- Page 1 PANIO HW2250K User manual...
- Page 2 Contents 1. Packing ........................3 2. Panel description ....................3 3. Remote Control .....................4...
- Page 3 1. Packing Name Unit Name Unit HW2250K Remote Control Battery not provided DC 12V Quick Guide 2. Panel description Front panel IR: for the IR remote control POWER: Power indicator light INPUT1 : for the HDMI inputs selection INPUT2: for the DP inputs selection...
- Page 4 Remote Control IN1, IN2: When connecting HDMI and DP signals at the same time, users can press the IN1 or IN2 to select to output. RESET: Press to reset when want to reset the bezel correction, output ports flip/rotating. SPLICING MODES: quick setup buttons for users to set the video wall The other buttons on this remote control is for the HDMI multiviewer Switch...
- Page 5 ROT1: For HDMI output 1 flipping, need to press reset button when want the normal display. ROT2: For HDMI output 2 flipping, need to press reset button when want the normal display. ROT3: For HDMI output 3 flipping, need to press reset button when want the normal display. ROT4: For HDMI output 4 flipping, need to press reset button when want the normal display.
