection of the inputs source and set the Scene.
  • Page 7 Output page: The outputs can also be assigned meaningful names, if desired. The Output page provides information about the signal status of the outputs. You can do the following operations on the Output page: ① Outputs: Output channel of the device. ②...

  • Page 8: Com Control Commands

    ① Input Control: You can control the operation of each input source by pressing the icons on the page. (You can control multiple inputs simultaneously.) ② Output Control: You can control the operation of each display, such as power on/off, volume +/-, active source switching.
  • Page 9 Explanation Feedback Power power on power on/off the device,z=0~1 s power z! System Initializing... Initialization (z=0 power off, z=1 power on) Finished! power off r power! get current power state power on / power off Reboot… s reboot! reboot the device System Initializing...

  • Page 10: Ir Control System

    Set input x to output y，x=1~8， s in x av out y! input x -> output y y=0~8(0=all) input 1 -> output 1 input 2 -> output 2 r av out y! Get output y signal status y=0~4(0=all) …… input 8 -> output 8 Get hdmi output y port output mode r hdmi y scaler ! hdmi y set to bypass mode...
  • Page 11 At HDBaseT receiver (Remote end): IR signal follows video switch to change. For example, the HDMI output signal on the HDBaseT Receiver 1 is from the HDMI INPUT 2 port, so IR input signal of the HDBaseT Receiver 1 will emit to IR OUT 2 port of the Matrix. The HDMI output signal on the HDBaseT Receiver 3 is from the HDMI INPUT 4 port.
