Summary of Contents for Panio HD1400K
- Page 1 PANIO HD1400K User manual...
-
Page 2: Table Of Contents
Contents 1. Packing ........................3 2. Panel description ....................3 3. EDID DIP switch .....................5 4. COM Control Commands ..................6 5. IR Control System ....................6... -
Page 3: Packing
1. Packing Name Unit Name Unit HD1400K-HDBaseT Splitter 5-pin Phoenix Connector HD1400K-R receivers Rack accessories IR Blaster Cable (1.5 meters) IR Receiver cable RS-232 cables User manual 3-pin Phoenix Connector Power Cord 2. Panel description Front panel Power LED When the HDMI IN port connects an active source device, the green LED will be on. -
Page 4: Edid Dip Switch
Connect to IR receiver cable, the IR receive signal will emit to “IR OUT” port of the HDBaseT Receiver. Connect to IR blaster cable, the IR emit signal is from “IR IN” port of the HDBaseT Receiver. AUDIO OUT (COAX, L/R). POWER switch. -
Page 5: Com Control Commands
3. EDID Mode 4. COM Control Commands RS232 cable with straight-through connection(USB-RS232 can be used directly to control) Communication protocol:... -
Page 6: Ir Control System
Baud rate: 115200 Data bit: 8 Stop bit: 1 Power power on power on/off the device,z=0~1 s power z! System Initializing... Initialization (z=0 power off, z=1 power on) Finished! power off r power! get current power state power on /power off Reboot…...
