- Page 1 PANIO CH4400K User manual...
-
Page 2: Table Of Contents
Contents 1. Packing ........................3 2. Panel description ....................3 3. Matrix Switcher control ..................4 Remote Control ..................... 4 WEB GUI Browser control ..................4 COM Control Commands ..................7... -
Page 3: Packing
1. Packing Name Unit Name Unit CH4400K IR extension cable DC 12V 2.5A Rack accessories Remote Control User manual Battery not provided RS-232 cables 2. Panel description Front panel IR Sensor: IR input for remote control of the switcher. POWER LED: Red LED indicates that the unit is powered. -
Page 4: Matrix Switcher Control
HDMI Input 1 to 4 HDMI Source inputs 1 to 4. HDMI Output 1 to 4HDMI outputs for displays 1 to 4. DC 12V INDC 12V input for 12V 2.5A PSU. 3. Matrix Switcher control This Matrix switcher can support IR remote,RS232/ WEB GUI browser or the front push-buttons control. Remote Control ... - Page 5 Status page: The buttons at the top right of the web interface are always available and provide the following function: •The Log out button will disconnect the current user from display the log in screen. •The Power on button changes the power status of the Switcher between On and Stand-by mode. Video page: The Video page allows selection of the inputs source and set the Scene.
- Page 6 The EDID data from any input or from the User 1 and User 2 locations can be read and stored on your Output page: The outputs can also be assigned meaningful names, if desired. The Output page provides information about the signal status of the outputs. The Scaler mode menu provides the following options: Bypass: Follow the input source.
-
Page 7: Com Control Commands
System page: The system page allows setting of the panel lock and beep on/off, control RS-232 port baud rate. This page is also used to install new firmware update, restore the factory default settings and reboot the Switcher. COM Control Commands RS232 cable with straight-through connection(USB-RS232 can be used directly to control) Communication protocol: Baud rate: 115200... - Page 8 Get the connection status of the x input port, r link in x! HDMI IN1: connect x=0~4(0=all) Get the connection status of the y output port, r link out y! HDMI OUT1: connect y=0~4(0=all) Enable/Disable buzzer function,z=0~1(z=0 beep s beep z! beep on / beep off off, z=1 beep on) r beep!
- Page 9 z=0~1(z=0,off,z=1 on) hdmi output 1 arc off r hdmi y arc! Get the arc state of HDMI output y，y=0~4(0=all) hdmi out1 arc on...
